- Page 1 Instruction Manual MP3 PLAYER / FM TUNER (Option) Model iFP-100 Series Model iFP-100 Thank you for purchasing the product. Please read this manual carefully before use. Limited http://www.iRiver.com...
- Page 2 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICES MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE, RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUS E UNDERSIRED OPERATION.
- Page 3 You can easily listen FM broadcast by using Auto Preset, Frequency Memory iRiver is a registered trademark of iRiver Limited in the Republic of Korea and and various function. /or other countries and is used under license. Microsoft Windows Media and...
-
Page 4: Table Of Contents
Contents CONTROLS FRONT VIEW 1. CONTROLS Front View, Side View 1................... Side View 2, Up/Downside View..............Neck Strap Volume + LCD Windows LCD Window....................2. BASIC OPERATION Listening to music.................... Playing FM Tuner.................... 10~13 Recording FM....................Recording Voice....................15~16 3. Useful Features Installing Software on PC................ -
Page 5: Lcd Window
CONTROLS CONTROLS SIDE VIEW 2 LCD Window Hold PLAYBACK MODE PLAY TIME HOLD TRACK NUMBER BATTERY LEVEL FOLDER NAME SINGER/MUSIC NAME UP/DOWNSIDE VIEW VOLUME EQUALIZER PROGRESSIVE BAR/ USB Connection Port BIT RATE Battery Compartment FILE FORMAT PROGRESSIVE/ Earphone SAMPLE RATE FREE SPACE... -
Page 6: Listening To Music
LISTENING TO MUSIC LISTENING TO MUSIC Connect the earphones as below. Turn the power of the player on . Press PLAY/MENU button to play. To Play/Pause To play next folder To change source Put the HOLD switch to “OFF”. To select music (MP3 Voice recording) To play previous folder... -
Page 7: Playing Fm Tuner
PLAYING FM TUNER PLAYING FM TUNER While Playing CD, Press MODE/REC button. Selecting Frequency(FM 87.5MHz ~ 108MHz) To change frequency, push the shortly. (ex : 87.5 87.6) Function selection picture displays on the LCD. Push I I button to select FM RADIO. Auto Scan function: To select memorized channel, press the Navi/Menu Press NAVI/MENU or PLAY/STOP button to confirm. - Page 8 PLAYING FM TUNER PLAYING FM TUNER Memory Function (Save channels) Memory delete function (Delete saved channels) Select channel to be deleted at preset mode. Select the channel by pressing the I I button. Push memory button for a long time. Press I and select the again...
-
Page 9: Recording Fm
RECORDING VOICE RECORDING FM Press MODE/REC button for a long Press I I button to Voice To record FM time. mode. Press [MODE/REC] button during FM receiving. To stop FM recording Press [MODE/REC] button once more, recording is completed. Press NAVI/MENU button(or Press MODE/REC button once more. -
Page 10: Recording Voice
You can upgrade the Operating System of the player by downloading from the Recorded file is saved as form of VOICE001.WAV. internet.(Log on to www.iriver.com or www.iriveramerica.com) System Requirements If displayed 00:00:00 on the LCD, the memory of the player is full. -
Page 11: Installing Software On Pc
INSTALLING SOFTWARE ON PC INSTALLING SOFTWARE ON PC To install “New hardware” The following picture appears when Select “iRiverDriver folder to Install. Connect the USB cable(Provided) to the USB port of your computer. connecting the USB cable. Click “OK”. Type “A” : USB port on the Panel of PC Type “B”... -
Page 12: Installing Software On Pc
Select the folder to Install. Click “NEXT”. Complete the installation of “New Click “NEXT”. hardware”. Generally assigned as “C Driver Program File iRiver iRiver- Manager To install Manager program Click “Finish” Click “SETUP.EXE” in the ifp-Eng Click “NEXT”. Complete the installation of “Manager”. -
Page 13: Basic Operation
BASIC OPERATION BASIC OPERATION BASIC OPERATION When using Navigation Volume Control: Slide jog lever to the upward or to the downward. When using Menu Changing FM Mode : (Refer p10) FM Changing : 1. LCD windows. 2. To select the previous music or station for MP3 or FM. 3. -
Page 14: Navi/Menu
NAVIGATION BASIC OPERATION MENU NAVIGATION is the function to search track. Long press of NAVI/MENU will execute menu function. You can find the desired song by pressing NAVI/MENU button and using VOL +, VOL - buttons. Shifting between menus : Press I Exit : Press VOL - button or long press NAVI/MENU button. - Page 15 NAVIGATION DELETING FOLDER ON THE PLAYER To delete folder Select the track Select the track Stop playback. Click NAVI/MENU Select folder to delete. button. Select the track Click MODE button. are you sure? is displayed on the FILE DELETE DELETING FILES ON THE PLAYER LCD.
-
Page 16: Program Mode
PROGRAM MODE MODE REPEAT Program mode: Play tracks in your favorite order. Play a single track repeatedly. Play whole tracks in the folder and stop. Activating Program mode Play whole tracks in the folder repeatedly. At stop mode Play whole tracks in the disk repeatedly. SHUFFLE Randomly play whole tracks in the disk repeatedly and stop. -
Page 17: Eq Mode
PROGRAM MODE EQ MODE Program play EQ MODE After programming, press to play the tracks in sequential order. Program mode icon appears Cancel Program Mode Long click of MEMORY/EQ button displays the current EQ. While in Stop Mode Every time you click this button, the EQ mode shifts in sequential order. Interval Repeat Play selected interval repeatedly Note: Please refer to the Function Control (Page 41) for configuring... - Page 18 MENU (FUNCTION CONTROLS) MENU Menu Operation Function Control is subject to change with different firmware versions. Users MAIN MENU can configure their own settings. Pressing NAVI/MENU button will show Configuration you the figures. It is composed of 6 main menus with submenus. SUB MENU When you select the sub menu window, you can set the user's preference to be displayed.
- Page 19 MENU MENU(GENERAL) GENERAL Enter Sub Menu BEEP VOL : Configure beep sound (ON/OFF) with volume level. Each control option is configured RESUME by three buttons shown below. : When activated, player returns to the same settings after STOP or Power OFF. FADE IN : When activated, volume increases Exit Sub Menu...
- Page 20 MENU(General & Display) MENU(DISPLAY) VISUALIZATION LOAD DEFAULT VALUE : Initialize to original factory setting. : Visualize audio signal at play mode, elapsed button operation order is as below. time of playing track or free space of memory. (select default menu) (select YES) (select YES : Initialization)
- Page 21 MENU(CONTROL) MENU(TIMER & CONTROL) TIMER(Set Auto Power Off) SCAN SPEED The fast scan speed can range from 1x/2x/ SLEEP POWER OFF 4x/6x. It is useful when studying a : Automatically power off after fixed time language. (Time range can be set from 0 to 99 minutes by minute) SCROLL SPEED button to adjust time.
- Page 22 MENU(PLAYBACK MODE) MENU(USER EQ) MODE Menu (User EQ) REPEAT MODE / SHUFFLE MODE (Page 27~28) BASS BOOST : Available with multiple section, selected modes are activated on mode : Bass Boost lever is from 0 to 24dB. operation. Pressing button to enter TREBLE BOOST : Treble boost level is from o to 6dB.
-
Page 23: Initializing/ Making New Folder/Refresh
INITIALIZING/ MAKING NEW FOLDER/REFRESH DOWNLOADING FROM THE PC Activate Manager program after connecting USB cable between the player and PC. Double Click the Manager Double Click the Manager icon on Click format icon or select “format” the PC windows to operate Manager icon on the PC windows. - Page 24 DOWNLOADING FROM THE PC UPLOADING/ LISTENING MP3 ON THE PC Activate Manager program after connecting USB cable between the player and PC. Click Downpload icon or select Downpload in Double Click the Manager the Transmission menu to download. icon on the PC windows. Select folder to be saved in the PC.
-
Page 25: Deleting Files On The Pc
UPLOADING/ LISTENING MP3 ON THE PC DELETING FILES ON THE PC Activate Manager program after connecting USB cable between the player and PC. Click Upload icon or select Upload in the After starting the Manager program, Transmission menu to upload. select files to delete. -
Page 26: Power Supply(Battery)
POWER SUPPLY(BATTERY) TROUBLE SHOOTING Should any problem persist after you have checked these symptoms, consult your Inserting a battery iRiver dealer. Open the battery cover. Insert the batteries. Be sure to match the + and - ends Check whether the batteries have been inserted in of the batteries with the diagram proper polarity. -
Page 27: Precautions
PRECAUTIONS ACCESSORIES Earphone/Earphone sponge USB cable Safety Vibration experienced during walking or exercising will not affect the player. However, dropping the player or dropping a heavy object on the player may result in damage or sound distortion. Avoid falling any liquid into the player. If water or any other liquid enters the case, take this unit to an authorized service center for inspection. -
Page 28: Specification
SPECIFICATION Distributing copies of MP3 tracks without permission is a violation of international copyright laws. iFP-120 iFP-140 iFP-180 Memory 32 MB 64 MB 128 MB Color White Pearl Bright Silver Gun Metal Color Code MA8288 MA8287 MC9905 ith FM Tuner...
