Dual-Bus I/O Module

This section describes the unique features and components of the dual-bus module. This
module (see Figure 3–6) is easily identifiable by the two VHDCI connectors and the three
LEDs.
1
4
Figure 3–6. Dual-bus I/O module components
2
3
CXO7063A
I/O Modules
Latch
SCSI Bus A connector
Status LEDs
L –Power
EFT
M —SCSI bus A
IDDLE
termination status
R –SCSI bus B
IGHT
termination status
SCSI Bus B connector
3–7
