- Page 1 OPTIMAX HE PLUS S INSTRUCTIONS FOR USE INSTALLATION AND MAINTENANCE...
- Page 2 “This record must be completed and left with the end user”. Ferroli is a member of the Benchmark initiative and fully supports the aims of the programme. Benchmark has been introduced to improve the standards of installation and commissioning of central heating systems in the UK and to encourage the regular servicing of all central heating systems to ensure safety and efficiency.
-
Page 3: Table Of Contents
OPTIMAX HE PLUS S 1. Instructions ........................4 1.1 Introduction ............................4 1.2 Control panel ..........................4 1.3 Turning ON and OFF ........................5 1.4 Adjustments ...........................6 2. Installation.......................... 7 2.1 General Instructions ........................7 2.2 Place of installation ........................8 2.3 Plumbing connections ........................8 2.4 Connection to the gas system ......................10... -
Page 4: Instructions
1.1 Introduction Dear Customer, thank you for choosing the Optimax HE PLUS S, a FERROLI wall-mounted boiler of the latest generation, featuring advanced design and cutting-edge technology. Optimax HE PLUS S is a high-efficiency condensing pre-mix appliance for heating with extremely low emissions, running on natural gas or LPG. -
Page 5: Turning On And Off
OPTIMAX HE PLUS S Indication during boiler operation Central Heating mode The Central Heating heat demand (generated by the OpenTherm Remote Control, the Room Thermostat or the Clock) is indicated by the flashing of the Hot Air symbol over the radiator (part. 13 and 14 - fig. 1). The display indicates the actual Central Heating water tem- perature (part. -
Page 6: Adjustments
OPTIMAX HE PLUS S Turning off Press the on/off button (part. 7 - fig. 1) for 5 seconds. fig. 6 - Turning off When the boiler is turned off with this key, the p.c.b is still powered, heating operation is disabled and the display is off however the frost protection will still be active. -
Page 7: Installation
OPTIMAX HE PLUS S 2. Installation 2.1 General Instructions This unit must only be used for its intended purpose. This unit is designed to heat water to a temperature below boiling point and must be connected to a heating system and/or a water supply system for domestic use, com- patible with its performance, characteristics and heating capacity. -
Page 8: Place Of Installation
OPTIMAX HE PLUS S 2.2 Place of installation The combustion circuit is sealed with respect to the place of installation and therefore the unit can be installed in any room. However, the place of installation must be sufficiently ventilated to prevent the creation of dangerous conditions in case of even slight gas leaks. - Page 9 OPTIMAX HE PLUS S Shutoff valve kit The isolation valve kit shown in fig. 10 is supplied as standard. fig. 10 Make up water Provision must be made for replacing water lost from the sealed system. Reference should be made to BS6798, for methods of filling and making up sealed systems.
-
Page 10: Connection To The Gas System
OPTIMAX HE PLUS S Water treatment If treatment of the water is necessary, Ferroli recommends the exclusive use of specific products such as Fernox or Sen- tinel to be applied in compliance with the producer’s instructions. For more information, please contact: Fernox Manufacturing Co. - Page 11 OPTIMAX HE PLUS S Accessing electrical terminal block The electrical connections terminal block can be accessed after removing the casing. The layout of the terminals for the various connections is given in the wiring diagram in fig. 35 and 36.
- Page 12 OPTIMAX HE PLUS S Central heating Demand The heat demand can be controlled by the room thermostat (terminal 5-6) or by a switch line 230 V (terminal 5). Standard Systems For a general pipe layout and wiring diagram on the “S” and “Y” plan systems please see fig. 13a, 13b, and 14a, 14b.
- Page 13 OPTIMAX HE PLUS S OPTIMAX “Y” Plan fig. 14a - Pipe layout fig. 14b -Wiring diagram Cod. 3540R543 - 08/2012 (Rev. 00)
-
Page 14: Flue System
The current standards and local regulations must be observed. Only a Ferroli flue system (with respective accessories) must be used with this unit, as required by BS 5440 and CE standards. - Page 15 OPTIMAX HE PLUS S Other coaxial connections fig. 16 - Examples of connection with coaxial pipes ( = Air / = Fumes) For coaxial connection, fit the unit with one of the following starting accessories. For the wall hole dimensions, refer to section 4.1 Dimensions and connections.
- Page 16 OPTIMAX HE PLUS S Connection with separate pipes fig. 18 - Examples of connection with separate pipes ( = Air / = Fumes) For the connection of separate ducts, fit the unit with the following starting accessory: fig. 19 - Starting accessory for separate ducts...
- Page 17 OPTIMAX HE PLUS S Position of terminals fig. 20 Minimum dimensions of fume exhaust terminals Directly under an opening, air inlet, openable window, etc. 300 mm Above an opening, air inlet, openable window, etc. 300 mm Horizontally to an opening, air inlet, openable window, etc.
-
Page 18: Condensate Drain Connection
Connection to multiple flues or single flues with natural draught To connect the Optimax HE PLUS S boiler to a multiple flue or a single flue with natural draught, the flue or chimney must be expressly designed by professionally qualified technical personnel in conformity with the current standards and regulations. - Page 19 OPTIMAX HE PLUS S Condensate drain If possible, the condensate should be conveyed inside the internal drainage system or pipe. For that purpose, use a pipe of at least 22 mm diameter and a trap with flexible connection supplied with the unit to facilitate connection of the condensate drain pipe.
-
Page 20: Service And Maintenance
All adjustment, conversion, startup and maintenance operations described below must only be carried out by Qualified Personnel (meeting the professional technical requirements prescribed by current regulations). FERROLI declines any liability for damage and/or injury caused by unqualified and unauthorised persons tampering with the unit. -
Page 21: Commisioning Instructions
OPTIMAX HE PLUS S Before lighting the boiler • Open any on-off valves between the boiler and the systems. • Check the tightness of the gas system, proceeding with caution and using a soap and water solution to detect any leaks in connections. -
Page 22: Routine Servicing, Maintenance & Repair
OPTIMAX HE PLUS S Check the operational (working) gas inlet pressure Set up the boiler to operate at maximum rate as described in section Test mode of section 3.3. With the boiler operating in the maximum rate condition check that the operational (working) gas pressure at the inlet gas pressure test point (see fig. -
Page 23: Combustion Check
OPTIMAX HE PLUS S • The expansion tank must be filled. • The gas flow and pressure must correspond to that given in the respective tables. The boiler casing, panel and aesthetic parts can be cleaned with a soft damp cloth, possibly soaked in soapy water. -
Page 24: Troubleshooting
OPTIMAX HE PLUS S Setting the Air/Gas Ratio valve There are two adjustments possible on the air/gas ratio valve, the throttle setting at maximum rate and the offset setting at minimum rate. If either setting is adjusted the combustion values must be rechecked at both rates. - Page 25 OPTIMAX HE PLUS S Table 6 - List of faults Fault Fault Possible cause Cure code Check the regular gas flow to the boiler and that the air has been purged No gas from the pipes Detection or Ignition electrode fault...
-
Page 26: Technical Data And Characteristics
OPTIMAX HE PLUS S 4. Technical data and characteristics 4.1 Dimensions and connections fig. 29 - Dimensions and connections 1 Heating system delivery 5 Heating system return 3 Gas inlet 6 Safety valve drain Cod. 3540R543 - 08/2012 (Rev. 00) -
Page 27: General View And Main Components
OPTIMAX HE PLUS S 4.2 General view and main components fig. 30 - General view 5 Sealed chamber 44 Gas valve 201 Mixing chamber 7 Gas inlet 56 Expansion tank 241 Automatic bypass 10 System delivery 81 Ignition electrode 250 System delivery filter... -
Page 28: Water Circuit
OPTIMAX HE PLUS S 4.3 Water circuit fig. 31 - Water circuit 10 System delivery 154 Condense drain pipe 11 System return 161 Condensing heat exchanger 14 Safety valve 186 Return sensor 32 Heating circulating pump 193 Condensate trap sensor... -
Page 29: Technical Data Table
OPTIMAX HE PLUS S 4.4 Technical data table UNIT 18 S 25 S 35 S Max. CH Heat input 18.0 25.2 34.8 Min. CH Heat input Max. useful heat output 80° C - 60° C 17.7 24.6 34.2 Min. useful heat output 80° C - 60° C Max. -
Page 30: Diagrams
OPTIMAX HE PLUS S 4.5 Diagrams Head available for the system (OPTIMAX HE PLUS 18 S) fig. 32 - Pressure loss Head available for the system (OPTIMAX HE PLUS 25 S) fig. 33 - Pressure loss Head available for the system (OPTIMAX HE PLUS 35 S) fig. -
Page 31: Wiring Diagram
OPTIMAX HE PLUS S 4.6 Wiring diagram OPTIMAX HE PLUS 18 S fig. 35 16 Fan 104 Fuse F 3.15 amp 32 Central heating pump 114 Water pressure switch 44 Combination gas valve 186 Return temperature sensor 62 Time clock (optional) - Page 32 OPTIMAX HE PLUS S OPTIMAX HE PLUS 25 S and 35 S fig. 35 16 Fan 104 Fuse F 3.15 amp 32 Central heating pump 114 Water pressure switch 44 Combination gas valve 186 Return temperature sensor 62 Time clock (optional)
- Page 34 Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty. This does not affect the customer’s statutory rights. If yes, and if required by the manufacturer, has a water scale reducer been fitted? CONDENSING BOILERS ONLY The condensate drain has been installed in accordance with the manufacturer’s instructions and/or BS5546/BS6798 If the condensate pipe terminates externally has the pipe diameter been increased and weatherproof insulation fitted?
-
Page 35: Service Record
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. - Page 36 Before contacting Ferroli please have available the completed BENCHMARK document (located in the back of this manual), boiler serial number and model detail. For Technical assistance during the installation, call our Technical Helpline on 0843 479 0479. You will be required to provide your Gas Safe Register Number.
