READ AND SAVE THESE INSTRUCTIONS
Emerson Fans
Designed by
CASTILLA
Ceiling Fan Owner's Manual
Model Numbers
KF120TZ00
KF120SCK00
Tannery Bronze
¨
with
¨
Seine Crackle
with
Teak/Mahogany Blades
Walnut/Mahogany Blades
Net Weight:
30.0
Lbs.
Part No. F40BP72810000
Form No. BP7281
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Emerson CASTILLA KF120SCK00
Summary of Contents for Emerson CASTILLA KF120SCK00
- Page 1 Emerson Castilla 1/24/05 8:18 AM Page 1 READ AND SAVE THESE INSTRUCTIONS Emerson Fans Designed by CASTILLA Ceiling Fan Owner's Manual Model Numbers KF120TZ00 KF120SCK00 Tannery Bronze ¨ with ¨ Seine Crackle with Teak/Mahogany Blades Walnut/Mahogany Blades Net Weight: 30.0 Lbs.
-
Page 2: Safety Instructions
Emerson Castilla 1/24/05 8:18 AM Page 2 WARNING WARNING: To avoid fire, shock, and serious personal injury, follow these instructions. Safety Instructions 1. Read your owner’s manual carefully and keep it for future reference. 2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting means to prevent power from being switched on accidentally. -
Page 3: Unpacking Instructions
Emerson Castilla 1/24/05 8:18 AM Page 3 This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly 1. Open styrofoam unit containing fan. Remove top half of styrofoam unit. One Phillips head screwdriver Remove parts and check to see that One wire stripper... -
Page 4: Remote Control Procedures
Emerson Castilla 1/24/05 8:18 AM Page 4 2. Remove the fan motor and housing Preset Memory Feature assembly from the protective plastic Your remote control receiver is equipped bag. Place the fan assembly into the with a preset memory feature. The receiv- upper foam pad with the top of the er will remember the light intensity and fan motor facing up. -
Page 5: Electrical Requirements
Emerson Castilla 1/24/05 8:18 AM Page 5 2. Slide the four switch levers on the code WARNING switch to your choice of ON (up) or down positions. Use a ball-point pen or Turning off wall switch is not suffi- cient. To avoid possible electrical small screwdriver and slide the levers shock, be sure electricity is turned off firmly up or down. - Page 6 Emerson Castilla 1/24/05 8:18 AM Page 6 and align the hanger ball so the pin is WARNING captured in the groove in the top of the It is critical that the clevis pin in the hanger ball. Pull the hanger ball up tight motor coupling is properly installed against the pin and securely tighten the and the setscrew securely tightened.
- Page 7 Emerson Castilla 1/24/05 8:18 AM Page 7 8. Turn the fan motor and housing assem- 12. Connect the white wire from the light bly upside down in preparation for fitter to the white wire from the switch mounting the fan blade assemblies. housing (Figure 8).
-
Page 8: Your Ceiling Fan How To Hang
Emerson Castilla 1/24/05 8:18 AM Page 8 16. You have now completed the assem- WARNING bly of your new ceiling fan. You can now proceed with hanging and wiring Hanger bracket must seat firmly your fan. against outlet box. If the outlet box is recessed, remove wall board until bracket contacts box. -
Page 9: How To Wire Your Ceiling Fan
Emerson Castilla 1/24/05 8:18 AM Page 9 How to Wire is visible at the wire connectors, except for the ground wire. Your Ceiling Fan 2. Refer to Figure 14 and 15 and connect If you feel that you do not have enough the receiver wires to the supply wires electrical wiring knowledge or experi- and the fan motor wires as follows:... - Page 10 Emerson Castilla 1/24/05 8:18 AM Page 10 STANDARD ON-OFF WALL SWITCH OR OPTIONAL SW113 WALL CONTROL BLACK BLACK (HOT) BLACK 120- VOLT WHITE SUPPLY WHITE WHITE GROUND BLACK TWO-CONDUCTOR BLUE WHITE CABLE (WITH GROUND) BLACK GREEN WIRE (GROUND) BLUE FROM HANGER BALL AND WHITE HANGER BRACKET Figure 15...
-
Page 11: Operating Your Ceiling Fan
Emerson Castilla 1/24/05 8:18 AM Page 11 8. Your ceiling fan is now installed and Installation of wired to be controlled by your remote Storage Bracket control system. A storage bracket is supplied with the remote control for holding the transmitter Operating Your when not in use. -
Page 12: Maintenance
Emerson Castilla 1/24/05 8:18 AM Page 12 Maintenance Accessories IMPORTANT CARE INSTRUCTIONS 1. Downrod Extension Kits (see store or for your Ceiling Fan catalog). 2. Ceiling Fan Controls (see store or cat- Periodic cleaning of your new ceiling fan is alog). -
Page 13: Troubleshooting
Emerson Castilla 1/24/05 8:18 AM Page 13 WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. Trouble Shooting TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not 1. Fuse or circuit breaker 1. -
Page 14: Repair Parts
Emerson Castilla 1/24/05 8:18 AM Page 14 Repair Parts FAN/OFF FOR/REV LIGHT DIMMER ®... -
Page 15: How To Order Repair Parts
Emerson Castilla 1/24/05 8:18 AM Page 15 Repair Parts Listing Part Numbers Model No. Model No. Description KF120SCK00 KF120TZ00 Hanger Pack, Consisting of: 761655-31 761655-33 Hanger Bracket — — Hanger Ball — — Downrod — — Parts Bag, Containing: 762656... -
Page 16: Limited Warranty
Emerson Castilla 1/24/05 8:18 AM Page 16 LIMITED WARRANTY What The Warranty Covers: This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials. You must be the original purchaser or user of the product to be covered. What The Period Of Coverage Is: As it applies to the motor, this warranty will last for thirty years from the date you purchased your ceiling fan.
