Important
Please read this User's Manual carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
重要
请仔细阅读用户手册,熟练掌握其安全和有效的操作程序。
请妥善保存此手册,供日后参考。

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DuraVision FDV1002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eizo DuraVision FDV1002

  • Page 1 Important Please read this User’s Manual carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. 重要 请仔细阅读用户手册,熟练掌握其安全和有效的操作程序。 请妥善保存此手册,供日后参考。...
  • Page 2: Fcc Declaration Of Conformity

    For U.S.A. , Canada, etc. (rated 100-120 Vac) Only FCC Declaration of Conformity We, the Responsible Party EIZO NANAO TECHNOLOGIES INC. 5710 Warland Drive, Cypress, CA 90630 Phone: (562) 431-5011 declare that the product Trade name: EIZO Model: DuraVision FDX1002/FDV1002 is in conformity with Part 15 of the FCC Rules.
  • Page 4: Safety Symbols

    EIZO NANAO CORPORATION’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
  • Page 5: Precautions

    PRECAUTIONS IMPORTANT • To ensure personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor. 【 Location of Caution Statement 】 WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice.
  • Page 6 WARNING Use the unit in an appropriate location. Not doing so may result in fire, electric shock, or equipment damage. • Do not place outdoors. • Do not place in a transportation system (ship, aircraft, train, automobile, etc.) where it may be affected by strong vibration or shock.
  • Page 7 WARNING Do not touch a damaged LCD panel directly with bare hands. The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part of the skin or body comes in direct contact with the panel, please wash thoroughly. If some physical symptoms result, please consult your doctor.
  • Page 8: Notice For This Monitor

    Notice for this monitor This product is suited for displaying microscope images. This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. This product may not be covered by warranty for uses other than those described in this manual.
  • Page 9: Lcd Panel

    Cleaning ATTENTION • Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage the cabinet or LCD panel. NOTE • Optional ScreenCleaner is recommended for cleaning the panel surface. ● LCD Panel •...
  • Page 10: Table Of Contents

    CONTENTS Cover ............1 PRECAUTIONS ..........3 Notice for this monitor ..........6 CONTENTS ............8 Chapter 1 Introduction ........9 1-1. Features .............. 9 1-2. Package Contents ..........9 1-3. Controls and Functions ........10 Chapter 2 Connecting Cables......11 2-1.
  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 10.4-inch screen • Resolution FDX1002: XGA (1024 × 768) display compliant / FDV1002: VGA (640 × 480) display compliant • Maximum brightness FDX1002: 600 cd/m / FDV1002: 450 cd/m •...
  • Page 12: Controls And Functions

    1-3. Controls and Functions Setting menu button Switches the input signal. Displays the Setting menu, fixes the setting or adjustment items on each menu, button and saves the setting or adjustment results. • Used to select the setting or adjustment items, or to increase or decrease the adjustment values on each menu.
  • Page 13: Chapter 2 Connecting Cables

    Chapter 2 Connecting Cables 2-1. Connection Procedures Connects to external equipment compatible with the monitor. ・ When used as a PC monitor ・・・・・・・・・・・・・・・・・・・・・・・・・・ page 11 ・ When using video equipment ・・・・・・・・・・・・・・・・・・・・・・・・・ page 12 ● When used as a PC monitor ATTENTION •...
  • Page 14: When Using Video Equipment

    (1) Connect the monitor to the PC with a signal cable that matches the connectors. After connecting the cable connectors, tighten the screws of the connectors to secure the coupling. monitor D-Sub mini 15-pin D-Sub mini 15-pin connector Signal cable MD-C87 (optional) connector Signal cable FD-C16 (optional) DVI connector...
  • Page 15: Adjusting The Screen Angle

    Plug the power cord of the monitor into a power outlet. (1) Connect the power cord to the AC adapter. (2) Connect the AC adapter to the Power jack of the monitor, and after that, connect the power plug to a power outlet.
  • Page 16: Chapter 3 Settings And Adjustments

    Chapter 3 Settings and Adjustments 3-1. Basic Operation and Functions Basic operation of Setting menu Setting Displaying Menu Press Setting/Adjusting Exiting Choose [Exit] with , and press NOTE • Keeping pressed for 2 seconds will also exit the Setting menu. Chapter 3 Settings and Adjustments...
  • Page 17 Functions The settings adjustable in the Setting menu are as shown below. The availability of items depends on the input signal. : Configurable : Not configurable ― √ Setting / adjustable item Video Reference √ √ page 16 Color Brightness √...
  • Page 18: Color Adjustment

    3-2. Color Adjustment This will perform color adjustments. Please switch between the input screens you want to adjust and adjust them one by one. Adjustable item / adjustable value Adjusting Brightness 0 - 30 Adjusts the brightness of the backlight. Contrast 0 - 30 Adjusts the contrast.
  • Page 19: Configure Other Settings

    3-3. Configure other settings This will configure other settings. Setting item / setting value Setting Normal/100% Configures the display range of the input image (overscan). Video Aspect “Normal” Displays the input image with the outmost parts slightly cut off. * This is how display devices normally display images.
  • Page 20: Capturing Screenshots

    Even if “ON” is selected in the Reverse display function settings (see page 17) , the captured screenshot will be saved in unreversed form. NOTE The files are saved in the “EIZO” folder on the connected USB memory device. • File handling This can be used to display or delete files on the USB memory device.
  • Page 21 Handling • To browse through captured screenshots: Select [Prev]/[Next] with , and press To delete files: • (1) Choose [Menu] with , and press (2) Choose [Delete] with , and press (3)Select “OK” in the deletion confirmation dialog box and press •...
  • Page 22: Chapter 4 Troubleshooting

    Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. Common Problems Possible cause and remedy No picture • Check whether the power cord is connected correctly. • Power indicator does not light. •...
  • Page 23 When displaying on a PC screen Problems Possible cause and remedy The message below appears. • This message appears when the signal is not input correctly even when the monitor functions properly. • This message appears when no signal • The message shown left may appear, because some is input.
  • Page 24: Chapter 5 Reference

    5-1. Attaching an Arm The stand can be removed and replaced with an arm (or another stand) to be attached to the monitor. Use an arm or stand of EIZO option. ATTENTION When attaching an arm or stand, follow the instructions of their user’s manual.
  • Page 25: Specifications

    5-2. Specifications FDX1002 10.4-inch (260 mm) TFT color LCD LCD Panel Size Surface treatment Anti-glare hard coating Surface hardness Horizontal 160°, Vertical 130° (CR : 10 or more) Viewing angle Dot Pitch 0.2055 mm Display Area (H × V) 210.4 mm × 157.8 mm 1024 dots ×...
  • Page 26 Operating temperature : 0 °C - 40 °C (32 °F - 104 °F) Environmental Temperature Storage temperature : -20 °C - 60 °C (-4 °F - 140 °F) Conditions Operating humidity : 20% - 80% R.H. (no condensation) Humidity Storage humidity : 10% - 80% R.H. (no condensation) Operating : 700 hPa - 1060 hPa Pressure Storage : 200 hPa - 1060 hPa...
  • Page 27 30°Up, 0°Down Movable Tilt range 35°Right, 35°Left Swivel Operating temperature : 0 °C - 40 °C (32 °F - 104 °F) Environmental Temperature Storage temperature : -20 °C - 60 °C (-4 °F - 140 °F) Conditions Operating humidity : 20% - 80% R.H. (no condensation) Humidity Storage humidity : 10% - 80% R.H.
  • Page 28: Outside Dimensions

    Outside Dimensions unit : mm (inch) FDX1002 35° 35° 252 (9.9) 20 (0.79) 212 (8.3) 20 (0.79) 32 (1.26) 175 (6.9) 200 (7.9) 204 (8.0) Chapter 5 Reference...
  • Page 29 FDV1002 35° 35° 252 (9.9) 20 (0.79) 213 (8.4) 20 (0.79) 32 (1.26) 175 (6.9) 200 (7.9) 204 (8.0) Chapter 5 Reference...
  • Page 30: Connector Pin Assignment

    Connector Pin Assignment • D-Sub mini 15-pin connector Pin No. Signal Pin No. Signal Pin No. Signal Red video Red video ground Green video Green video ground Data (SDA) Blue video Blue video ground H. Sync V. Sync Ground Ground Clock (SCL) (NC*: No Connection) •...
  • Page 31: Glossary

    5-3. Glossary Afterimage The Afterimage is particular to LCD monitors. When the monitor screen is left on for a long period without use. The Afterimage can be removed gradually by changing the displayed image. Clock The analog input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog input signal is converted to a digital signal for image display.
  • Page 32: Preset Timing

    5-4. Preset Timing The following table shows the factory preset video timing of the PC. ATTENTION Display position may be deviated depending on the PC connected, which may require screen adjustment using • Setting menu. If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen •...
  • Page 33: Limited Warranty

    Original Purchaser or any third parties other than as provided under this Warranty. EIZO and Distributors will cease to hold or store any parts of the Product upon expiration of seven (7) years after the production of such parts is discontinued. In repairing the monitor, EIZO and Distributors will use renewal parts which comply with our QC standards.
  • Page 35 关于电子信息产品污染控制标识 本标识根据「电子信息产品污染控制管理办法」 ,适用于在中华人民共和国销售的电子信息产品。标识中央的 数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项,在自制造日起算的年限内,不会 产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 • 有毒有害物质或元素的名称及含量 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI) ) (PBB) (PBDE) 印刷电路板 × ○ ○ ○ ○ ○ 机箱 ○ ○ ○ ○ ○ ○ 液晶显示器 × ○ ○ ○...
