- Page 1 VOIP-211RS/210RS/220RS/440S SIP VoIP Router User’s Guide...
- Page 2 Trademarks Contents are subject to revise without prior notice. All trademarks belong to their respective owners. FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Table Of Contents
INDEX 1. Home…………………………………………………… 2. WAN………………………………………….………… WAN Status………………………………………………….……………… WAN Configuration………………………………………………………… WAN PPPoE Configuration……………………………………………… IPSec Configuration………………………………………………………. WAN VLAN Configuration……………………………………………… MAC Spoofing Configuration…………………………………………… 3. LAN……………………………………………………. LAN Configuration……………………………………………………….. DHCP Server Configuration……………………………………………… Router Configuration……………………………………………………… Port Forwarding Configuration………………………………………….. LAN VLAN Configuration……………………………………………….. 4. SIP……………………………………………………… SIP Configuration…………………………………………………………. SIP Extensions……………………………………………………………... RTP Telephone Event Configuration…………………………………….. - Page 4 7. Download……………………………………………… 8. Reset …………………………………………………... Appendix ………………………………………………... Sample Dial Plans…………………………………………………………...
-
Page 5: Home
Home System Uptime: specifies the amount of time, which the system has been up. This time is reset every time the system is reset. LAN IP Address: indicates the IP Address of your LAN. MAC address: MAC address is the address of your MAC. Security: for your password, which is configured in the “System”... -
Page 6: Wan
WAN status Interface Status: these are the details of your interface’s status. Enabled: “Yes”, lets you know that your interface is enabled and ready to be used. Service: either “Routed or Bridged”, tells you the level of your interface’s connection. Protocol: refers to how you are transmitting data. - Page 7 Dynamic IP Assignment: “Yes” or “No”, depending on whether or not you are using a dynamic IP. IP address: your specified IP. MAC address: Your specified MAC address. Subnet Mask: indicates the IP address of your mask. Default Gateway: is the IP address of the gateway. The gateway IP could be retrieved from DHCP offer in DHCP mode, or be set up manually in fixed IP mode.
-
Page 8: Wan Configuration
WAN Configuration 1. Device Operating Mode: you choose either “Router” or “Bridged” depending on your operation. 2. You will check either “Obtain WAN configuration dynamically” or “Specify fixed WAN configuration”. When you choose “Obtain WAN configuration dynamically”, the information is detected automatically through DHCP. If you choose “Specify fixed WAN configuration”, you are required to enter the IP address, IP of the Sub mask, IP of the Gateway, and IP of the DNS Server, if applicable. - Page 9 Multicast Limit: the value specifies the maximum limit on the percentage of multicast packets which will be bridged to the destination interface (as a percentage of the source side bandwidth)
-
Page 10: Wan Pppoe Configuration
WAN PPPoE Configuration 1. Enable PPPoE: “Yes” or “No”, to enable/disable PPPoE 2. Under “Authentication”, you enter the username and password given by your ISP. 3. Settings: Idle Timeout: Idle timeout before PPP connection is closed due to inactivity Echo Timeout: the duration between PPP echo requests sending to server. Echo Count: the number of unanswered PPP echo requests before PPP connection is closed. -
Page 11: Ipsec Configuration
IPSec Configuration This page allows configuration of the device’s IPSec (IP Security) settings. Enable tunnel 1: Enable/disable tunnel 1 IP sec Remote IP Address range: start and end of remote IP address range. Remote security gateway: Remote security gateway IP address Security Mode: IPSec mode (tunneling/transport) Outbound AH SPI (DEC): Outbound AH security parameter index number. - Page 12 Inbound AH Authentication Key (HEX): hex number up to 40 nibbles Inbound ESP SPI (DEC): Inbound ESP security parameter index number Inbound ESP Encryption Algorithm: 3DES-CBC or DES-CBC Inbound ESP Authentication Algorithm: in HMAC-MD5 or HMAC-SHA1 Inbound ESP Encryption Key (HEX): hex number up to 48 nibbles Inbound ESP Authentication Key (HEX): hex number up to 40 nibbles...
-
Page 13: Wan Vlan Configuration
WAN VLAN Configuration WAN VLAN Tag: VLAN tag for all outgoing packets on interface. The value should be between 0 and 4094 WAN Priority Tag: Priority tag for all outgoing packets on interface. The value should be between 0 and 7... -
Page 14: Mac Spoofing Configuration
MAC Spoofing Configuration WAN MAC Address (Spoofed): Only available when devices under the router mode. The spoofed MAC address to be used by the device’s WAN interfaces, the Ethernet address of the outgoing packets from the WAN interface would be replaced with this address. -
Page 15: Lan
LAN Configuration 1. Under “Network Settings”, you enter the IP address and subnet mask of your network. 2. Multicast Limits: Broadcast Limit: the value specifies the maximum limit on the percentage of broadcast packets which will be bridged to the destination interface (as a percentage of the source side bandwidth) Multicast Limit: the value specifies the maximum limit on the percentage of multicast packets which will be bridged to the destination... -
Page 16: Dhcp Server Configuration
DHCP Server Configuration These configuration parameters are for the device’s internal DHCP server. 1. Server Setting: “Yes” or “No”, to enable/disable DHCP Client IP Address Range: Minimum and Maximum limit on the DHCP IP address pool 2. Client Network Information Domain Name: LAN domain name provided to DHCP clients during the OFFER process. -
Page 17: Router Configuration
Router Configuration These configuration parameters are for the device’s internal router. 1. Dynamic Routing: Whether or not dynamic routing on TX/RX interfaces is enabled/disabled. 2. Static Routing Under “Static Routing”, you can specify your routing path of your internal network. -
Page 18: Port Forwarding Configuration
Port Forwarding Configuration 1. Under “Reserved Ports”, specified are the ports, which cannot be forwarded to the LAN. 2. Under “Port Forwarding to LAN”, you enter the specifications, which you will be forwarding to the lan, including port range, protocol(Both, TCP or UDP), and destination IP address. -
Page 19: Lan Vlan Configuration
LAN VLAN Configuration LAN VLAN Tag: VLAN tag for all outgoing packets on interface. The value should be between 0 and 4094 LAN Priority Tag: Priority tag for all outgoing packets on interface. The value should be between 0 and 7 Click on “Save VLAN Settings”, to save your configurations. -
Page 20: Sip
SIP Configuration 1. Under “SIP Server Settings”, you enter the server address, port, domain name, and expiration time unit, if you choose to send registration request with an expiration time. 2. Gateway Settings • Dial Plan: refer to appendix D of this guide •... -
Page 21: Sip Extensions
SIP Extensions Support PRACK method: enable SIP PRACK support. Encode SIP URI with user parameter: encode user=phone parameter in SIP URI. Send INVITE with Timer header: encode Timer header in all INVITE requests for ringing timeout SIP session timer: enable SIP session timer function. Conditional Call Forwarding Timer: Forward the call to the pre- configured number if the phone does not pick up within the timer. -
Page 22: Rtp Telephone Event Configuration
RTP Telephone Event Configuration This sub-page allows configuration of the out-of-band signaling options for SIP. Select whether OOB telephone event signaling is to be done using the SIP INFO message, or to be done via RFC2833 RTP signaling. For additional information please refer RFC2833. -
Page 23: Tos/Diffserv
ToS/DiffServ This sub-page is used to configure the Type-of-Service/Diffserv byte values which are to be used in the IP header of all transmitted SIP signaling packets and RTP packets. The ToS/DiffServ byte values are entered as two-digit hexadecimal values. If no special ToS/DiffServ value is to be used for a particular traffic type, enter “00”... -
Page 24: Voip Vlan Configuration
VoIP VLAN Configuration This sub-page allows configuration of specific VLAN tags that are to be applied to all SIP signaling and RTP packets used for VoIP calls. These VLAN settings will override any general VLAN settings applied to the interface Press "Save VoIP VLAN Settings"... -
Page 25: Codec
CODEC Audio/CODEC Configuration 1. CODECS: configure the silence suppression to your desired settings. 2. Packetization: configure the packet sending increments. 3. Jitter Buffer: configure the timing of the voice buffering. Selection between adaptive or fixed jitter buffer. Default = ADAPTIVE Set the adaptive jitter buffer maximum playout delay. -
Page 26: System
SYSTEM Set Security Password Configure a password for the system. -
Page 27: Localization
Localization Choose the correct country for a proper impedance match, as well as the NTP Server, and Time Zone. Check the “Adjust clock for daylight savings”, when applicable. Click on “Save Localization Settings”, to save your configurations. -
Page 28: Snmp Configuration
SNMP Configuration 1. SNMP Trap Configuration IP address: Trap host IP address Trap Community: The community name used by the SNMP manager to verify traps. The default value is ‘public’ 2. SNMP Community Configuration Read Community: The community name used by the SNMP manager when reading SNMP data items from a client MIB. -
Page 29: Service Access Configuration
Service Access Configuration Check the proper boxes enabling LAN and WAN for the HTTP, SNMP, and VoIP Discovery. Click on “Save Service Access Settings”, to save the configurations. -
Page 30: Download
Download For both HTTP and TFTP methods, the device will reboot itself into the downloader mode if the main application is executing, and proceed with the ROM file download and permanent write of the application to the device’s flash memory. After the download is completed, the download status page will be displayed. -
Page 31: Reset
Reset Chose the “Reset and execute Main Application” option, for execution of the main application which you have configure, once you reset the system. Chose the “Reset and execute Downloader Application” option, to being downloading, once you reset the system. -
Page 32: Appendix
Appendix. Dial Plans The H.323 and SIP code will allow provisioning (via web browser) of the dial plan. A dial plan gives the unit a map to determine when a complete number has been entered and should be passed to the gatekeeper for resolution into an IP address. Dial plans are expressed using the same syntax as used by MGCP NCS specification. -
Page 33: Sample Dial Plans
Sample Dial Plans Simple Dial Plan Allows dialing of 7 digit numbers (e.g. 5551234) or an operator on 0. Dial plan is (0T|xxxxxxx) Non-dialed Line Dial Plan As soon as handset is lifted the unit contacts the gatekeeper (used for systems where dtmf detection is done in-call).
