WAN Configuration

There are three types of WAN connection that you can use
• Static IP, to specify the IP address manually. Mostly used when you connect the V2xx ATA to a broadband router with out a DHCP
server.
• Dynamic IP, to connect to a service which has a DHCP server on the network. Mostly used when using the V2xx ATA with an Optus
cable modem or connecting the V2xx ATA to another router / gateway.
• PPPoE Client, to connect to a network with PPPoE service. Mostly used to connect the V2xx ATA to a bridge ADSL modem.
Static IP Configuration
1. Click on WAN on the left menu.
2. Change the IP Type to DHCP.
3. Enter the required information, IP Address, Subnet Mask, Gateway, DNS Server1, DNS Server2 and Host Name in the respective
fields.
4. After that, click the Submit button.
Option Description
Configures the VoIP Gateway as a router or bridge.
LAN Mode
IP Type Fixed IP address allows the user to manually assign an IP address. DHCP mode allows the VoIP Gateway to automatically obtain an IP address from
a DHCP enabled server on your network. PPPoE allows the VoIP Gateway to use a PPPoE connection. In this mode, enter the PPPoE Username and
Password in the fields under PPPoE settings.
IP The unique address of the VoIP Gateway on your network.
The subnet mask of your network.
Mask
Gateway The default gateway address through which the VoIP Gateway communicates with the Internet. This is usually your modem / router.
DNS Server 1 The Domain Name Service that the NetComm ATA uses to resolve domain names to IP addresses. This is usually your modem / Router or the primary
DNS server specified by your Internet Service Provider (ISP).
DNS Server 2 The Domain Name Service that the NetComm ATA uses to resolve domain names to IP addresses. This is usually your modem / router. DNS 2 can be a
different address to DNS 1 to provide a backup DNS server if DNS 1 fails.
MAC The Ethernet MAC address of the WAN interface.
Host Name The host name of the VoIP Gateway (Optional)
5. Click on Save Settings/Reboot on the left menu and then click the Save & Reboot button to save
your settings.
6. The NetComm ATA will reboot automatically to make your changes effective. Please wait while it reboots.
