QuickSpecs

System Technical Specifications

System Board
System Board Form Factor ATX 27.69 x 24.38 mm (10.9 x 9.6 inches)
Processor Socket
CPU Bus Speed
Chipset
Memory Expansion Slots 4 DDR3 memory slots
Memory Type Supported
Memory Modes
Memory Speed Supported 1600MHz DDR3
Memory Protection
Maximum Memory
Memory Configuration
(Supported)
PCI Express Connectors
PCI Connectors (5.0V)
Supported Drive
Interfaces
Single LGA-1150
DMI
Intel® PCH C226
DDR3, UDIMM (Unbuffered), ECC& non-ECC
Non-Interleaved for single channel. Interleaved when both channels are populated.
ECC available on data
32GB
4GB and 8GB non-ECC/ 2GB, 4GB and 8GB ECC unbuffered DIMMs are supported.
ECC and non-ECC memory DIMMs cannot be mixed on the same system.
NOTE: Maximum memory capacities assume 64-bit operating systems, such as genuine Genuine
Windows® 7 Professional 64-Bit or Red Hat Linux 64-bit. 32-bit Windows Operating Systems support up to
4 GB.
1 PCI Express Gen3 slot x16 mechanical/ x16 electrical (full height, full length)
1 PCI Express Gen2 slot x4 mechanical/ x1 electrical (full height)
1 PCI Express Gen2 slot x16 mechanical/ x4 electrical (full height, full length)
1 PCI Express Gen2 slot x1 mechanical/ x1 electrical (full height)
In the PCIe Gen3 (x16 electrical/x16 mechanical) slot, if it is not being used for a graphics card, only cards
certified as After Market Options for this platform are supported.
1 PCI slot, full height, full length
SATA
Serial Attached SCSI
Integrated RAID
Integrated Graphics
DA - 14629 Worldwide — Version 13 — February 3, 2014
HP Z230 Tower Workstation
Integrated (5) Serial ATA interfaces (6Gb/s SATA). One port can
optionally be used for eSATA.
RAID 0 and 1 supported. Factory integrated RAID is Microsoft
Windows only. RAID 5 is supported by Software XOR.
None
NOTE: Requires identical hard drives (speeds, capacity,
interface)
Intel HD Graphics 4600 (on Core i5/i7-4xxx processors);
Intel HD Graphics P4600 (on Intel Xeon E3-12x5v3 processors).
Based on Unified Memory Architecture (UMA)- a region of
system memory is reserved and dedicated to the graphics
display.
Support for Microsoft DirectX 11, OpenGL 4.0 and OpenCL 1.2
on Intel HD Graphics P4600;
1 DVI-I and 2 DP 1.2 graphics ports integrated in motherboard;
Supports up to three simultaneous displays across DP & DVI-I
outputs.
Max. resolution supported on DVI- I ports: 1920x1200 @60Hz
Page 15
