Summary of Contents for First Alert PRO-DC8810-520
- Page 1 BRK Series H.264 Digital DVR quick install guide MODELS PRO-DC8810-520 8 Channel/8 Cameras PRO-DC8410-520 8 Channel/4 Cameras H.264 VIDEO DIGITAL DVR MOBILE PHONE/ DVR OPTIMIZED INDOOR/OUTDOOR NIGHT SATA HDD COMPRESSION RECORDER WEB READY 520 TVL CAMERAS VISION...
-
Page 2: Product Overview
BRK Brands, Inc. is a subsidiary of Jarden Corporation (NYSE: JAH). First Alert® is a registered trademark of the First Alert Trust. To obtain warranty service, contact the Consumer Affairs Division at 1-800-323-9005, Monday through Friday, 7:30 a.m. -
Page 3: Dvr Controls
About this Quick Start Guide Thank you for choosing First Alert for your security needs! This Quick Start Guide is designed to provide you with the basic operation of your PRO-D810 DVR which is included in the PRO-DC8810-520 and the PRO-DC8410-520 security kits. Please consult the complete User’s Manual included on the CD disk for a detailed explanation of all the features and functions of... -
Page 4: Back Panel
product overview dvr controls back Panel Item Function Description POWER Input DC 12V/5A power connection Network For connecting RJ45 ethernet cable to PC or router VGA Output For connecting to a VGA monitor Video Ouput For connecting to a BNC monitor (800 x 600) Alarm Input 8 alarm inputs Alarm Output... -
Page 5: Remote Control
product overview DVR controls remote control Remote Control Operation The remote control is the secondary input device for navigating the system’s interface. In device operation, the OK key has the same function as “left click” of the mouse. Item Function Description STANDBY Press to turn standby mode ON/OFF... -
Page 6: Initial Setup
Longer Cable Runs Camera Orientation Longer cable runs may require an upgrade to RG59 Coax cable. First Alert kits ship It’s important the camera is with economical AV cable that is designed to work well up to the length of cable mounted correctly to ensure the provided, usually around 60 feet. -
Page 7: System Operation
initial setup system operation Step 3 ... system start up Power On/Off To power the system On/Off, connect the power cable to the DC 12V port on the rear panel. Flip the toggle switch on in the back of the DVR. At startup, the system performs a basic system check and runs an initial loading sequence. - Page 8 initial setup system operation Step 4 ... language, date and time Setting Up Language/Date/Time Set the system language, date and time, passwords, and configure audio and dis- play options. The Basic Setup Menu contains the following sub-menus: Language, Date/Time, Password, Display, and Video/Audio. Language To change the system language:, from the drop-down menu select LANGUAGE.
- Page 9 initial setup system operation Step 5 ... camera display setup Setting Up Cameras for Viewing and Recording Use the Display Setup menu to customize channel titles, show/hide the date and time in live viewing and playback, and enable/ disable preview channels. To customize Display settings, click BASIC from the Main Menu, then click DISPLAY: Display Configure the following options: •...
-
Page 10: Basic Operation
initial setup Basic operation Basic Setup Use the BASIC SETUP menu to configure language, date and time settings, password setup, along with display, video and audio settings. You can also exit the system through this menu. The Basic Setup menu contains the following sub-menus: Language, Date/Time, Password, Display, Video/Audio and Exit. -
Page 11: Playback Mode
initial setup Basic operation Motion Detect Setup You can configure motion detection for each channel (Camera) connected to the DVR. To configure motion detection: From the Main Menu click ADVANCED. Then click MD (Motion Detect). Under STATUS, select ON to enable motion detection for the desired chan- nel. - Page 12 BRK Brands, Inc. ©2012 a Jarden Corporation Company (NYSE:JAH) 3901 Liberty Street Road, Aurora, IL 60504-8122 Phone: 630-851-7330 Tech Services: 800-323-9005 www.brkelectronics.com M08-0387-004r7-2012...
