Summary of Contents for Eizo DuraVision FDX1001

  • Page 1 Important Please read this User’s Manual carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. 重要 请仔细阅读用户手册,掌握如何安全、有效地使用本产品。 请保留本手册,以备日后参考。...
  • Page 2: Fcc Declaration Of Conformity

    For U.S.A. , Canada, etc. (rated 100-120 Vac) Only FCC Declaration of Conformity We, the Responsible Party EIZO NANAO TECHNOLOGIES INC. 5710 Warland Drive, Cypress, CA 90630 Phone: (562) 431-5011 declare that the product Trade name: EIZO Model: DuraVision FDX1001/FDV1001/FDX1201 is in conformity with Part 15 of the FCC Rules.
  • Page 4: Safety Symbols

    EIZO NANAO CORPORATION’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
  • Page 5: Precautions

    PRECAUTIONS IMPORTANT • To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below). 【 Location of Caution Statement 】 WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice.
  • Page 6 WARNING Use the unit in an appropriate location. Not doing so may result in fire, electric shock, or equipment damage. • Do not place outdoors. • Do not place in a transportation system (ship, aircraft, train, automobile, etc.) where it may be affected by strong vibration or shock.
  • Page 7 WARNING Do not touch a damaged LCD panel directly with bare hands. The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part of the skin or body comes in direct contact with the panel, please wash thoroughly. If some physical symptoms result, please consult your doctor.
  • Page 8: Notice For This Monitor

    The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc.
  • Page 9: To Use The Monitor Comfortably

    Cleaning ATTENTION • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel. NOTE •...
  • Page 10: Table Of Contents

    CONTENTS Cover ............. 1 PRECAUTIONS ..........3 Notice for this monitor ..........6 CONTENTS ............. 8 Chapter 1 Introduction ........9 1-1. Features .............. 9 1-2. Package Contents ..........9 1-3. Controls and Functions ........10 Chapter 2 Connecting Cables ......11 2-1.
  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • FDX1001/FDV1001: 10.4-inch screen FDX1201: 12.1-inch screen • Resolution - FDX1001/FDX1201: XGA (1024 × 768) display compliant - FDV1001: VGA (640 × 480) display compliant •...
  • Page 12: Controls And Functions

    1-3. Controls and Functions Setting menu button Switches the input signal. Displays the Setting menu, fixes the setting or adjustment items on each menu, button and saves the setting or adjustment results. • Used to select the setting or adjustment items, or to increase or decrease the adjustment values on each menu.
  • Page 13: Chapter 2 Connecting Cables

    Chapter 2 Connecting Cables 2-1. Connection Procedures Connects to external equipment compatible with the monitor. ・ When used as a PC monitor ・・・・・・・・・・・・・・・・・・・・・・・・・・ page 11 ・ When using video equipment ・・・・・・・・・・・・・・・・・・・・・・・・・ page 12 ● When used as a PC monitor ATTENTION •...
  • Page 14: When Using Video Equipment

    (1) Connect the monitor to the PC with a signal cable that matches the connectors. After connecting the cable connectors, tighten the screws of the connectors to secure the coupling. monitor D-Sub mini 15-pin D-Sub mini 15-pin connector Signal cable MD-C87 (optional) connector Signal cable FD-C16 (optional) DVI connector...
  • Page 15: Adjusting The Screen Angle

    Plug the power cord of the monitor into a power outlet. (1) Connect the power cord to the AC adapter. (2) Connect the AC adapter to the Power jack of the monitor, and after that, connect the power plug to a power outlet.
  • Page 16: Chapter 3 Settings And Adjustments

    Chapter 3 Settings and Adjustments 3-1. Basic Operation and Functions Basic operation of Setting menu Setting Displaying Menu Press Setting/Adjusting Exiting Choose [Exit] with , and press NOTE • Keeping pressed for 2 seconds will also exit the Setting menu. Chapter 3 Settings and Adjustments...
  • Page 17 Functions The settings adjustable in the Setting menu are as shown below. The availability of items depends on the input signal. : Configurable : Not configurable ― √ Setting / adjustable item Video Reference Color Brightness √ √ page 16 Contrast √...
  • Page 18: Color Adjustment

    3-2. Color Adjustment This will perform color adjustments. Please switch between the input screens you want to adjust and adjust them one by one. Adjustable item / adjustable value Adjusting Brightness 0 - 30 Adjusts the brightness of the backlight. Contrast 0 - 30 Adjusts the contrast.
  • Page 19: Configure Other Settings

    3-3. Configure other settings This will configure other settings. Setting item / setting value Setting Video Aspect Normal/100% Configures the display range of the input image (overscan). “Normal” Displays the input image with the outmost parts slightly cut off. * This is how display devices normally display images.
  • Page 20: Chapter 4 Troubleshooting

    Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. Common Problems Possible cause and remedy No picture • Check whether the power cord is connected correctly. • Power indicator does not light. •...
  • Page 21: Chapter 5 Reference

    5-1. Attaching an Arm The stand can be removed and replaced with an arm (or another stand) to be attached to the monitor. Use an arm or stand of EIZO option. ATTENTION • When attaching an arm or stand, follow the instructions of their user’s manual.
  • Page 22: Specifications

    5-2. Specifications FDX1001 LCD Panel Size 10.4-inch (260 mm) TFT color LCD Surface treatment Anti-glare hard coating Surface hardness Viewing angle Horizontal 160°, Vertical 130° (CR : 10 or more) Dot Pitch 0.2055 mm Display Area (H × V) 210.4 mm × 157.8 mm Resolution 1024 dots ×...
  • Page 23 Environmental Temperature [Operating temperature] Conditions Main unit : 0 °C - 50 °C (32 °F - 122 °F) AC adapter : 0 °C - 40 °C (32 °F - 104 °F) [Storage temperature] -20 °C - 60 °C (-4 °F - 140 °F) Humidity [Operating humidity] Main unit : 20% - 90% R.H.
  • Page 24 Mass Main unit Approx. 3.4 kg (7.5 lbs.) Main unit (without stand) Approx. 1.8 kg (4.0 lbs.) Movable Tilt 30°Up, 0°Down range Swivel 35°Right, 35°Left Environmental Temperature [Operating temperature] Conditions Main unit : 0 °C - 50 °C (32 °F - 122 °F) AC adapter : 0 °C - 40 °C (32 °F - 104 °F) [Storage temperature] -20 °C - 60 °C (-4 °F - 140 °F)
  • Page 25 Power Screen Display On AC adapter (AC) : 20 W or less Consumption Main unit (DC) : 17 W or less Power Off AC adapter (AC) : 1.6 W or less Main unit (DC) : 0.8 W or less Dimensions Main unit 293 mm (11.5 inch) ×...
  • Page 26: Outside Dimensions

    Outside Dimensions unit : mm (inch) FDX1001 35° 35° 30° 252 (9.9) 20 (0.79) 20 (0.79) 212 (8.3) 175 (6.9) 200 (7.9) 201 (7.9) FDV1001 35° 35° 30° 252 (9.9) 20 (0.79) 20 (0.79) 213 (8.4) 175 (6.9) 200 (7.9) 201 (7.9) Chapter 5 Reference...
  • Page 27: Connector Pin Assignment

    FDX1201 35° 35° 30° 293 (11.5) 22.8 (0.90) 22.8 (0.90) 247.4 (9.7) 200 (7.9) 175 (6.9) 207 (8.1) Connector Pin Assignment • D-Sub mini 15-pin connector Pin No. Signal Pin No. Signal Pin No. Signal Red video Red video ground Green video Green video ground Data (SDA)
  • Page 28: Glossary

    5-3. Glossary Afterimage The Afterimage is particular to LCD monitors. When the monitor screen is left on for a long period without use. The Afterimage can be removed gradually by changing the displayed image. Clock The analog input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog input signal is converted to a digital signal for image display.
  • Page 29: Preset Timing

    5-4. Preset Timing The following table shows the factory preset video timing of the PC. ATTENTION • Display position may be deviated depending on the PC connected, which may require screen adjustment using Setting menu. • If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen display may still be incorrect even after the adjustment.
  • Page 30: Limited Warranty

    Original Purchaser or any third parties other than as provided under this Warranty. EIZO and Distributors will cease to hold or store any parts of the Product upon expiration of seven (7) years after the production of such parts is discontinued. In repairing the monitor, EIZO and Distributors will use renewal parts which comply with our QC standards.
  • Page 31 关于电子信息产品污染控制标识 本标识根据「电子信息产品污染控制管理办法」 ,适用于在中华人民共和国销售的电子信息产品。标识中央的 数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项,在自制造日起算的年限内,不会 产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 • 有毒有害物质或元素的名称及含量 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI) ) (PBB) (PBDE) 印刷电路板 × ○ ○ ○ ○ ○ 机箱 ○ ○ ○ ○ ○ ○ 液晶显示器 × ○ ○ ○...
  • Page 32 Helmut-Grashoff-Straße 18, 41179 Mönchengladbach, Germany Phone: +49 2161 8210210 Fax: +49 2161 8210150 中国苏州市苏州工业园区展业路8号中新科技工业坊5B Phone: +86 512 6252 0100 Fax: +86 512 6252 1508 http://www.eizo.com 6th Edition-August, 2012 Printed in Japan. 00N0L562F1 Copyright © 2009-2012 EIZO NANAO CORPORATION All rights reserved. (U.M-FDX1001-AL)
