The following are valid barcode formats for part numbers.
Parts Bin
10020099
10020099
0099
0099
10020099
10020099
As long as there is some difference between the pick ticket and parts bin barcode format, the EP1 can determine
if the user has made mistakes like scanning 2 pick tickets in a row, or scanning 2 parts bins in a row, and will
report any such deviation as an error. In the example shown above there are two differences between the parts
bin and pick ticket barcode. One difference is that the length of the part number is not the same, and the other is
that one uses a 1D format and the other a 2D format.
IMPORTANT NOTE:
directly on the part from the supplier, or it can be the label on the parts bin itself. But once a barcode is
chosen for error proofing, then the operator must stick with that barcode unless a decision is made to
change which barcode to scan. If a decision is made to change the parts bin barcode, then the "Parts bin
setup" on page 20 would have to be performed again while scanning the proper barcode label.
2.) Job Sequence Number: These labels will contain numbers that are in order. It is recommended that this
mode be used mainly to double-check your work. An example would be to use the part number mode at
station 1 to check the parts loaded onto a rack. When the rack arrives at station 2, a second scanner would
be used to check each part for the correct Job Sequence Numbers (JSN) before shipping. A typical label
will resemble figure 8 and each number scanned after the first should be in sequence or an alarm will sound.
3.) JSN/Part Number: This mode generates the most thorough checking. A pick ticket will have both a job
sequence number and part number so two checks are performed at once. A pick ticket barcode label will
contain a dot (a period) separating the job sequence number and part number (ex. 1234567.12345678)
( JSN.PARTNUMBER).
4.) Each scan will then check for a part number that is different (unless you have checked the Dual JSN box)
and a correct sequence number.
When you request a pick ticket barcode be printed for this mode you must request the following format:
Job Sequence Number. Part Number
Pick Ticket
10020099
0099
10020099
0099
20099
099
When choosing parts bin barcodes, the parts bin label can be either a label
