Compaq 4200 User Manual page 67

Table 7–5 Power Supply Replacement Procedure (Continued)
5. While lifting up on the module latch
supply to the rear.
1
2
CAUTION:
Pressing in on the center section of the blower shroud can damage the blower
blades. To avoid damaging the blower, only press on the outer portion of the blower shroud.
6. While lifting up on the module latch
shroud until it is fully seated in the enclosure
7. Press the module latch down to secure the supply in the enclosure.
8. Connect the AC power cord and observe the power supply for proper operation.
The blower starts operating immediately.
The blower LED is O
The blower on the other supply is no longer be operating at high-speed.
, grasp the blower element shell
6
4
3
CXO6809A
, push in on the power supply
.
N
Replacing CRUs
and pull the power
5
and the outer blower
7–11
