ISA/PCI Motherboard with Onboard AGP
VGA PCI Audio, PCI IDE and Super
Multi-I/O
TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 6.0
September 17, 1999
Advertisement
Related Manuals for EPOX MVP4G
Summary of Contents for EPOX MVP4G
- Page 1 ISA/PCI Motherboard with Onboard AGP VGA PCI Audio, PCI IDE and Super Multi-I/O TRADEMARK All products and company names are trademarks or registered trademarks of their respective holders. These specifications are subject to change without notice. Manual Revision 6.0 September 17, 1999...
- Page 2 Supports (1) 16 bit ISA slots, (4) 32 bit PCI slots, (1)AMR and provides (2) independent high performance PCI IDE interfaces capable of supporting PIO Mode 3/4 and Ultra DMA 33/66 devices. The MVP4G supports (2) PCI Bus Master slots and a jumperless PCI INT# control scheme which reduces configuration confusion when plugging in PCI card(s).
- Page 3 Features MVP4G • Resume by Alarm - Allows your system to turn on at a preselected time. • Supports CPU Hardware sleep and SMM (System Management Mode). • Supports Keyboard power ON function (KBPO). • Supports USDM software to offer motherboard various status.
- Page 4 Installation MVP4G MVP4G Detailed Layout S O C K E T 7 Figure 1 Page 4...
-
Page 5: Installation
MVP4G Installation The following must be completed before powering on your new system: Configure Jumpers to match your hardware Install memory chips Device Connectors We design this motherboard with the fewest jumpers to make your install fast and easy. The following will describe all of the jumpers that you are required to set before moving on to step 2. - Page 6 Installation MVP4G SW1: CPU Vcore Selection S W 1 C P U 3 4 5 V c o re 1 .8 V 2 .0 V 2 .1 V 2 .2 V 2 .3 V 2 .4 V 2 .8 V 2 .9 V...
- Page 7 MVP4G Installation The MVP4G supports (3) 168-pin DIMMs (Dual In-line Memory Module). The DIMMs can be either EDO (Extended Data Out) or SDRAM (Synchronized DRAM). The DIMMs may be installed using just one chip. • We recommend using SDRAM DIMM can not mixing with EDO DIMM modules.
- Page 8 Installation MVP4G Please install the motherboard into the chassis. Now that your motherboard is installed you are ready to connect all your connections (figure 6). parallel port Joystick/Midi port PS/2 Mouse USB port PS/2 KEYBOARD COM1 VGA1 Speaker Line_in Figure 6 CPU Fan Power •...
- Page 9 MVP4G Installation Reset - Closed to restart system. Speaker - Connect to the system's speaker for beeping 1. Speaker 3. GND 2. N/C 4. GND Power LED connector 1. Power LED(+) 4. NC 2. N/C 5. GND 3. GND IR Connector 1.
