    Contents For the installer For the user Technical specifications Safety information Unpacking Description of the appliance - Damages - Spray arm - Use - Coarse strainer/microfilter - Positioning - Fine filter - Detergent dispenser Installation 17-18 - Rinse aid dispenser - Water inlet - Water softener - Water drainage...
  • Page 3: Safety Information

    Safety information Before installing and first using the dishwasher, read this instruction booklet carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the dishwasher are thoroughly familiar with its operation and safety features. Save these instructions and make sure they remain with the dishwasher if it is moved or sold, so that everyone using it through its life can be properly informed on appliance use and safety.
  • Page 4: Description Of The Appliance

    Description of the appliance - 4 -...
  • Page 5: Spray Arm

    Description of the appliance Spray arm (1) 4. Close the lid and press until it locks again. It is important to keep all the holes in the spray arm clear. Do not fill the rinse aid dispenser with liquid A clogged hole can seriously affect washing efficiency. detergent.
  • Page 6: The Control Panel

    The control panel Indicator and control lamps Reset position On/Off Indicator lamp Programme Delay start selector button Start/Cancel button Programme selector Indicator lamps: Turn the programme selector clockwise or anticlockwise Shows current phase of the selected programme. to select the programme and temperature according to •...
  • Page 7: Setting Of The Water Softener

    Setting of the water softener To prevent limescaling on the dishes and to the interior of the Contact your local Water Authority to find the dishwasher, the dishes must be washed with soft water. exact water hardness level for your area. This dishwasher is equipped with a water softener, where tap- The water softener has 10 settings: water which is harder than 4 °d (german degree) is softened.
  • Page 8: Programme Chart

    Programme chart All types of All types of Plates and Coffee cups, Type of dishes delicate items dishes dishes cooking pots • heavily Type of • normally • normally • lightly • 3) soiled soil: soiled soiled soiled • dried-on food •...
  • Page 9: Loading And Unloading

    Loading and unloading the dishwasher How to load the dishes Baskets The illustration shows the dishwasher loaded with six Main basket place settings. Your own dishes are not likely to be Cutlery basket identical to this load, but if you follow the advices below The cup shelves can be placed in two different we are sure you will be pleased with the result.
  • Page 10: Using The Appliance

    Using the appliance Starting the programme Cancelling the drying phase 1. Scrape or rinse off solid food remnants. In case you do not want to wait until the drying phase is completed, you can cancel it. 2. Load the dishwasher. (See the basket and loading).
  • Page 11: Maintenance And Cleaning

    Maintenance and cleaning Cleaning the filters Moving the dishwasher There are two filters, a coarse one and a fine one which If you have to move the dishwasher (you are moving should be cleaned after every wash. Lift out these filters house, etc): which are in the base of the dishwasher and wash under 1.
  • Page 12: Something Not Working

    Something Not Working Before calling out an engineer, please check through the details below because some faults can be rectified easily without the need to call out an engineer. If an engineer is called to resolve a problem listed below or to repair a fault caused by incorrect installation or mis-use a charge will be made, even if the appliance is under guarantee.
  • Page 13: Service

    Service Service and Spare Parts Customer Care Department In the event of your appliance requiring service, or if you For general enquiries concerning your Electrolux appliance wish to purchase spare parts, please contact your local or for further information on Electrolux products, please Service Force Centre by telephoning: contact our Customer Care Department by letter or telephone at the address below or visit our website at...
  • Page 14: Guarantee Conditions

    Guarantee Conditions Standard guarantee conditions We, Electrolux, undertake that if within 12 months from the date of the purchase this ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •...
  • Page 15: Technical Speciļ¬cations

    Installation instructions Any electrical work required to install this appliance, should be carried out by a qualified electrician or competent person. Any plumbing work required to install this appliance, should be carried out by a qualified plumber or competent person. Technical specifications Capacity: 6 place settings accordance EN 50242...
  • Page 16: Unpacking

    Unpacking Damages If the dishwasher has been damaged during transport, you should immediately notify the company responsible for delivering it. Check that the dishwasher is undamaged. If you discover any damage, faults or that anything is missing, you should notify the dealer immediately. Never leave packaging material in a place where children may play with it.
  • Page 17: Installation

    Installation Water inlet The dishwasher is equipped with safety features which are to prevent the water from going back to the fresh water system. These features are ac- cording to current water technical safety regulations. The dishwasher should be permanently plumbed into a separate cold water supply.
  • Page 18: Power Supply

    Installation Power supply The dishwasher is supplied with a lead and electrical plug for connection to a 230 V, 13 A earthed wall socket. Before any work is carried out on the dish- washer, it must be isolated from the electric mains supply, for example by removing the plug from the wall socket.
  • Page 19: Information For Test Centres

    Information for test centres The salt container and rinse aid dispenser shall be filled in accordance with this instruction manual. Before conducting the measurements the dishwasher shall be operated for one or two complete cycles using detergent and a clean load. Test standard: EN 50242 and EN 60704 Rated capacity:...
