URL : http://www.iRiver.com
Provides information on our company, products, and email addresses for
support.
Unique feature of "Firmware (system software) Upgrade" is available for
download on our site. The Firmware provides new features as well as
enhancements to current features. New CODECS that will be introduced in
the future will be supported via Firmware Upgrade.
Provides FAQ as well as a User's Forum.
Register your iRiver product online so that our Customer Service is able to
provide support as efficiently as possible.
iRiver Limited does not assume any responsibility for errors or omissions in
this document or make any commitment to update the information contained
herein.
iRiver is a registered trademark of iRiver Limited in the Republic of Korea and
/or other countries and is used under license. Microsoft Windows Media and the
Windows Logo are trademarks or registered trademarks of Microsoft
Corporation in the United States and /or other countries.
All other brand and product names are trademarks of their respective
companies or organization. All other product names may be trademarks of the
companies with which they are associated.
1999-2003 iRiver Limited. All right reserved.
2
Unique Design
Multi-Codec Player
: Supports MP3, WMA, ASF formats.
Firmware Upgrade
: Provides the latest updated features via firmware upgrade.
Player features such as add on, modification, and continuous improvement of
player are always provided.
Graphic LCD supporting Multiple Languages
: iFP-300 Series comes with graphic LCD which can support multiple languages
FM Function
You can easily listen to FM stations and set your favorite stations by using Auto
Preset and Frequency Memory functions.
Normal, Rock, Jazz, Classic, U Bass, Metal
6 Preset EQ :
5 Band User EQ
GUI(Graphic User Interface) MENU SUPPORTING
Easy Navigation
Support MP3 Direct Encoding:
8KHz ~ 44.1KHz, 8Kbps ~ 320Kbps
3
Advertisement
Table of Contents
Related Manuals for IRiver iFP-380T
Summary of Contents for IRiver iFP-380T
- Page 1 GUI(Graphic User Interface) MENU SUPPORTING herein. Easy Navigation iRiver is a registered trademark of iRiver Limited in the Republic of Korea and Support MP3 Direct Encoding: /or other countries and is used under license. Microsoft Windows Media and the 8KHz ~ 44.1KHz, 8Kbps ~ 320Kbps Windows Logo are trademarks or registered trademarks of Microsoft Corporation in the United States and /or other countries.
-
Page 2: Side View
INTRODUCING TO THE IRIVER WEBSITES..............FRONT VIEW UNIQUE FEATURE......................CONTENTS......................... 1. LOCATING THE CONTROLS LCD Window Volume + FRONT VIEW, SIDE VIEW 1....................SIDE VIEW 2........................LCD WINDOW........................2. BASIC OPERATION BASIC OPERATION......................INSTALLING SOFTWARE ON THE PC................BASIC OPERATION EXPLANATION.................. - Page 3 LCD Window SIDE VIEW 2 THE ORDER PLAY Hold USB Connection Port OF SONGS TIME PLAYBACK MODE HOLD BATTERY INDICATOR Earphone FOLDER NAME ARTIST/TITLE NAME Battery Compartment VOLUME FILE BIT RATE EQUALIZER FORMAT WAVEFORM SAMPLING RATE PROGRAM...
- Page 4 BASIC OPERATION When using Navigation Press + on volume button to increase volume and press – on button to decrease volume. When using Menu Selecting FM Mode when listening FM : (Refer to p. 34) VOICE LINE IN Changing : 1.
-
Page 5: Deleting Files On The Player
MENU DELETING FILES ON THE PLAYER Click the Select the files to delete by A long press of NAVI/MENU button will execute menu function. Stop playback. “NAVI/MENU” using VOL or VOL . button. Scrolling between menus : Press Exit : Push the VOL - switch down or hold down the NAVI/MENU button. Select Function: Press the NAVI/MENU Button to down. -
Page 6: System Requirements
LCD of the player. You can update the features of the player by downloading from the internet. connect the USB cable. (Log on to www.iriver.com) When installing in O.S after Microsoft Windows 2000, install the software after log-in on administrator... - Page 7 Click “Next” after selecting the Click “Next” to Install iRiver Music Click “Install” to install. Installation is progressing. language to install. Manager. Click “Finish” Select the folder to Install. Completed the installation of “New Click “Next”. hardware”.
-
Page 8: Basic Operation
When installing in Window XP O.S. 1. Basic operation Click „Continue Anyway“ inspite of following alert display when installing in Manager version to be Installed is Double click the iRiver Music Manager Window XP O.S. displayed. icon on the PC to start the Manager program. - Page 9 2. PLAYER & FILE TRANSFERING Downloading is completed. Downloading is processing. 1) Downloading from the PC Select the folder to be saved in the Select the folder and the file on the player. PC to download to the player. CAUTION Files which file name is over 127 chracters(Korean: 63characters) by English is not downloaded.
- Page 10 1) Uploading to the PC Uploading is completed. Uploading is processing. Select the folder to be saved on the Select files or folders in the player to save. CAUTION - You cannot upload general music files(MP3, WMA, ASF) from the player to the PC according to copyright laws.
- Page 11 4) Moving to upper folder(PC & Player) 3) Transfering of folders or files on the player Click the “moving icon to upper folder” in the menu bar of the iRiver Music Manager. Drag and move folders or files to be moved to the wanted place.
-
Page 12: Managing Files
3. Managing files 2) Making new folders on the PC 1) To make a new folder on the player Click the “New Folder” icon or select New folder is created. “File-New folder” in the file menu to make a new folder. Click the “New Folder”... - Page 13 3) Deleting folders or files of the player 4) Deleting folders or files of the PC Click the “Delete” icon or “File-Delete”. After starting the “Manager” program, Click the “Delete” icon or “File-Delete”. After starting the “Manager” program, select the files or folders to delete. select the files or folders to delete.
- Page 14 4. Additional functions The guiding window as below is displayed and firmware upgrade is processing. Click “OK” after the player turns off. 1) Upgrading the firmware Download the latest updated Firmware from our website. And Unzip it, IFP-3XXT.HEX file is created. If not created, execute the “*.EXE” file. Click the “Transter-Firmware Upgrade”...
- Page 15 2) Format 3) Modifing the Radio channels Format will erase all files in your player memory. You can modify the FM Radio channels on the iRiver Music Manager. Click “Start”. Click the “format” icon or select “File- Select “Transfer-Tuner Setting”...
- Page 16 Put the HOLD switch to “OFF”. Connect the earphones as below. To turn on the player To play the next folder To Play Press the PLAY/STOP button to To select music To play the previous folder turn the player on. And press it : To select previous music again to play.
- Page 17 To listen the favorate broadcasting(FM 87.5~108MHz) While playing MP3, Press and hold the MODE/REC button. To change frequency, push the switch to the left or the right. (ex : 87.5 87.6) The function selection picture displays LINE VOICE on the LCD. RADIO Push the button to select FM RADIO.
- Page 18 Memory Function(Save channels) Memory delete function(Delete saved channels) Select the channel to be deleted at preset mode Select the channel by pushing the switch to the left or the right. Press and hold the memory button. Push and select the again desired channels.
-
Page 19: Recording Voice
To record FM Recording Voice Press and hold the MODE/REC Press the switch to Press the MODE/REC button during FM button. select Voice mode. reception. To stop FM recording Press the MODE/REC button again to stop recording. The recorded file is saved as TUNER000.REC. LINE LINE VOICE... -
Page 20: Recording From The External Equipment
To stop recording To play a recorded file Recording from the external equipment Press the MODE/REC button. Press the PLAY/STOP button. Connect LINE out jack of the external equipment to LINE IN jack of the player. To stop recording temporarily Press button during recording. -
Page 21: To Play A Recorded File
To stop recording Press the NAVI/MENU button(or Press the switch to PLAY/STOP) to go to Line-In select Line-In mode. recording mode. Press the MODE/REC button. STEREO 44.1KHz 128KBPS LINE The recorded file is saved as form of AUDIO000.REC, AUDIO001.REC... in VOICE RADIO sequential order. - Page 22 Navigation is the function used to search tracks. After pressing the NAVI/MENU button, select a recorded file using switch. You can select a song by pressing the NAVI/MENU button and using the VOL +, VOL - buttons. NAVI/MENU button Scroll up Press the PLAY/STOP button.
- Page 23 REPEAT Select the track Scroll up Play a single track repeatedly. Select the Play all tracks in the folder and stop. track Play all tracks in the folder repeatedly. Scroll down Play all tracks in the player repeatedly. SHUFFLE Randomly play all tracks in the player repeatedly and stop. Play a single track repeatedly.
- Page 24 Press the MEMORY/EQ button. Program mode: Create your own playlists. Activating Program mode At stop mode To delete programmed files Press the MODE/REC button after selecting the file to be deleted using the MEMORY/EQ Scroll to Program mode button. Then the program list is automatically changed. Program mode is activated while in Stop Mode.
-
Page 25: Program Play
Program Play EQ MODE After programming, press to play the tracks in sequential order. The program mode icon appears Cancel Program Mode While in Stop Mode Press and hold the MEMORY/EQ button to display the current EQ. Every time you click this button, the EQ mode scrolls in sequential order. Interval Repeat Play a selected interval repeatedly Press button once to select... -
Page 26: Menu Operation
MENU OPERATION Function Control is subject to change with different firmware versions. Users can configure their own settings. MAIN MENU Press and hold the NAVI/MENU button to CONFIGURATION display the menus. It is composed of 6 main menus with sub- menus. - Page 27 Enter Sub Menu GENERAL BEEP VOL : Configure beep sound with volume level. Set to “0” for OFF. RESUME Each control option is configured by : When activated, the player returns to the three buttons as below. same settings after STOP or Power OFF. FADE FADE IN : When activated, volume increases gradually at playback mode to prevent sudden...
- Page 28 LOAD DEFAULT VALUE SCROLL SPEED : Initialize to original factory setting. Adjust scroll speed by Button operation order is as below. 1x/2x/4x/Vertical/Horizontal. Click NAVI/MENU(select default menu) (select Vertical : The scroll goes up and down YES) Click NAVI/MENU(select YES : Initialization) Horizontal : The scroll goes from the left to the right.
- Page 29 TIMER(SET AUTO POWER OFF) FF/FR SCAN SPEED The fast scan speed can range from 1x/2x/ 4x/6x. SLEEP POWER OFF : Automatically turns power off after a fixed recording quality time. (Time range can be set from 0 to 180 minutes by a minute) SOUND BALANCE Balance your sound to the right or left or keep it in Use the...
- Page 30 TUNER RECORDING MODE MODE(PLAYBACK MODE) You can adjust recording quality when TUNER RECORDING MODE MONO STEREO recording Tuner. 32KHz Bit Rate : 8Kbps~320Kbps 128KBPS REPEAT MODE / SHUFFLE MODE (Page 46~47) Sampling Frequency : 8KHz ~44.1KHz : A number of Repeat and Shuffle modes are available. Select the one you want by pressing MODE button(Multi selecting available) LINEIN RECORDING MODE You can adjust recording quality when...
-
Page 31: Inserting A Battery
INSERTING A BATTERY USER EQ Open the battery cover. Insert the battery. USER EQ You can adjust sound according to your liking Be sure to match the + and - ends of the battery with the There are 5 band frequency steps, set from - diagram inside the battery 12dB to +12dB by 3dB step. - Page 32 Should any problem persist after you have checked these symptoms, consult SAFETY your iRiver dealer or contact support at iRiver.com. Vibration experienced during walking or exercising will not affect the player. Check whether the batteries have been inserted in However, dropping the player or dropping a heavy object on the player may result in properly.
- Page 33 Earphone/ Installation CD USB cable Earphone sponge Memory 128MB 256MB 512MB Model No iFP-390T iFP-380T iFP-395T Memory is not upgraded. Category Specifications ITEM User Manual/ Battery(AA type 1EA) Neck strap for FM Frequency range 87.5 MHz ~ 108 MHz Warranty card...
- Page 34 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
