Warning! Once connected to the
mains supply check that all cooking
zones are ready for use by briefly
switching each on in turn at the
maximum setting.
• A duplicate rating label is supplied
with this unit. For easy identification of
this unit after installation, stick it to a
readily available surface adjacent to
the cooktop.
Sticking on the seal
• Clean the worktop around the cutout area.
• Stick the single-sided adhesive sealing
tape provided on the underside of the hob

Assembly

EHET 66CS
around the outside edge ensuring that it is
not stretched. The two ends of the tape
should join in the middle of one side. After
trimming the tape (allow it to overlap by 2-3
mm), press the two ends together.
The cut-out section in the worktop
is illustrated in the drawing with the
dimensions 560 x 490 / 880 x 490
mm. The appliance can also be built
into a shorter cut-out section with
the dimensions 560 x 485 / 880 x 485
mm.
EHET 96CS
electrolux 15
