FUNCTION CONTROL(Control/EQ)
INTRO MODE
INTRO : Play beginning 10 seconds of each
track.
POWER
You can select the access time and continuous
play time.
Normal : Media access time : High speed
Continuous play time : about 9 hours
Power Save : Continuous play time : about 10.5 hours
Super Power Save : Media access time : Low speed
Continuous play time : about 12 hours
USER EQ
BASS BOOST
: Bass Boost level is from 0 to 12dB.
BASS CORNER FREQUENCY
: Bass Boost frequencies are 50Hz, 100Hz and
200Hz.
Bass Boost function is effective under the
frequency range configured. Maximized at
200Hz.
26
* 1000mA Battery used
FUNCTION CONTROL(Control/EQ)
TREBLE BOOST
: Treble Boost level is from 0 to 12dB.
TREBLE CORNER FREQUENCY
: Treble boost frequencies are 2kHz, 4kHz and
7kHz.
Treble Boost function is effective over the
frequency range configured. Maximized at
2kHz.
27
