5-port Dual-speed Fast Ethernet Hub
Asanté's FriendlyNet FH205P 5-port Dual-speed Ethernet Hub offers a cost-effective solution to
today's growing need for greater network speed. With five10/100Mbps plug-and-play ports, you can
begin installing 100Mbps devices in your existing 10Mpbs network and move to a 100Mbps network
in the future.
Key features include:
•
Compliant with IEEE802.3 & 802.3u Class I and II Repeater specifications
•
10Base-T/100Base-TX N-WAY automatic speed detection
•
Compact size
•
One Uplink switch to support uplink function
PACKAGE CONTENTS
The package should include the following items:
•
One FriendlyNet FH205P 5-port Dual-speed Ethernet Hub
•
One power adapter
•
One power cord
•
One mail-in registration card
•
One User's Guide
If any item is missing, please contact your dealer immediately.
Page 1
FriendlyNet FH205P
User's Guide
1
PRODUCT INTRODUCTION
Advertisement
Table of Contents
Related Manuals for Asante FriendlyNet FH205P
Summary of Contents for Asante FriendlyNet FH205P
- Page 1 User’s Guide PRODUCT INTRODUCTION Asanté’s FriendlyNet FH205P 5-port Dual-speed Ethernet Hub offers a cost-effective solution to today’s growing need for greater network speed. With five10/100Mbps plug-and-play ports, you can begin installing 100Mbps devices in your existing 10Mpbs network and move to a 100Mbps network in the future.
-
Page 2: Hardware Description
3/17/99 5:45 PM Page 2 HARDWARE DESCRIPTION Front Panel The LED indicators help you to monitor the working status of the hub and overall network situation. 100Mbps Speed-detection LED FH205P 100Mbps LINK/ACT 10M 100M Power Collision LED Link / Activity LED... - Page 3 FH205PQSG 3/17/99 5:45 PM Page 3 A: Basic Installation Place the hub on a smooth, horizontal surface. Establish network connection by plugging one end of the Category 5 UTP/STP cable RJ-45 connector into the hub port, the other end to the Ethernet/Fast Ethernet adapter installed in the workstation computer.
- Page 4 FH205PQSG 3/17/99 5:45 PM Page 4 The FriendlyNet FH205P can be deployed where 10Mbps and 100Mbps network devices coexist and need to be integrated. The diagram below illustrates one sample application: Uplink Node DC 5V Connection cable may be up to 100 meters long...
