easily tell this by watching for the point where the TONE ARM
(7) "floats" freely.
4. Place TONE ARM (7) on ARM REST (11) and lock it in place
with the ARM CLAMP (10).
5. With the TONE ARM (7) locked on the ARM REST (11), hold
the COUNTERWEIGHT (8) steady with one hand while rotating
the STYLUS PRESSURE RING (9) until the numeral "0" on the
ring aligns with the center line on the TONE ARM (7) rear shaft.
The HORIZONTAL ZERO (0) balance should be completed.
6. Re-float the TONE ARM (7) to ensure horizontal zero (0) bal-
ance. If zero balance has not been maintained, repeat counter-
weight steps 3 - 5.
7. After adjusting the HORIZONTAL ZERO (0) balance, turn the
balanced COUNTERWEIGHT (8) counter clockwise until the
cartridge manufacturer's recommend stylus pressure appears
on the STYLUS PRESSURE RING (9) where it meets the cen-
ter line of the TONE ARM (7) rear shaft.
ADJUSTING THE ANTI-SKATING CONTROL:
Set the ANTI-SKATING CONTROL (12) to the same value as
the stylus pressure.
NOTE: IF YOUR TURNTABLE CAME WITH A CN-1000 CARTRIDGE, IT HAS A
RECOMMENDED TRACKING FORCE OF 3.0 GRAMS AND CAN HAVE RANGE
FROM 2.5-3.5 GRAMS.
ADJUSTING TONE ARM HEIGHT:
The TT-03 comes with an adjustable TONE ARM BASE (7).
This feature is generally used when a larger or smaller sized
headshell is used for record playing. You may adjust the height
of the TONE ARM (7) by unlocking the base with the use of the
LOCK SWITCH (20) located next to the ANTI SKATE CON-
TROL (12). Then adjust the TONE ARM ADJUSTMENT
LEVER (8), located below the counter weight, to adjust the
height of the TONE ARM (7) by 6 mm.
CONNECTIONS:
1. Plug the AC power plug into an appropriate outlet.
2. See TABLE A for proper connection of the output RCA plugs
and ground connector. Make sure that all the plugs are firmly
plugged into the appropriate jacks (phono inputs).
NOTE: TO REDUCE HUM, MAKE SURE THE GROUND LUG IS FIRMLY CON-
NECTED TO THE GROUND SCREW.
TABLE A:
OUTPUT CONNECTORS
L (WHITE)
R (RED)
GND (SPADE LUG)
OPERATING INSTRUCTIONS:

BASIC OPERATION:

1. Turn the POWER (13) switch to the "ON" position, at which
point the TARGET LIGHT (14) will light up, TARGET LIGHTS
(14) are an optional accessory available at your local retailer.
2. Place a record on the SLIPMAT (4) which sits on the PLAT-
TER (2).
3. Select the desired speed by depressing the 33, 45 or 78 (33
& 45 simultaneously) SPEED SELECTOR (16) button.
MIXER OR RECIEVER
PHONO L CHANNEL
PHONO R CHANNEL
GND SCREW
(5)
4. Remove the stylus protector (if applicable to your cartridge).
5. Release the ARM CLAMP (10) found on the ARM REST (11).
6. Push the START/STOP (15) button. The turntable PLATTER
(2) will start to spin.
7. Carefully position the TONE ARM (7) over the desired posi-
tion over the record. Lower the TONE ARM (7) slowly, while let-
ting go of the TONE ARM (7) over the record where you want to
play.
8. When play is over, raise the TONE ARM (7), move it onto the
ARM REST (11), and secure it with the ARM CLAMP (10).
9. You now have the option of turning off the power by turning
the POWER (13) switch to the "OFF" position, or stopping the
PLATTER (2) by pushing the START/STOP (15) button.
INTERRUPTING PLAY:
1. Pushing the START/STOP (15) button will cause the record to
stop exactly when the START/STOP (15) button is pressed
while playing.
2. Press the START/STOP (15) button again to start playback
with a short delay effect.
ADJUSTING THE PITCH CONTROL:
1. The TT-03 is equipped with a PITCH SLIDE CONTROL (17).
When the PITCH SLIDE CONTROL (17) is in the center posi-
tion, the speed will be 33, 45, or 78 depending on which SPEED
SELECTOR (16) button is pushed.
2. When the PITCH SLIDE CONTROL (17) is positioned off cen-
ter, the pitch can vary ±10% depending on the position of the
PITCH SLIDE CONTROL (17).
3. To lock the PITCH SLIDE CONTROL (17) press the QUARTZ
LOCK BUTTON (18) located above the PITCH SLIDE CON-
TROL (17).

SPECIFICATIONS:

TURNTABLE SECTION:
Type.................................Direct
Drive Method..............High Torque (2.2 kg) Direct Drive
Motor.............................................................................DC Motor
Speed...............................................33 1/3, 45, 78 RPM
Wow and Flutter.....................Less than 0.15% WRMS*
*THIS RATING REFERS TO THE TURNTABLE ASSEMBLY AND PLATTER
ONLY AND EXCLUDES EFFECTS OF RECORDS, CARTRIDGES OR TON-
EARMS.
TONEARM SECTION:
Type......................Statically
Headshell Weight....................................................5.6
GENERAL:
Power Supply..............................AC 115 V~60 Hz/230 V~50 Hz
Power Consumption.............................................................30 W
Dimensions...................................................17.75" x 5.75" x 14"
....................................................................(450 x 136 x 352mm)
Weight.....................................................20.1 lbs. (9.1 kg)
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE. THE
WEIGHT AND DIMENSIONS SHOWN ARE APPROXIMATE.
TT-0 0 3
TT-0 0 3
Drive Manual Turntable
Balanced Straight Tonearm
g
