  • Page 1 Snapshot OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Linking power USER MANUAL 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com...
  • Page 2: Table Of Contents

    General Maintenance ... 9 Returns Procedure ... 9 Claims ... 9 Technical Specifications ... 10 1. B EFORE What is included  1 x LXW  Power Cord  Warranty Card  User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition.
  • Page 3: Ac Power

    All fixtures must be connected to circuits with a suitable Earth Ground. Contact Us Wor l d Wi de General Information Technical Support World Wide Web LXW User Manual CHAUVET 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560...
  • Page 4: Safety Instructions

    Do not daisy chain power to more than 80 units @ 120V and 160 units @ 230V. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. 2. I NTRODUCTION Features...
  • Page 5: Product Overview

    Product Overview Bracket adjustment knob Safety eyebolt Mode selection switch Power in/fuse holder External ground screw LXW User Manual selection Microphone sensitivity adjustment Power link out Hanging bracket Voltage switch Sound 12/31/2008 4:21 PM...
  • Page 6: Fuse Replacement

    Safety cables must always be used. Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. LXW User Manual The fuse is located inside this compartment.
  • Page 7: Operating Instructions

    Use the audio sensitivity knob on the back of the unit to make the unit more or less sensitive in Sound-Active mode. Turning the knob counterclockwise decreases the sensitivity; turning the knob clockwise increases the sensitivity. LXW User Manual NSTRUCTIONS Constant rotation...
  • Page 8: General Troubleshooting

    No light output Check slip ring & brushes for contact Install bulb Call service technician If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location listed below. Technical Support Address: Service Dept.
  • Page 9: Appendix

    Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return.
  • Page 10: Technical Specifications

    Power Output ... 80 units max at 120V, 160 units max @ 230V LIGHT SOURCE LED ... 1x 750mA (1 White 8,500 K) 50,000hrs PHOTO OPTIC Beam Angle ... 39° THERMAL Maximum ambient temperature ...104°F (40°C) ORDERING INFORMATION LXW... LXW WARRANTY INFORMATION Warranty... 1-year limited warranty LXW User Manual 12/31/2008 4:21 PM...
