D
I
ESKTOP
NSTALLATION
To install the switch on the desktop, follow these steps:
Set the switch on a flat surface strong enough to support the entire weight
1.
of the switch with all fittings.
Remove the adhesive backing papers from the rubber feet.
2.
Turn the switch over and attach the supplied rubber feet to the recessed
3.
areas on the bottom at each corner of the switch.
Figure 4: Attaching Rubber Feet
Upturn the switch and set in the desired location, making sure there is
4.
enough ventilation space on all sides for proper air flow
Connect the switch to a power source with the provided power cord. See
5.
"Powering On" on page
C
AUTION
R
I
ACK
NSTALLATION
To install the switch in an EIA standard-sized, 19-inch rack, follow the
instructions described below:
28.
Avoid placing anything heavy on the switch.
:
C
HAPTER
h
c
it
w
S
E
o
P
e t
n
e r
h
E t
s
p
s t
b
M
a
0
F
0
t
o r
0
/1
P
0
6 -
0
/1
1
0
1
h
c
it
w
S
Z
E
– 25 –
| Installing the Switch
