- Page 1 I N S T RU C T I O N B O O K FOR ELECTROLUX COOKER HOOD EFC 635 and EFC 935 cod. 4329617 03 - 010907...
- Page 2 To enable you to use your application effectively and safely, please read this instruction book carefully before using the appliance and retain for future reference. If you require guidance in the use of the appliance or require further information on Electrolux Products, please contact our Customer Care Department.
-
Page 3: Important Safety Information
• It is dangerous to alter the specifications or Refer to your local Electrolux Service Force modify this product in any way. Centre. Always insist on genuine spare parts. When installed between adjoining wall •... -
Page 4: Your Appliance
YOUR APPLIANCE OPERATING INSTRUCTIONS This cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. Cooker Hood Controls The cooker hood functions are controlled by three switches located to the right on the underside of the hood immediately in front of the metal grease filters. - Page 5 To Operate Select the required fan speed and light if required. The appliance can be installed to recirculate or extract contaminated air. The cooker hood is more effective when used in the extraction mode. Recirculation The cooker hood is supplied specified for use in the recirculation mode with the charcoal filter fitted.
-
Page 6: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before carrying out any maintenance or cleaning isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fire hazard. External Cleaning Wipe the cooker hood frequently with warm soapy water using a mild detergent. -
Page 7: Charcoal Filters
Charcoal Filters In the recirculation mode the charcoal filters absorb smells and unwanted odours. The charcoal filters cannot be cleaned, we recommend they should be replaced approximately every three months or more often if the hood is used for more than three hours per day. -
Page 8: Something Not Working
SERVICE AND SPARE PARTS If you require an engineer or spare parts For general assistance with your appliance or contact your local Service Force Centre by for further information on Electrolux products telephoning: please contact our Customer Care Department. Customer Care Department,... -
Page 9: Guarantee Conditions
GUARANTEE CONDITIONS We, Electrolux, undertake that if within twelve months of the date of the purchase this Electrolux built-in product or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option repair or replace the same FREE OF ANY CHARGE for labour, materials or carriage on condition that: •... -
Page 10: Installation Instructions
INSTALLATION INSTRUCTIONS Technical information DIMENSIONS HEIGHT OF CANOPY: 270mm HEIGHT OF CHIMNEY:(UPPER SECTION) 215mm (LOWER SECTION) 530mm WIDTH OF CANOPY: EFC 635 598mm EFC 935 898mm DEPTH OF CANOPY: 490mm ELECTRICAL SUPPLY VOLTAGE: (~50Hz) 220-240V POWER CONSUMPTION: 225W FAN MOTOR:... -
Page 11: Installing The Cooker Hood
INSTALLING THE COOKER HOOD (Optional Splashback B) Please ensure that when the appliance is The manufacturer disclaims any responsibility for installed it is easily accessible to an engineer damage due to incorrect installation of the cooker in the event of a breakdown. hood or if the hood is not installed in compliance with relevant regulations controlling this type of installation. -
Page 12: Clearance Heights
Clearance Heights The cooker hood is designed to be fitted over a cooking appliance at the clearance heights stated, providing the maximum output of the appliance beneath does not exceed the maximums quoted in the Technical Specifications. If the output of the appliance below the cooker hood exceeds the maximum outputs quoted, please refer to the cooker manufacturer’s installation instructions. - Page 13 Fixing the first wall bracket No 2 Draw a horizontal line through the vertical at 15mm from the ceiling as illustrated, or from a horizontal line drawn between the top of two adjoining wall cabinets. Place the top edge of the bracket against the line, aligning the centre of the bracket with the vertical line.
-
Page 14: Fitting The Canopy Hood
Fitting the Canopy Hood Adjust the two screws V on the top of the canopy to about halfway as illustrated in Fig. 5. Hook the canopy onto the wall bracket 1 and push down until the canopy adjusting screws V rest on the bracket, turn the screws to adjust the canopy vertically and level it horizontally as illustrated in Fig. - Page 15 Extraction The charcoal filters are not required in this mode and should be removed. Ducting The ducting used must be 150mm (6ins), or 125mm (5ins) in diameter. If possible duct through the wall immediately above the canopy. For the best performance use the shortest possible duct run and the minimum number of bends.
-
Page 16: Fitting The Chimney Stack
Fitting the Chimney Stack The chimney consists of two sections. The upper chimney measures 215mm and the lower chimney (with the holes for recirculation on either side) measures 530mm. Fit the two plastic supports provided into the two holes on top of the canopy as illustrated in Fig. - Page 20 55 - 77 High Street - Slough BERKSHIRE SL1 1DZ © Electrolux Household Appliances Limited 2001...
