INSTALLING SOFTWARE ON PC

System Requirements
Pentium 133MHz or faster CD-ROM drive
USB port 20MB free hard disc space
Window 98 SE/ME/2000(PRO)/XP
You can install programs as follows :
DataPlay Bass Components
Future Player
DataPlay file System
Java Runtime Environment
8
CONNECTING THE UNIT TO PC
Connect the USB cable(Provided) to the USB port of your computer.
Type A : USB port on the Panel of PC
Type B : USB port of iDP-100
Connect the USB cable to match the direction.
Type "A"
Type "B"
USB cable
USB port on the PC USB port on the IDP-100
Connect the USB port on the Panel of PC.
Turn on the iDP-100, remove the protective cover of USB port, and connect the
USB cable.
"USB CONNECTED" will appear on the LCD of the player.
9
Type "A"
Type "B"
