the MENU/SCROLL control press then ENTER button to store the setting. NOTE: This
setting has no effect on the RADAR display or audio level in Pin Point mode.
TIP! This level should be set as high as possible without the R1 spuriously sounding off.
PIN - PT GAIN
DISCRIM MOTION GAIN
SENSITIVITY PIN -PT GAIN
AUDIO TUNE
PROGRAMS
SET UP BACK
This sets the sensitivity of the Pin Point, or NON-MOTION, mode. When Pin-Pt Gain is
selected the R1 automatically selects Pin Point mode to aid setting the level. Once the
desired level has been set by rotating the MENU/SCROLL control press then ENTER button
to store the setting. This setting also alters the sensitivity of the RADAR display. NOTE: This
setting has no effect on the normal MOTION search mode.
TUNE
DISCRIM MOTION GAIN
SENSITIVITY PIN -PT GAIN
AUDIO TUNE
PROGRAMS
SET UP BACK
This sets the threshold or background tone. This is only audible with Silent Search turned
off. As soon as Tune is selected then Silent Search will be turned OFF so that the
background tone will be heard. Once the desired level has been set by rotating the
MENU/SCROLL control press the ENTER button to store the setting.
AUDIO
DISCRIM DISCRIM
SENSITIVITY SIL SEARCH
AUDIO MODE
PROGRAMS
SET UP BACK
This range of functions control how the audio information about buried targets is presented.
DISCRIMINATION
DISCRIM DISCRIM
SENSITIVITY SIL SEARCH
AUDIO MODE
PROGRAMS
SET UP BACK
This enables or disables Audio Discrimination for both Motion and Pin Point modes. Audio
Discrimination gives the operator an indication of the composition of the target by varying the
pitch/tone of the audio signal. For all modes, highlight the desired option by rotating the
MENU/SCROLL control and then press the ENTER button. Note: Pin Point and Motion
Audio Discrimination can be set independently.
PIN - PT OFF
This turns Audio Discrimination OFF for Pin Point Mode.
PIN -PT OFF
PIN -PT ON
MOTION OFF
MOTION ON
