Summary of Contents for Electrolux EFC6420
- Page 1 Gebrauchsanweisung , Notice d'utilisation et d'installation EFC 6420 EFC 9420 Istruzioni di montaggio ed uso , User manual...
-
Page 2: Table Of Contents
Contents Safety warnings ..............................31 For the installer ..............................31 For the user ................................31 Description of the Appliance ........................... 32 Extractor version ..............................32 Filter Version ................................32 Control Panel ..............................33 Maintenance and care ............................34 Cleaning the hood ..............................34 Metal grease filter .............................. -
Page 3: Safety Warnings
Safety warnings For the installer • When the hood is used in its extractor function, the following rules must be followed to obtain • When used as an extractor unit, the hood must optimal operation: be fitted with a 150mm diameter hose. —... -
Page 4: Description Of The Appliance
• The hood is supplied as an extractor unit and can also be used with a filtering function by fitting one charcoal filter. • You will need an original ELECTROLUX charcoal filter for this function (Available from your local ELECTROLUX Service Force Centre). -
Page 5: Control Panel
Control Panel • Best results are obtained by using a low speed for normal conditions and a high speed when odours are more concentrated. Turn the hood on a few minutes before you start cooking, you will then get an under pressure in the kitchen. The hood should be left on after cooking for about 15 minutes or until all the odours have disappeared. -
Page 6: Maintenance And Care
Maintenance and care • The hood must always be disconnected from the electricity supply before beginning any maintenance work. Cleaning the hood Warning • Clean the outside of the hood using a damp • Failure to observe the instructions on cleaning cloth and a mild detergent. -
Page 7: Charcoal Filter
• The charcoal filter should only be used if you want to use the hood in the recirculation function. • To do this you will need an original ELECTROLUX charcoal filter (available from your local Service Force Centre). • Cleaning/replacing the carbon filter Unlike other carbon filters, the LONGLIFE carbon filter can be cleaned and reactivated. -
Page 8: What To Do If
What to do if If your appliance fails to work properly please carry out the following checks. Symptom Solution The cooker hood will not start... Check that: The hood is connected to the electricity supply. Check that a fan speed has been selected The cooker hood is not working Check that: The fan speed is set high enough for the task. -
Page 9: Technical Assistance Service
Technical assistance service You are welcome to telephone our technical assistance service (see list of technical assistance centres) whenever you need information or in the unlikely event of a fault. For service in Australia call 1300 650 020. When calling, please be ready to specify: 1. -
Page 10: Installation
Installation Unpacking Check that the cooker hood has no damages. Transportation damages should immediately be reported to the one responsible for the transport Damages, faults and eventually missing details should immediately be reported to the seller. Take care of the packing material so that small children cannot play with it. -
Page 11: Mounting Accessories Included
Mounting accessories included 1 deflector 1 chimney support (3 pieces to assemble) 4 metal screws 4 x 8 (to assemble the chimney support) 4 metal screws 3,5 x 9,5 (to affix the deflector to the support) 1 support bracket 5 wood-screws 5 x 45 mm (for wall mounting) 5 wall plugs Ø... -
Page 12: Installation
Installation Wall unit mounting - Fig. 9 Disconnect the hood during electrical connection, by turning the home mains switch off. • Rest the suction unit on a flat surface and thread the lower part of the hood onto it (1). •... -
Page 13: Service And Spare Parts For Uk
* This information can be found on the rating plate, which can be seen when the grease filters are removed. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk... -
Page 14: Guarantee Conditions For Uk
Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. - Page 15 LI11TA Ed. 11/02...
