User's Manual
Color LCD Monitor
Touch Panel Color LCD Monitor
Important
Please read this User's Manual, and the Setup Manual (separate
volume) carefully to familiarize yourself with safe and effective usage.
• Please refer to the Setup Manual for basic information ranging from
monitor installation to using the monitor.
• The latest User's Manual is available for download from our web site:
http://www.eizoglobal.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eizo DuraVision FDX1203-BK
Summary of Contents for Eizo DuraVision FDX1203-BK
- Page 1 User’s Manual Color LCD Monitor Touch Panel Color LCD Monitor Important Please read this User’s Manual, and the Setup Manual (separate volume) carefully to familiarize yourself with safe and effective usage. • Please refer to the Setup Manual for basic information ranging from monitor installation to using the monitor.
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Table Of Contents
Setting the Orientation ........17 3-2. Enabling / Disabling DDC/CI communication ...........17 3-3. Locking Operation Buttons ......17 3-4. Showing and hiding the EIZO logo ....17 3-5. Setting Language .........18 3-6. Resetting the Monitor to the Default Settings ............18 ● To reset the color adjustments .......18 ●... -
Page 4: Chapter 1 Introduction
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • FDX1003 / FDX1003T : 10.4″ LCD, FDX1203 / FDX1203T : 12.1″ LCD • Supports a resolution of 1024 ×768 • LED backlight LCD panel The LED backlight provides better power efficiency and reduced power consumption compared to existing fluorescent backlight LCD panels. -
Page 5: Eizo Lcd Utility Disk
1-2. EIZO LCD Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and the overview of the software programs. ● Disk contents and software overview The disk includes adjustment software, touch panel software, and user’s manuals. Refer to Readme. -
Page 6: Basic Operation Of The Setting Menu
1-3. Basic Operations and Functions ● Basic operation of the Setting menu Displaying the Setting menu 1. Press . The Setting menu appears. Adjusting / Setting 1. Choose a menu to adjust / set with , , and then press . -
Page 7: Functions
Language “3-5. Setting Language” (page 18) DDC/CI “3-2. Enabling / Disabling DDC/CI communication” (page 17) Logo “3-4. Showing and hiding the EIZO logo” (page 17) Reset “To reset all adjustments to the default settings” (page 18) Information “6-2. Displaying Monitor Information” (page *1 The adjustment / settings available on the “Color”... -
Page 8: Chapter 2 Adjusting Screens
Chapter 2 Adjusting Screens 2-1. Setting the Resolution ● Display resolution For details on compatible resolutions, refer to “Compatible Resolutions” in the Setup Manual. ● Setting resolution When you connect the monitor to the PC and find that the resolution is improper, or when you want to change the resolution, follow the procedure below. -
Page 9: Adjusting Color
Mac OS X 1. Select “System Preferences” from the Apple menu. 2. When the “System Preferences” dialog box is displayed, click “Displays” for “Hardware”. 3. On the displayed dialog box, select the “Display” tab and select desired resolution in the “Resolutions”... -
Page 10: Adjustable Settings In Each Mode
● Adjustable settings in each mode The adjustable settings depend on the mode. (Non-adjustable or non-settable function cannot be selected.) √: Adjustable -: Not adjustable Color Mode Function User1 User2 sRGB Brightness √ √ √ Temperature √ √ Advanced Settings Saturation √... -
Page 11: To Adjust Color Temperature
● To adjust color temperature Color temperature can be adjusted. The color temperature is normally used to express the hue of “White” and / or “Black” by a numerical value. The value is expressed in degrees “K” (Kelvin). The screen becomes reddish at a low color temperature, and bluish at a high color temperature, like the flame temperature. -
Page 12: To Adjust Hue
● To adjust hue This function allows you to adjust hue. Adjustable range -50 to 50 Procedure 1. Choose “Color” in the Setting menu, and press 2. Choose “Advanced Settings” in the “Color” menu, and press 3. Choose “Hue” in the “Advanced Settings” menu, and press The “Hue”... -
Page 13: Screen Adjustment
2-3. Screen Adjustment ● Digital Signal Input When digital signals are input, images are displayed correctly based on the preset data of the monitor, but if characters and / or lines appear blurred, go to “To modify blurred characters / lines” (page 16). - Page 14 Prepare to use analog screen adjustment patterns. Load the “EIZO LCD Utility Disk” to your PC, and then open the “Screen adjustment pattern files”. Note • For details and instructions on opening the “Screen adjustment pattern files”, refer to the Readme.txt file.
- Page 15 ● To remove flickering or blurring Procedure 1. Choose “Analog Adjustment” in the “Screen” menu, and press 2. Choose “Phase” in the “Analog Adjustment” menu, and press The “Phase” menu appears. 3. Adjust the phase with to minimize flickering or blurring. 4.
- Page 16 Adjusting color gradation. ● To adjust color gradation automatically Every color gradation (0 to 255) can be displayed by adjusting the signal output level. Procedure 1. Display Pattern 2 in full screen on the monitor using the “Screen adjustment pattern files”. 2.
-
Page 17: Chapter 3 Setting Monitor
- Turning on or off the monitor with the Power button 3-4. Showing and hiding the EIZO logo When the monitor is turned on, the EIZO logo appears on the screen. You can choose to show or hide the display of the EIZO logo. -
Page 18: Setting Language
3-5. Setting Language This function allows you to select a language for the Setting menu or messages. Selectable languages English, German, French, Spanish, Italian, Swedish, Japanese, Simplified Chinese, Traditional Chinese Procedure 1. Choose “Monitor Settings” in the Setting menu, and press 2. -
Page 19: Chapter 4 Power Saving Functions
Chapter 4 Power Saving Functions 4-1. Setting Power Saving This function allows you to set the monitor into the power saving mode according to the PC status. When the monitor has shifted to the power saving mode, the images on the screen are not displayed. Attention •... -
Page 20: Enabling / Disabling Auto Power-Off
4-3. Enabling / Disabling Auto Power-OFF This function allows you to switch the setting to turn off the monitor automatically after a specified time has passed in the power saving mode. Adjustable range Off, 0, 1, 2, 3, 5, 10, 15, 20, 25, 30, 45 min, 1, 2, 3, 4, 5 h Procedure 1. -
Page 21: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. 5-1. No picture Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Power indicator does not light. -
Page 22: Imaging Problems (For Both Digital And Analog)
1. The screen is too bright or too dark. • Adjust “Brightness” in the Setting menu. (The LCD monitor backlight has a limited life span. When the screen becomes dark or begins to flicker, contact your local EIZO representative.) 2. Characters are blurred. -
Page 23: Other Problems
5-4. Other problems Problem Possible cause and remedy 1. The Setting menu does not appear. • Check whether the operation lock function is active (see “3-3. Locking Operation Buttons” (page 17)). 2. The “Smoothing” on the Setting menu • You cannot choose “smoothing” when the screen is “Screen”... -
Page 24: Chapter 6 Reference
Chapter 6 Reference 6-1. Connecting Multiple PCs The product has multiple connections to PCs and allows you to switch to one of the connections for display. Connection examples DVI-D connector D-Sub connector Signal cable Signal cable (option FD-C39) (supplied MD-C87) D-Sub mini 15-pin DVI connector connector... -
Page 25: To Set Input Signal Selection
● To set input signal selection Setting Function Auto The monitor recognizes the connector through which PC signals are input. When a PC is turned off or enters the power saving mode, the monitor automatically displays another signal. Manual The monitor detects only the PC’s signals currently displaying automatically. Select the input signal for display using the operation button. -
Page 26: Preset Timing
6-3. Preset Timing The following table shows factory preset analog signal timing. Attention • Display position may be deviated depending on the PC connected, which may require screen adjustment using Setting menu. • If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen display may still be incorrect even after the adjustment. -
Page 27: Chapter 7 Glossary
Chapter 7 Glossary Clock The analog signal input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog signal is converted to a digital signal for image display. - Page 28 Resolution The LCD panel consists of numerous pixels of specified size, which are illuminated to form images. This monitor consists of horizontal 1024 pixels and 768 vertical pixels. At a resolution of 1024 × 768, all pixels are illuminated as a full screen (1:1). sRGB (Standard RGB) International standard for color reproduction and color space among peripheral devices (such as monitors, printers, digital cameras, scanners).
-
Page 29: Appendix
Kensington and MicroSaver are trademarks of ACCO Brands Corporation. EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO ScreenSlicer, i • Sound, Screen Administrator, UniColor Pro, and Re/Vue are trademarks of EIZO Corporation. -
Page 30: Limited Warranty
The period of this Warranty is two (2) years from the date of purchase of the Product (hereinafter referred to as the “Warranty Period”). EIZO and Distributors shall bear no liability or obligation with regard to the Product in relation to the Original Purchaser or any third parties other than as provided under this Warranty. - Page 31 Haftung oder Verpfl ichtung dem Erstkäufer oder Dritten gegenüber. Nach Ablauf von sieben (7) Jahren nach Ende der Produktion solcher Teile werden EIZO und Vertriebshändler keine Teile (mit Ausnahme von Konstruktionsteilen) mehr vorhalten und lagern. EIZO und seine Vertriebspartner verpfl ichten sich, bei einer etwaigen Reparatur des Monitors ausschließlich Produkte gemäß...
- Page 32 EIZO et ses distributeurs utiliseront des pièces de rechange conformes à nos normes de contrôle qualité. Si l'unité ne peut pas être réparée en raison de son état ou de la rupture de stock d'une pièce adéquate, EIZO et ses Distributeurs peuvent proposer le remplacement par un produit aux performances équivalentes au lieu de le réparer.
- Page 33 EIZO y los distribuidores utilizarán repuestos que cumplan con nuestros estándares de control de calidad. Si no utilizzeranno p se puede reparar la unidad debido a su estado o si se han agotado las existencias de una pieza importante, EIZO y sus causa delle su distribuidores podrían ofrecerle sustituirlo por un producto con rendimiento equivalente en lugar de repararlo.
- Page 34 GARANZIA LIMITATA EIZO Corporation (a cui si farà riferimento da qui in poi con “EIZO”) ed i Distributori autorizzati da EIZO (a cui si farà riferimento da qui in poi con “Distributori”) garantiscono, secondo i termini di questa garanzia limitata (a cui si farà...
- Page 35 Nät skärmen repareras använder EIZO och distributörer reservdelar som uppfyller våra kvalitetsstandarder. Om enheten inte kan repareras på grund av skicket eller att en del inte fi nns i lager kan EIZO och dess leverantörer erbjuda sig att byta ut produkten mot en produkt med likvärdig prestanda istället för att reparera den.
- Page 36 «Εγγύηση»), στον αρχικό αγοραστή (στο εξής «Αρχικός Αγοραστής») ο οποίος αγόρασε το προϊόν που καθορίζεται στο παρόν έγγραφο (στο εξής «Προϊόν») από την EIZO ή τους Διανομείς, η οποία εξασφαλίζει ότι η EIZO και οι Διανομείς, σύμφωνα με τη διακριτή ευχέρειά τους, είτε θα επισκευάσουν είτε θα αντικαταστήσουν το Προϊόν χωρίς χρέωση εάν ο...
- Page 37 Компания EIZO и ее дистрибьюторы хранят детали изделия (за исключением деталей внешней конструкции) не более 7 (семи) лет после прекращения его выпуска. В случае ремонта монитора EIZO и Дистрибьюторы будут использовать запчасти, которые соответствуют нашим стандартам QC (контроль качества). Если устройство невозможно...
- Page 38 有限责任保证书 EIZO Corporation（以下简称 “EIZO”）和 EIZO 授权的经销商（以下简称 “ 经销商 ”） ，接受并依照本有限责任保证书（以 下简称 “ 保证书 ”）之条款， 向从 EIZO 和经销商购买本文中所规定产品（以下简称 “ 产品 ”）的原买方（以下称 “ 原买方 ”） 提供保证 ： 在保证期内（规定如下） ，如果原买方发现按本产品所附使用说明书（以下简称 “ 用户手册 ”）所述方式正常使 用本产品过程中，本产品出现故障或损坏，EIZO 和经销商根据其独自的判断免费修理或更换该产品。 本保证期限定为本产品自购买本产品之日起的二（2）年（以下简称 “ 保证期限 ”） 。EIZO 和经销商将不向原买方或任何第 三方承担本保证书所规定之外的与本产品有关任何责任或义务。 零件停产七（7）年后，EIZO 及其经销商不再保留或保存产品的任何零件（设计零件除外） 。维修显示器时，EIZO 与经销...
-
Page 39: Recycling Information
Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una fi lial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. http://www.eizoglobal.com Informazioni sul riciclaggio Per lo smaltimento e il riciclaggio del presente prodotto, attenersi alle normative vigenti nel proprio paese per ridurre l’impatto ambientale. - Page 40 Ten produkt po zużyciu powinien być zbierany i przetwarzany zgodnie z krajowymi przepisami dotyczącymi ochrony środowiska. Wyrzucając ten produkt, należy skontaktować się z lokalnym dystrybutorem lub partnerem. Adresy kontaktowe można znaleźć we wskazanej poniżej witrynie internetowej fi rmy EIZO. http://www.eizoglobal.com...
- Page 41 Při likvidaci produktu musí být produkt vyzvednut a recyklován podle zákonů příslušné země, aby nedocházelo k zatěžování životního prostředí. Zbavujete-li se produktu, kontaktujte distributora nebo pobočku ve své zemi. Kontaktní adresy jsou uvedeny na následující webové stránce společnosti EIZO. http://www.eizoglobal.com Ringlussevõtu alane teave...
- Page 42 вашата страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: http://www.eizoglobal.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
- Page 43 3rd Edition-May, 2016 03V25221C1 Copyright © 2014-2016 EIZO Corporation All rights reserved. (U.M-FDX1003)
