14 electrolux
your household waste disposal service or the
shop where you purchased the product.
Packaging material.
The packaging materials are envi-
ronmentally friendly and can be re-
cycled. The plastic components are

Installation Instructions

Warning! Safety instructions
Warning! This must be read! The laws,
ordinances, directives and standards in
force in the country of use are to be
followed (safety regulations, proper
recycling in accordance with the
regulations, etc.)
Important! Installation may only be carried
out by a qualified electrician.
The minimum distances to other appliances
and units are to be observed.
Anti-shock protection must be provided by
the installation, for example drawers may on-
ly be installed with a protective floor directly
underneath the appliance.
The cut surfaces of the worktop are to be
protected against moisture using a suitable
sealant. The sealant seals the appliance to
the work top with no gap. Do not use silicon
sealant between the appliance and the work
top.
Avoid installing the appliance next to doors
and under windows. Otherwise hot cook-
ware may be knocked off the rings when
doors and windows are opened.
Caution! Warning! Risk of injury
from electrical current.
• The electrical mains terminal is live.
• Make electrical mains terminal free of volt-
age.
• Follow connection schematic.
• Observe electrical safety rules.
• Ensure anti-shock protection by installing
correctly.
• The appliance must be connected to the
electrical supply by a qualified electrician.
• Loose and inappropriate plug and socket
connections can make the terminal over-
heat.
• Have the clamping connections correctly
installed by a qualified electrician.
• Use strain relief clamp on cable.
identified by markings, e. g., >PE<,
>PS< etc. Please use markings to
dispose of the packaging materials
in the appropriate container at the
community waste disposal facilities.
Caution! The surface temperature
exceeds 95°C. To avoid a hazard,
underbench access must be restric-
ted
Electrical Connection
Before connecting, check that the nominal
voltage of the appliance, that is the voltage
stated on the rating plate, corresponds to the
available supply voltage. Also check the
power rating of the appliance and ensure that
the wire is suitably sized in accordance with
local wiring rules to suit the appliance power
rating. The rating plate is located on the lower
casing of the hob. The heating element volt-
age is AC230V~. The appliance also works
perfectly on networks with AC220V~ or
AC240V~. Means for disconnection must be
incorporated in the fixed wiring in accord-
ance with local wiring rules.The hob is to be
connected to the mains using a device that
allows the appliance to be disconnected
from the mains at all poles with a contact
opening width of at least 3 mm, eg. auto-
matic line protecting cut-out, earth leakage
tripsorfuse. If this appliance's mains cable is
damaged, it must be replaced by a special
cable (type H05BB-F Tmax 90°C; or higher).
The latter is available from the Customer
Care Department. The connection must be
carried out as shown in the diagram. The
connecting links should be fitted according
to the appropriate connection diagram. The
earth lead is connected to terminal
earth lead must be longer than leads carrying
electric current. The cable connections
must be made in accordance with regu-
lations and the terminal screws tight-
ened securely. Finally, the connecting cable
is to be secured with the mains cable cleat
and the covering closed by pressing firmly
(lock into place). Before switching on for the
first time, any protective foil or stickers must
be removed from the glass ceramic surface.
. The
