R1 - RAPID GET YOU GOING
ASSEMBLY
• Assemble stems and adjust for length.
• Use the 25cm (10 inch) search head.
• Twist surplus head lead around stem, allowing enough cable for free
movement of the search head. (Push the cable into the cable slots in the
lower stem to hold it firm).
• Connect search head to detector.
• Insert batteries.
SET-UP
• Rotate the right hand control clockwise to turn the unit on. It also acts as
the volume control. Initially set it to the 3 o'clock position. This switches
the unit on. The display will light up and show an option of "PROGRAM"
mode or "MANUAL" mode.
• Press the ENTER push-button. The display will show 5 possible programs
to choose from, with "COIN INLAND" highlighted.
• Press the ENTER push-button to select this program.
• The R1 is now ready to use.
SEARCHING
• Keep the search head at a constant height above the ground, i.e. do not
allow the search head to swing higher at the right and left edges of your
swing.
PINPOINTING
• When you hear a tone from the loudspeaker, you have found a target.
• Keep the head close to the ground & move it away from the target.
• Hold the PINPOINT push-button.
• Sweep the head over the target area.
• The sound will be loudest when the head is directly above the target.
CONTROLLING THE DETECTOR
• To adjust the settings on the detector first press the ENTER button to
activate the MENU system. You can still detect normally in this mode.
• Use the MENU/SCROLL control to highlight an option and then press
ENTER to select it.
• To return to the full search screen keep pressing ENTER until it appears.
• For more details on individual menu options read the instruction manual.
IF A PROBLEM IS ENCOUNTERED REFER TO THE FULL INSTRUCTIONS
INSTRUCTIONS
PROGRAM
MANUAL
