System Start Up

Default Video Output
The default video output for the DVR system is VGA. If you connect a
BNC (CVBS) monitor on initial setup, you will need to use the mouse
"Scroll Wheel" to switch to the BNC output to be able to use the
mouse. Roll the mouse "Scroll Wheel" backward to go to BNC and
forward to go to VGA. The REMARK screen is shown on startup.

Power On/Off

To power the system On/Off, connect the power
cable to the DC 12V port on the rear panel. Flip
the toggle switch on in the back of the DVR. At
startup, the system performs a basic system
check and runs an initial loading sequence.
After a few moments, the system loads a live
display view.
Standby Mode
The system can also be put into Standby Mode. Power will remain to the
system but will not be recording. To start/stop Standby Mode:
1. Press and hold the POWER button on the front panel or remote control
until the prompt closes. The system enters standby mode.
2. To exit standby mode, press and hold the POWER button on the front
panel or remote control until the system beeps. The system will begin
powering up.
User Login
Password
ATTENTION: By default, passwords are disabled on the system. You do not
need to enter a password when accessing any system menus. However, for
security purposes, it is highly recommended to enable passwords on the
system using the Password Menu. See "Password" section for details on
setting up passwords. Click APPLY to proceed to the MAIN MENU.
INITIAL SETUP
SYSTEM OPERATION
Power Switch
Page 13
Switch between VGA to BNC Output
Standby Mode
User Login Menu
