READ AND SAVE THESE INSTRUCTIONS
Emerson Fans
Designed by
STURBRIDGE
Ceiling Fan Owner's Manual
Model Numbers
KF180OZ01
KF180AP01
Antique Pewter with Natural
Olde Bronze
¨
with
Cherry/Mahogany Blades
Teak/Natural Pine Blades
KF180DBK01
Distressed Black with Distressed
Black/Natural Cherry Blades
Net Weight:
30.9
Lbs.
Part No. F40BP72840003
Form No. BP7284-3
U.L. Model No.: KF180

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KF180 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emerson KF180

Summary of Contents for Emerson KF180

  • Page 1 Ceiling Fan Owner's Manual Model Numbers KF180OZ01 KF180AP01 Antique Pewter with Natural Olde Bronze ¨ with Cherry/Mahogany Blades Teak/Natural Pine Blades KF180DBK01 Distressed Black with Distressed Black/Natural Cherry Blades Net Weight: 30.9 Lbs. Part No. F40BP72840003 Form No. BP7284-3 U.L. Model No.: KF180...
  • Page 2 DATE CODE: The date code of this fan may be found on the box, stamped in ink on a white label. You should record this data above and keep it in a safe place for future use.

  • Page 3: Unpacking Instructions

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. 10:52 AM Page 3 1.

  • Page 4: Remote Control Procedures

    The lower foam pad serves as a holder for the fan during the first stages of assembly. General Your Emerson ceiling fan comes equipped with a remote control transmitter and a remote control receiver. This remote con- trol systems is designed to control your ceiling fan speed and light intensity.

  • Page 5: Electrical Requirements

    BP7284, Sturbrige, KF180 7/31/06 2. Slide the four switch levers on the code switch to your choice of ON (up) or down positions. Use a ball-point pen or small screwdriver and slide the levers firmly up or down. 3. In the receiver (Figure 1), slide the four switch levers to the same positions as set in the transmitter.
  • Page 6 BP7284, Sturbrige, KF180 7/31/06 WARNING It is critical that the clevis pin in the motor coupling is properly installed and the setscrews securely tight- ened. Failure to verify that the pin and setscrews are properly installed (as shown in Figure 3) could result in the fan falling.
  • Page 7 BP7284, Sturbrige, KF180 7/31/06 8. Turn the fan motor and housing assem- bly upside down in preparation for mounting the fan blade assemblies. Remove and discard the three shipping retainers securing the motor hub in the motor housing. NOTE: Take care not to scratch the fan housing when installing the blade assemblies.

  • Page 8: How To Hang Your Ceiling Fan

    BP7284, Sturbrige, KF180 7/31/06 How to Hang Your Ceiling Fan WARNING The fan must be hung with at least 7' of clearance from floor to blades (Figure 9). CEILING AT LEAST FLOOR Figure 9 WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs.

  • Page 9: How To Wire Your Ceiling Fan

    BP7284, Sturbrige, KF180 7/31/06 How to Wire Your Ceiling Fan If you feel that you do not have enough electrical wiring knowledge or experi- ence, have your fan installed by a licensed electrician. WARNING Turning off wall switch is not suffi- cient.
  • Page 10 BP7284, Sturbrige, KF180 7/31/06 STANDARD ON-OFF WALL SWITCH OR OPTIONAL SW101 WALL CONTROL BLACK (HOT) 120- VOLT SUPPLY WHITE GROUND TWO-CONDUCTOR CABLE (WITH GROUND) GREEN WIRE (GROUND) FROM HANGER BALL AND HANGER BRACKET Figure 13 3. Push the wires and connectors up into the outlet box while inserting the receiv- er fully into the hanger bracket.

  • Page 11: Operating Your Ceiling Fan

    BP7284, Sturbrige, KF180 7/31/06 9. Grasp the lower ring assembly and raise it up and over the ring rods of the adapter assemlby (Figure 16). Position the ring assembly of that the ring assembly arms protrude through the holes at the end of the ring rods.

  • Page 12: Maintenance

    This product is designed to use only those parts supplied with this prod- uct and/or any accessories designat- ed specifically for use with this product by Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co.

  • Page 13: Troubleshooting

    BP7284, Sturbrige, KF180 7/31/06 WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. Trouble Shooting TROUBLE PROBABLE CAUSE 1. Fan will not 1. Fuse or circuit breaker start. blown. 2. Loose power line...

  • Page 14: Repair Parts

    BP7284, Sturbrige, KF180 7/31/06 Repair Parts 10:52 AM Page 14...

  • Page 15: How To Order Repair Parts

    • PART NUMBER • NAME OF ITEM • PART DESCRIPTION • MODEL NUMBER The model number of your Fan will be found on a label attached to the top housing. For repair parts, phone 1-800-654-3545. 10:52 AM Page 15 Part Numbers Model No.

  • Page 16: Limited Warranty

    You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
