E Brake and clutch fluid reservoir (left-hand drive)
clutch fluid check (page 202).
F Battery: See Vehicle battery (page 209).
G Auxiliary fuse box: See Fuses (page 176).
H Air cleaner: No maintenance necessary.
I Engine oil dipstick
*
For easy identification, filler caps and the engine oil dipstick are marked in
colour.
ENGINE OIL DIPSTICK -
1.6L DURATEC-16V
(SIGMA)/1.6L DURATEC-
16V TI-VCT (SIGMA)
A B
E95540
A MIN
B MAX
Maintenance
*
: See Engine oil check (page 200).
ENGINE OIL DIPSTICK -
1.8L DURATEC-HE
(MI4)/2.0L DURATEC-HE
(MI4)
E92036
199
*
: See Brake and
A B
A MIN
B MAX
