Summary of Contents for Ferroli Optimax 25C- Modena HE
- Page 1 Boiler Replacement Optimax 25C- Modena HE...
- Page 2 The new Ferroli Modena 32C HE high efficiency condensing combination boiler is an ideal replacement for the earlier Ferroli Optimax 25C. The Ferroli Modena 32C HE is smaller, weighs less, has built-in frost protection and an IP protection rating of IPX5D. This allows direct replacement wherever the existing boiler is legitimately installed (i.e.
- Page 3 BOILER REPLACEMENT: OPTIMAX 25C TO MODENA 32C HE Manual Handling When lifting take suitable safety precautions: keep your back straight, bend knees, do not turn your body, avoid bending forward or sideways and keep the load as close as possible to your body. Ideally seek assistance in lifting the boiler.
- Page 4 BOILER REPLACEMENT: OPTIMAX 25C TO MODENA 32C HE Disconnect and remove the flue from the existing boiler by undoing the four screws securing the appliance bend to the top of the boiler (Fig.4) Fig.4 Ensure that all pipe connections are free, move the base of the boiler forward and lift the boiler off the hanging bracket tabs and unscrew the hanging bracket from the wall.
- Page 5 BOILER REPLACEMENT: OPTIMAX 25C TO MODENA 32C HE INSTALLING THE NEW MODENA C HE Modena 32C HE Dimensions Boiler Pack Contents 1 x Modena C HE Boiler 1. Check the existing flue terminal position 1 x Installation Instructions with regard to possible nuisance “pluming”. 1 x Hanging Bracket 1 x Filling Loop 1 x Valve Pack...
- Page 6 BOILER REPLACEMENT: OPTIMAX 25C TO MODENA 32C HE 5. Lay the boiler on its back. Remove the front casing panel by undoing the two securing screws on the underside of the case. Ease the lower edge of the panel forward to clear the controls display and lift upwards off the frame.
- Page 7 BOILER REPLACEMENT: OPTIMAX 25C TO MODENA 32C HE Remove the condensate bowl and hose from the boiler fittings pack. Undo plastic nut (Fig.9-A) and fit Condensate bowl, the condensate bowl and washer. Push on the washer and rubber rubber condensate hose to the trap outlet (Fig.9-B). hose connection Fig.9 10.
- Page 8 BOILER REPLACEMENT: OPTIMAX 25C TO MODENA 32C HE 13. Open the cold water isolation valve and thoroughly flush the cold/hot water pipe-work by opening all the hot taps. 14. Reinstate the gas supply, purge and test in accordance with BS 6891 and IGE/UP/1. 15.
- Page 9 BOILER REPLACEMENT: OPTIMAX 25C TO MODENA 32C HE 16. Commissioning the boiler: (see 3.3 of the Modena C HE Installation Instructions) Fig.13 Connect a manometer to the inlet test point of the gas valve (Fig.13) Set the boiler to operate at maximum by selecting ‘TEST MODE’...
- Page 10 Whilst every effort is taken to ensure the accuracy of the information contained within the brochure, the details are offered in good faith and Ferroli Ltd. accepts no liability for matters arising as a result of errors and/or omissions. The information in this brochure was correct at the time of printing, however specifications and designs may be changed owing to Ferroli’s policy of...
