CAT5 4X
Extender
EXT-HDMI-CAT5-4X
User Manual
www.gefen.com
f

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDMI-CAT5-4X and is the answer not in the manual?

Questions and answers

Summary of Contents for Gefen HDMI-CAT5-4X

  • Page 1 CAT5 4X Extender EXT-HDMI-CAT5-4X User Manual www.gefen.com...
  • Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. HDMI CAT5 4X Extender is a trademark of Gefen Inc.
  • Page 3: Table Of Contents

    Introduction Operation Notes Features Sender Panel Descriptions Receiver Panel Descriptions Connecting And Operating The Hdmi Cat5 4x Extender Manual Equalization Procedure Dip Switch Location Diagram Network Cable Wiring Diagram 10 Rack Mount Installation 11 Mounting Plate Installation 12 Specifi cations 13 Warranty CONTENTS...
  • Page 4: Introduction

    Congratulations on your purchase of the HDMI CAT5 4X Extender. Your complete satisfaction is very important to us. Gefen Gefen delivers innovative, progressive computer and electronics add-on solutions that harness integration, extension, distribution and conversion technologies. Gefen’s reliable, plug-and-play products supplement cross-platform computer systems, professional audio/video environments and HDTV systems of all sizes with hard-working solutions that are easy to implement and simple to operate.
  • Page 5: Operation Notes

    READ THESE NOTES BEFORE INSTALLING OR OPERATING THE HDMI CAT5 4X EXTENDER • HDMI CAT5 4X Extender and HDMI CAT5 MSR units are housed in a metal box for better RF shielding. • The maximum cable extension is 300 feet (91 meters) for video resolutions of 1080i and below.
  • Page 6: Features

    Features • Easily distribute four HDMI sources to four remote HDMI displays • Extends video signals up to 300 feet over CAT-5, CAT-5e or CAT-6 network cable • Maintains 1920 x 1200, 1080p, and 2k resolution video Package Includes (1) 4x HDMI CAT5 Sender (4) HDMI CAT5 MS Receivers (4) 6 Foot HDMI Cable (M-M) (4) 5V Dc Power Supply...
  • Page 7: Sender Panel Descriptions

    SENDER PANEL DESCRIPTIONS...
  • Page 8: Receiver Panel Descriptions

    RECEIVER PANEL DESCRIPTIONS Front Panel HDMI Output 5V DC Power input EQ trim pot Power LED Indicator Back Panel DDC RJ-45 Port VIDEO RJ-45 Port...
  • Page 9: Connecting And Operating The Hdmi Cat5 4X Extender

    CONNECTING AND OPERATING THE HDMI CAT5 4X EXTENDER How to Connect the HDMI CAT5 4X Extender Connect your sources (up to four) to the HDMI CAT5 4X Extender unit’s HDMI inputs using the supplied HDMI cables. Connect your displays (up to four) to the HDMI CAT5 MSR receiver unit’s HDMI outputs using user supplied HDMI cables.
  • Page 10: Manual Equalization Procedure

    MANUAL EQUALIZATION PROCEDURE The HDMI CAT5 4X Extender and HDMI CAT5 MSR receiver units both have sets of dip switches located on the underside of their casings. There is a piece of silver metallic tape that must be removed to expose these dip switches. The HDMI CAT5 4X Extender unit carries 4 banks of 4 dip switches.
  • Page 11: Dip Switch Location Diagram

    DIP SWITCH LOCATION DIAGRAM HDMI CAT5 4X Extender FRONT Remove Tape Boost Dip Switches HDMI CAT5 MSR Equalization Trim Pot Remove Tape Auto EQ Dip Switches...
  • Page 12: Network Cable Wiring Diagram

    Gefen has specifi cally engineered their products to work with the TIA/EIA-568-B specifi cation. Please adhere to the table below when fi eld terminating cable for use with Gefen products. Failure to do so may produce unexpected results and reduced performance.
  • Page 13: Rack Mount Installation

    RACK MOUNT INSTALLATION Rack mount ears are provided for installation of this unit into a 1U rack mount space. Locate the side screws on the unit. Remove the front 2 screws that are located closest to the front of the unit. Using the removed screws, screw the rack mounting bracket into the unit.
  • Page 14: Mounting Plate Installation

    MOUNTING PLATE INSTALLATION Mounting Plate Installation Remove the rubber feet covering the screws off the bottom of the unit. Remove the screws. Line up the mounting plates and screw it on to the unit.
  • Page 15: Specifications

    SPECIFICATIONS Video Amplifi er Bandwidth ...4 x 165 MHz Input Video Signal ... 1.2 Volts p-p Input DDC Signal ... 5 Volts p-p (TTL) Single Link Range ...1080p / 1920 x 1200 HDMI Connector Type ... Type A 19 Pin Female Link Connector ...
