- Page 1 Important Please read this User’s Manual carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. 重要 请仔细阅读用户手册，熟练掌握其安全和有效的操作程序。 请妥善保存此手册，供日后参考。...
-
Page 2: Fcc Declaration Of Conformity
For U.S.A. , Canada, etc. (rated 100-120 Vac) Only FCC Declaration of Conformity We, the Responsible Party EIZO NANAO TECHNOLOGIES INC. 5710 Warland Drive, Cypress, CA 90630 Phone: (562) 431-5011 declare that the product Trade name: EIZO Model: DuraVision FDX1001T/FDV1001T/FDX1201T is in conformity with Part 15 of the FCC Rules. -
Page 4: Safety Symbols
EIZO NANAO CORPORATION’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice. -
Page 5: Precautions
PRECAUTIONS IMPORTANT • To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below). 【 Location of Caution Statement 】 WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises,disconnect all power connections immediately and contact your dealer for advice. - Page 6 WARNING Use the unit in an appropriate location. Not doing so may result in fire, electric shock, or equipment damage. • Do not place outdoors. • Do not place in a transportation system (ship, aircraft, train, automobile, etc.) where it may be affected by strong vibration or shock.
- Page 7 WARNING Do not touch a damaged LCD panel directly with bare hands. The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part of the skin or body comes in direct contact with the panel, please wash thoroughly. If some physical symptoms result, please consult your doctor.
-
Page 8: Notice For This Monitor
Notice for this monitor Aside from displaying microscope images, this product is also suited to the dedicated usages such as operation of terminal equipment. This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. -
Page 9: To Use The Monitor Comfortably
Cleaning ATTENTION • Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage the cabinet or panel. • Do not soak liquid into the clearance between the panel and the panel frame. NOTE •... -
Page 10: Table Of Contents
CONTENTS Cover ............1 PRECAUTIONS ..........3 Notice for this monitor ..........6 CONTENTS ............8 Chapter 1 Introduction ........9 1-1. Features .............. 9 1-2. Package Contents ..........9 1-3. Controls and Functions ........10 Chapter 2 Connecting Cables......11 2-1. Connection Procedures ........11 ● When used as a PC monitor ......11 ● When using video equipment ......12 2-2. Adjusting the Screen Angle ......13 2-3.Installing the Touch Panel Driver ..... 14 2-4.Calibrating the Monitor ........14 Chapter 3 Settings and Adjustments . -
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • FDX1001T/FDV1001T: 10.4-inch screen, FDX1201T: 12.1-inch screen • Resolution - FDX1001T/FDX1201T: XGA (1024 × 768) display compliant - FDV1001T: VGA (640 × 480) display compliant •... -
Page 12: Controls And Functions
1-3. Controls and Functions Setting menu button Switches the input signal. Displays the Setting menu, fixes the setting or adjustment items on each menu, button and saves the setting or adjustment results. ・ Used to select the setting or adjustment items, or to increase or decrease the adjustment values on each menu. -
Page 13: Chapter 2 Connecting Cables
Chapter 2 Connecting Cables 2-1. Connection Procedures Connects to external equipment compatible with the monitor. ・ When used as a PC monitor ･････････････････････････ page 11 ・ When using video equipment ････････････････････････ page 12 ● When used as a PC monitor ATTENTION •... -
Page 14: When Using Video Equipment
(1) Connect the monitor to the PC with a signal cable that matches the connectors. After connecting the cable connectors, tighten the screws of the connectors to secure the coupling. monitor D-Sub mini 15-pin D-Sub mini 15-pin connector Signal cable MD-C87 (optional) connector Signal cable FD-C16 (optional) DVI connector... -
Page 15: Adjusting The Screen Angle
Plug the power cord of the monitor into a power outlet. (1) Connect the power cord to the AC adapter. (2) Connect the AC adapter to the Power jack of the monitor, and after that, connect the power plug to a power outlet. -
Page 16: 2-3.Installing The Touch Panel Driver
Uninstall the other touch panel driver, if it is installed. Insert the “EIZO Touch Panel Disk” CD-ROM to the CD-ROM drive. Double click “Setup.exe” from the drive into which the “EIZO Touch Panel Disk” CD-ROM has been inserted. Follow the instruction of the menu to install the touch panel driver. -
Page 17: Chapter 3 Settings And Adjustments
Chapter 3 Settings and Adjustments 3-1. Basic Operation and Functions Basic operation of Setting menu Displaying Setting Menu Press Setting/Adjusting Exiting Choose [Exit] with , and press NOTE • Keeping pressed for 2 seconds will also exit the Setting menu. Chapter 3 Settings and Adjustments... - Page 18 Functions The settings adjustable in the Setting menu are as shown below. The availability of items depends on the input signal. : Configurable : Not configurable ― √ Setting / adjustable item Video Reference Color Brightness page 17 √ √ Contrast √...
-
Page 19: Color Adjustment
3-2. Color Adjustment This will perform color adjustments. Please switch between the input screens you want to adjust and adjust them one by one. Adjustable item / adjustable value Adjusting Brightness 0 - 30 Adjusts the brightness of the backlight. Contrast 0 - 30 Adjusts the contrast. -
Page 20: Configure Other Settings
3-3. Configure other settings This will configure other settings. Setting item / setting value Setting Video Aspect Normal/100% Configures the display range of the input image (overscan). “Normal” Displays the input image with the outmost parts slightly cut off. * This is how display devices normally display images. -
Page 21: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. Common Problems Possible cause and remedy No picture • Check whether the power cord is connected correctly. • Power indicator does not light. •... - Page 22 Touch panel problems Problems Possible cause and remedy Cursor position is not correct. / Cursor • Turn off and on the monitor. If the symptom is not jumps. improved, perform the calibration on the monitor. • Touch with one finger only. Touch operation is not effective.
-
Page 23: Chapter 5 Reference
Reference 5-1. Attaching an Arm The stand can be removed and replaced with an arm (or another stand) to be attached to the monitor. Use an arm or stand of EIZO option. ATTENTION • When attaching an arm or stand, follow the instructions of their user’s manual. -
Page 24: Specifications
5-2. Specifications FDX1001T LCD Panel Size 10.4-inch (260 mm) TFT color LCD Surface treatment Anti-glare Surface hardness Viewing angle Horizontal 160°, Vertical 130° (CR : 10 or more) Dot Pitch 0.2055 mm Display Area (H × V) 210.4 mm × 157.8 mm Resolution 1024 dots ×... - Page 25 Environmental Temperature [Operating temperature] Conditions Main unit : 0 °C - 50 °C (32 °F - 122 °F) AC adapter : 0 °C - 40 °C (32 °F - 104 °F) [Storage temperature] -20 °C - 60 °C (-4 °F - 140 °F) Humidity [Operating humidity] Main unit : 20% - 90% R.H.
- Page 26 Dimensions Main unit 252 mm (9.9 inch) × 255 mm (10 inch) × 175 mm (6.9 inch) (Width) × Main unit (without stand) 252 mm (9.9 inch) × 216 mm (8.5 inch) × 45 mm (1.77 inch) (Height) × (Depth) Mass Main unit Approx.
- Page 27 Video input Applicable Format NTSC, PAL, SECAM Input Signal Connector S-Video DIN mini 4 pin/ Video Pin jack × 1 Input Signal Level S-Video DIN mini 4 pin : Y 1.0Vp-p/75Ω, C 0.28Vp-p/75Ω Video Pin jack : 1.0Vp-p/75Ω Power Supply AC adapter (AC) : 100-240VAC±10%, 50/60Hz, 0.4-0.25A (Max.) Main unit (DC) : 12VDC±10%, 1.4 A Power...
-
Page 28: Outside Dimensions
Outside Dimensions unit : mm (inch) FDX1001T / FDV1001T 252 (9.9) 20 (0.79) 213 (8.4) 20 (0.79) 175 (6.9) 200 (7.9) 201 (7.9) FDX1201T 35° 35° 30° 293 (11.5) 22.8 (0.90) 22.8 (0.90) 247.4 (9.7) 200 (7.9) 175 (6.9) 207 (8.1) Chapter 5 Reference... -
Page 29: Connector Pin Assignment
Connector Pin Assignment • D-Sub mini 15-pin connector Pin No. Signal Pin No. Signal Pin No. Signal Red video Red video ground Green video Green video ground Data (SDA) Blue video Blue video ground H. Sync V. Sync Ground Ground Clock (SCL) (NC*: No Connection) •... -
Page 30: Glossary
5-3. Glossary Afterimage The Afterimage is particular to LCD monitors. When the monitor screen is left on for a long period without use. The Afterimage can be removed gradually by changing the displayed image. Clock The analog input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog input signal is converted to a digital signal for image display. -
Page 31: Preset Timing
5-4. Preset Timing The following table shows the factory preset video timing of the PC. ATTENTION • Display position may be deviated depending on the PC connected, which may require screen adjustment using Setting menu. • If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen display may still be incorrect even after the adjustment. -
Page 32: Limited Warranty
Original Purchaser or any third parties other than as provided under this Warranty. EIZO and Distributors will cease to hold or store any parts of the Product upon expiration of seven (7) years after the production of such parts is discontinued. In repairing the monitor, EIZO and Distributors will use renewal parts which comply with our QC standards. - Page 33 关于电子信息产品污染控制标识 本标识根据「电子信息产品污染控制管理办法」 ，适用于在中华人民共和国销售的电子信息产品。标识中央的 数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项，在自制造日起算的年限内，不会 产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 • 有毒有害物质或元素的名称及含量 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 （Pb） （Hg） （Cd） （Cr（VI） ） （PBB） （PBDE） 印刷电路板 × ○ ○ ○ ○ ○ 机箱 ○ ○ ○ ○ ○ ○ 液晶显示器 × ○ ○ ○...
