ALCATEL T60
ATLINKS Europe, 22 quai Gallieni 92150 Surensnes - France
Alcatel Logo and Alcatel name are trademarks of Alcatel Lucent and used under license by Atlinks.
I
NTRODUCTION
provided by your local telephone company, to subscribers of
Your Caller ID phone enables you to:
Identify callers before you answer the phone.
View the time and date of each incoming call.
Record up to 58 Caller ID name and number messages
sequentially.
M
F
AIN
EATURES
FSK/DTMF auto detect.
Alphanumerical backlight display.
6 languages interface selection.
Record up to 58 incoming caller names and numbers.
Record up to 10 recent dialed numbers.
10 two-touch memories.
4 one-touch memories.
Pulse or Tone dialing mode.
Flash timing selectable.
Mute function.
Speakerphone.
To get the most from your new phone, please read through this
user's guide.
SHORT GLOSSARY OF TERMINOLOGY USED IN
THIS MANUAL
Hook switch. The part of the phone that pops up to activate the
phone line when the handset is lifted from the base.
Off-hook. The phone is in active mode when the handset is off
the base cradle or the SPEAKER feature is on.
On-hook. The phone is in standby mode when the handset is on
the base cradle.
P
C
ARTS
HECKLIST
Your package includes the following items:
ALCATEL T60
Alcatel Logo and Alcatel name are trademarks of Alcatel Lucent and used under license by Atlinks.
ATLINKS Europe, 22 quai Gallieni 92150 Surensnes - France
User's Guide
Base
Handset
Coiled cord
Line cord
NOTE: If there is any item missing in the package, please
contact the shop where you bought this product.

TELEPHONE JACK REQUIREMENTS

To use this phone, you need a RJ11C type modular telephone jack,
(similar to the one pictured here) installed in your home. Call your
local phone company to have one installed.
Wall plate
Modular telephone line jack
I
NSTALLATION
CAUTION: Disconnect the phone cord from the wall
outlet before installing or replacing the batteries.
Never install telephone wiring during a lightning storm.
Never touch un-insulated telephone wires or terminals, unless
the telephone line has been disconnected at the network
interface.
Install or modify telephone lines with caution.
Never install telephone to operate in wet or damp locations.

INSTALLING AND REPLACING THE BATTERIES

Your Caller ID phone uses 3 AA-Size alkaline batteries for receiving
and storing Caller ID records and storing the number.
IMPORTANT: If you are not going to use the telephone
for more than 30 days, remove the batteries.

BATTERY

1. If the telephone line cord is connected, disconnect it from the
base unit.
2. Carefully turn the phone over, use a pen or paper clip to loosen
the battery cover. Open the battery compartment by pushing
on the battery cover and sliding it away from the unit.
3. Insert 3 AA-size alkaline batteries (not included) as shown on
the engraving in the battery
compartment.
4. Snap the battery compartment
door back into place.
5. Reconnect the telephone
line cord to the base.

INSTALLING THE PHONE

Your phone should be placed on a level surface, such as a desk or
table top, or you can mount it on a wall.
1. Connect the handset.
2. Connect the telephone
line.
W
M
ALL
OUNTING
1. Rotate the wall mounting knob as shown below:
Wall mounting
knob Location
Rotate 180°
WALL MOUNTING: The knob is designed
to keep this unit in place when the
telephone is vertically placed on the wall.
2. Install the base unit to the wall and then plug one end of line
cord into the base and the other end into the modular telephone
line jack.
3. Fix the telephone on the wall as shown below.
O
M
PTIONS
ENU
Low battery indicator
Morning
Voice mail
Speakerphone
Afternoon
Month
Day Hour
Minutes
Mute Mic Repeat New CID Call-log
Phone
Name display
number display
Ringer Volume Switch
Display
Down button
Up button
Menu button
Dial back button
Delete button
Mute button
Store button
Flash button
M1 button
M4 button
M2 button
M3 button
Redial/Pause button
Speaker button
Speaker Volume button
Microphone
S
P
ETTING THE
HONE
NOTE: Program the following settings before using the
phone.
There are 6 options to set:
Date format
Time format
English/French/Spanish/
Turkish/Polish/Greece

SETTING DATE/TIME

OR

SETTING LOCAL AREA CODE

OR
Number
The area code prior to an incoming number will be removed from
the caller ID display if it matches with the area code you set.

SETTING LONG DIST CODE

OR

SETTING LANGUAGE

OR
SETTING FLASH TIME
OR
SETTING TONE/PULSE
OR
OR
Enter Month, Day,
Hour and Minute
Enter your area code
Enter your long
distance code
OR
Select Language
100/300/1000/600
OR
Select timing
OR
Select Tone or Pulse
