Summary of Contents for Chauvet BEAMSHOT

  • Page 1 User Manual...

  • Page 2: Table Of Contents

    Program Speed ............................12 Master/Slave Mode ..........................13 Custom Settings ............................14 Dimmer ..............................14 5. Technical Information ....................15 Product Maintenance ........................15 6. Technical Specifications ....................16 Returns ............................17 Contact Us ............................17 Page 2 of 17 BEAMshot™ User Manual (Rev. 1)

  • Page 3: Before You Begin

    Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with CHAUVET® within 7 days of delivery. Text Convention Meaning 1–512...

  • Page 4: Product At A Glance

    This product is not intended for permanent installation. · Keep this User Manual for future use. If you sell the product to another user, be sure to give this document to the next owner. Page 4 of 17 BEAMshot™ User Manual (Rev. 1)

  • Page 5: Introduction

    2. I NTRODUCTION Overview Power Out Menu Buttons Display DMX In Power In DMX Out Fuse Holder Back Panel View BEAMshot™ User Manual (Rev. 1) Page 5 of 17...

  • Page 6: Dimensions

    Dimensions Page 6 of 17 BEAMshot™ User Manual (Rev. 1)

  • Page 7: Setup

    3. S ETUP AC Power The BEAMshot™ has an auto-ranging power supply and it can work with an input voltage range of 100~240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart.

  • Page 8: Power Linking

    Diagram Additional Products You can power link up to 62 BEAMshot™ units on 120 VAC or up to 100 BEAMshot™ units on 230 VAC. The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET®...

  • Page 9: Mounting

    Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The BEAMshot™ may be mounted in any position; however, make sure adequate ventilation is provided around the product. · Rigging Before deciding on a location, always make sure there is easy access to the product for maintenance and programming.

  • Page 10: Operation

    Starting Address The BEAMshot™ has two DMX personalities. One is a 2-channel mode and the other is a 4-channel mode. The BEAMshot™ uses up to 4 DMX channels in its 4-channel DMX mode, which defines the highest configurable address to 509.

  • Page 11: Dmx Channel Modes, Assignments, And Values

    000 ó 255 Auto programs speed, slow to fast Speed Channel Function Value Setting 2-Channel 000 ó 255 0–100% White 000 ó 010 No function Shutter 011 ó 255 Strobe, slow to fast BEAMshot™ User Manual (Rev. 1) Page 11 of 17...

  • Page 12: Configuration (Standalone)

    To set the auto program speed, follow the instructions below: Press <MENU> repeatedly until S-- shows on the display. Use <UP> or <DOWN> to select the desired auto program speed (S 1–S100). Press <ENTER>. Page 12 of 17 BEAMshot™ User Manual (Rev. 1)

  • Page 13: Master/Slave Mode

    Master/Slave The Master/Slave mode allows a single BEAMshot™ unit (the “master”) to control the actions of one or more BEAMshot™ units (the “slaves”) without the need of a DMX Mode controller. The master unit will be set to operate in either Automatic or Sound-Active mode, while the slave units will be set to operate at DMX address d 1.

  • Page 14: Custom Settings

    Custom Settings The BEAMshot™ allows you to choose custom strobe and dimmer settings to achieve the effect you like. To select these custom settings, follow the instructions below: Press <MENU> repeatedly until U-- shows on the display. Press <ENTER> and S 0–S255 (strobe, slow to fast) shows on the display.

  • Page 15: Technical Information

    · Gently polish the external optics and glass/transparent surfaces until they are free of haze and lint. Always dry the external optics and glass/transparent surfaces carefully after cleaning them. BEAMshot™ User Manual (Rev. 1) Page 15 of 17...

  • Page 16: Technical Specifications

    Maximum External Temp. Cooling System 104° F (40° C) Convection I/O Connectors Connector Type Channel Range 3-pin XLR Sockets 2, 4 Ordering Product Name Item Code UPC Number BEAMshot™ 03050668 781462210168 Page 16 of 17 BEAMshot™ User Manual (Rev. 1)

  • Page 17: Returns

    You must send the merchandise prepaid, in its original box, and with its original packing and accessories. CHAUVET® will not issue call tags. Clearly label the package with the RMA number. CHAUVET® will refuse any product returned without an RMA number.
