B–2 Compaq StorageWorks 4200 Family LVD Disk Enclosure User Guide
Table B–1 Disk Enclosure Physical Specification
Horizontal Orientation
Empty
Height
5.16 in (13.1 cm)
Depth
17.625 in (44.8 cm)
Width
19.875 in (50.5cm)
Weight
24 lb (11 kg)
Height
Depth
Width
Weight
Height
Depth
Width
Weight
Installed
5.16 in (13.1 cm)
17.625 in (44.8 cm)
19.875 in (50.5cm)
68 lb (31 kg)
Table B–2 Element Physical Specifications
Vertical Orientation
Installed
Environmental Monitoring Unit (EMU)
4.5 in (11.4 cm)
9.5 in (24.1 cm)
1.375 in (3.5 cm)
1.3 lb (0.6 kg)
Variable Speed Blower (without power supply)
5.5 in (14.0 cm)
3.25 in (6.4 cm)
6.25 in (15.9 cm)
1.0 lb (0.5 kg)
Vertical Orientation
Shipping Carton Shipping Carton and
25.25 in (64.1 cm) 30.25 in (76.8 cm)
23.5 in (59.7 cm) 40.0 in (101.6 cm)
12.5 in (31.8 cm) 24 in (61 cm)
96 lb (44 kg) 108 lb (49 kg)
Horizontal Orientation
Shipping Carton
8.5 in (21.6 cm)
13.0 in (33.0 cm)
4.5 in (11.4 cm)
2.3 lb (1.0 kg)
7.5 in (19.0 cm)
8.75 in (22.2 cm)
8.0 in (20.3 cm)
2.0 lb (0.9 kg)
Pallet
