- Page 1 PIANI COTTURA ISTRUZIONI PER L’USO TABLES DE CUISSON NOTICE D’EMPLOI ENCIMERAS INSTRUCCIONES PARA EL USO HOBS USER INSTRUCTIONS PLACAS DE INSTRUÇÕES DE UTILIZAÇÃO...
- Page 2 Tab. 1 BUILT IN HOBS Burners/hotplates 4 gas 4 gas 3 gas 4 gas 5 gas 5 gas 5 gas 4 gas 4 gas 1 electric 1 electric 1 electric Type / reference Flame failure device - / yes - / yes - / yes - / yes - / yes...
- Page 3 UR - DC BIST.
-
Page 4: Instructions For The Installer
INSTRUCTIONS FOR THE INSTALLER INSTALLATION The Purchaser is responsible for the installation of the hob. The Manufacturer does not accept any responsibility for any damage or loss resulting from incorrect installation, and as such this will not covered by the Manufacturer’s Guarantee. The hob may be installed in any worktop which is heat resistant to a temperature of 100°... - Page 5 If a hob of 60 cm is fitted above an oven which is not equipped with fan cooling system it is recommended that openings are created within the built in furniture to ensure cor- rect air circulation. The size of these openings must be at least 300 cm and placed as shown in fig.
-
Page 6: Electrical Connection
ELECTRICAL CONNECTION (FOR U.K. ONLY) Warning - this appliance must be earthed This appliance is designed for domestic use only. Connection to the mains supply must be made by a competant electrician, ensuring that all current regulations concerning such installations are observed. The appliance must only be connected to a suitably rated spur point, a 3 pin 13 amp plug/socket is not suitable. - Page 7 ELECTRICAL CONNECTION Check the data on the rating plate, located on the outside of the unit, to ensure that the supply and input voltage are suitable. Before connection, check the earthing system. By Law, this appliance must be earthed. If this regulation is not complied with, the Manufacturer will not be responsible for any damage caused to persons or property.
-
Page 8: Adapting The Hob To Different Types Of Gas
To prevent any potential damage to the hob please carry out the installation following this sequence: 1/2 GAS CONICAL A) As illustrated, as- 2) Tighten the joints 3) Attach fitting C to semble parts in se- with the Spanners, mains gas supply us- quence: remembering to twist ing rigid copper pipe... -
Page 9: Regulating The Minimum Flame
X dimension according Table of gas consumption 1W = 0,860 kcal/h to Gas type G20 20mbar G20/G25 G30 29mbar 25mbar G31 37mbar Working reg. reg. Ø gas jet Ø gas jet STD. Dim min.Dim reg. reg. burner 1/100 mm 1/100 mm large 2,65 0,65... -
Page 10: Using The Gas Burner
When you have carried out the new gas regulation, replace the old gas rating pla- te on your appliance with one (supplied with hob) suitable for the type of gas for which it has been regulated. USE OF HOB USER INSTRUCTIONS This appliance must only be used for the purpose for which it is intended, domestic cooking, and any other use will be considered improper and could therefore be danger- ous. - Page 11 If over the years the gas taps become stiff to turn it is necessary to lubricate them. Such operation must be carried out only by qualified Service Engineers. Some model are equipped with a small steak griddle. This is only to be used over the medium size burner SEMIRAPID.
- Page 12 HOW TO USE THE GRIDDLE (see fig. G) The griddle must be placed over Correct position of griddle the central burner; the correct position as shown in fig. 12 is ar- chived by correct locking over the pan support. The griddle has been designed for cooking of foodtuffs, do not place pans, kettles or pots on the griddle.
-
Page 13: Maintenance And Cleaning
USE OF ELECTRIC HOTPLATES OR CERAMIC ELEMENTS. For the best use of the electric hotplates and to minimise energy consumption, the fol- lowing recommendations should be noted. No. setting ce- No. setting food stuff power setting ramic element rapid hotplate VERY LOW Warming dishes &... - Page 14 Never use abrasives, corrosive detergents, bleaching agents or acids. Avoid any acid or alkaline substances (lemon, juice, vinegar etc.) on the enamelled, varnisched or stain- less steel sections. The burners can be cleaned with soapy water. To restore their original shine, use a household stainless steel cleaner.
