Contents Safety warnings ............... 33 For kitchen unit installer ............33 Description of the appliance ..........34 Mounting of grease filters ............34 Function ..................34 Extractor version ............... 34 Filter version ................34 Using the hood ................35 Control devices for the grease filter and carbon filter ... 35 Grease filter saturation led ............ -
Page 3: Safety Warnings
Safety warnings For kitchen unit installer • If the hood is used in its filtering function, it Attention: The air outlet must not be connected will operate simply and safely in the above to chimney flues or combustion gas ducts. The conditions without the need for any of the air outlet must under no circumstances be aforementioned measures. -
Page 4: Description Of The Appliance
Description of the appliance Mounting of grease filters Attention! The grease filters are supplied not mounted and packed in order to avoid damages during transport of the hood. • Fit the pins of the filter on the slots of the grease filter housing, then use the handles of the filter to lock them. -
Page 5: Using The Hood
Using the hood The hood has one variable speed motor. For the Control devices for the grease best performance, we recommend using the low filter and carbon filter speeds in normal conditions and the high This hood has a device which warns you when speeds in particular cases of strong odour and to clean the grease filter or replace the carbon vapour concentration. -
Page 6: Maintenance
Maintenance The hood must always be disconnected from the mains power supply before beginning any maintenance work. Cleaning Warning • Warning: always disconnect the hood from • Failure to observe the instructions on clean- the mains power supply before cleaning it. ing the unit and changing the filters will Never insert pointed objects in the motor’s cause a fire hazard. -
Page 7: Carbon Filter
For this reason you should always use original Electrolux filters only, making sure they are replaced when necessary. Changing the light bulb • Disconnect the cooker hood from the main supply. -
Page 8: Technic Details
Technic Details Model EFC 009.1 Dimensions height 752-930 mm width 1000 mm depth 700 mm Lighting 4 x 20 W Grease filter max absorbed power 240 W We reserve the right to generate constructive and chromatic modifications as required by technological growth. -
Page 9: Mounting Of Hood
Installation Standard accessories included: • Screws for mounting • Drilling scheme • No return valve (mounted on air outlet) RIGHT SIDE FRONT SIDE Mounting of hood LEFT SIDE REAR SIDE First set the telescopic support structure on the right direction and drill as indicated on the drilling scheme supplied with the hood. -
Page 10: For Both Versions
• From the bottom of the telescopic supporting structure fit the connection ring supplied (bajonett attachment- turn clockwise and fix definitively with one screw 2,9x9,5). (Fig. 10). • Fit a section of pipe or flex tube Ø 150 mm sufficiently long to reach the connection ring of the hood once this hood will be fit on place (Fig. - Page 11 • Fit the glass part on top of the hood • Fit temporarily the hood on the supporting structure by means of the already mentioned pins with nuts to be inserted on the proper holes located on the lower side of the sup- porting structure.
