Contents Safety instructions ......................41 Description of the appliance ....................42 Exhausting version ..............................42 Recycling version ..............................42 Special accessories ......................43 Installation ........................... 43 Unpacking ................................43 Placement ................................43 Electrical connection .............................43 Mounting of hood on wall .............................44 Installing the duct for exhausting version ......................45 Installing the duct for recycling into the room (Carbon filter version) ..............45 Mounting of carbon filter ............................
Congratulations to your new Cooker Hood Thank you for your choice of an Electrolux product. We are convinced that you will have great use and pleasure from your new cooker hood. Before you use the cooker hood we recommend that you read through the whole user manual giving a direct description of the cooker hood and its functions.
1. Control panel containing work light 2. Motor speed button 3. Operating light 4. Light button 5. Grease filters 2 pcs on model EFC 635 X 3 pcs on model EFC 935 X Standard accessories included: Wall mounting template Screws No return valve Fig.
Special accessories Flex tube kit Active carbon filter When the hood is to be connected to an evacuation When the hood is used in recirculation mode an channel use the flex tube kit containing one evacu- active carbon filter should be used. ation flex tube, one roof connecting duct and two Order by the retailer "Tube clamps"...
Ø 12mm Ø 12mm Mounting of hood on wall Place the drilling scheme in the correct position (the lower edge and right and left side corre- spond with the lower edge and right and left ends of the hood respectively). Drill the Ø...
Installing the duct for exhausting version Fasten the top support H (fig. 9) to the wall close to the ceiling on the perpendicular of the bottom connections. To do use the two Ø 5x45 screws and Ø 8mm plugs supplied as standard equipment.
Place the carbon filter in the front edge of the hood and fasten it with help of the two hooks at the back edge O (Fig. 12). Replace the grease filter. Fig. 12 Using the hood Using the controls To start the appliance, pull the control panel downwards for access to the light and motor switches.
Maintenance Before performing any maintenance operation, disconnect the hood from the electricity. Grease filter This serves to hold the grease particles in suspen- sion. To remove the filter, push it towards the back of the hood and pull it downwards (Fig. 15). The metal filter should be washed every month with warm soapy water or, if possible, in the dishwasher (60°C).
Technical data Model EFC 635 EFC 935 Capacity Intensive 441 m 275 m 441 m 275 m full speed 360 m 360 m low speed 200 m 200 m Dimension Height 840 - 1170 mm 840 - 1170 mm Width 598 mm 898 mm Depth...
