Summary of Contents for CHIEF RSM A-D
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S RSM Elite Series Projector Mounts RPA Elite Series Projector Mount RPA Elite Series Projector Mount RPA Elite Series Projector Mount RPA Elite Series Projector Mount RPA Elite Series Projector Mount RPA Elite Series Projector Mount RSM A-D...
-
Page 2: Important Safety Instructions
• mounted to double 2" x 4" wood stud cross bracing (1-1/2" on center) between two 2" x 4" ceiling joists; Chief® is a registered trademark of Milestone AV Technologies. with a maximum drywall covering of 5/8". All rights reserved. -
Page 3: Installation Instructions
Installation Instructions RSM Elite Series Projector Mounts DIMENSIONS 57.8 40.9 2.28 1.61 BOLT CIRCLE 55.4 2.18 40.9 110.9 1.61 4.37 INTERFACE LOCKING SWITCH THREADS ONTO 1-1/2' NPT PITCH ADJUSTMENT POINT YAW ADJUSTMENT POINT 128.7 5.07 46.4 1.83 ROLL ADJUSTMENT POINT NOTE: CUSTOM INTERAFCE BRACKET NOT SHOWN. - Page 4 RSM Elite Series Projector Mounts Installation Instructions LEGEND Pencil Mark Tighten Fastener Marquage au crayon Serrez les fixations Segno a matita Serrare il fissaggio Stiftmarkierung Befestigungsteil festziehen Marcar con lápiz Apretar elemento de fijación Potloodmerkteken Bevestiging vastdraaien Marcar com lápis Apertar fixador Drill Hole Loosen Fastener...
-
Page 5: Tools Required For Installation
Installation Instructions RSM Elite Series Projector Mounts LEGEND Hammer Target of Projector Punto de enfoque del proyector Martillo Ziel des Projektors Hammer Mira do projector Martelo Martello Punto di proiezione Doel van de projector Hamer Cible du projecteur Marteau TOOLS REQUIRED FOR INSTALLATION 7/16"... - Page 6 RSM Elite Series Projector Mounts Installation Instructions RSM INSTALLATION (not included) NOTE: Models RSM-A/RSM-B/RSM-C/RSM-D are identical EXCEPT each provides a different keyed lock. Threaded Pipe Installation Carefully determine required mounting location. IMPORTANT ! : This will require knowing the (not included) lens to screen distance.
-
Page 7: Wood Stud Installation
Installation Instructions RSM Elite Series Projector Mounts INSTALLATION Wood Stud Installation Carefully determine required mounting location. IMPORTANT ! : This will require knowing the lens to screen distance. See projector specifications for details on determining this distance. WARNING: IMPROPER INSTALLATION CAN RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! Structural members MUST be capable of supporting five times the... -
Page 8: Concrete Installation
RSM Elite Series Projector Mounts Installation Instructions Concrete Installation Determine mounting location. WARNING: The RSM is designed to be mounted to a concrete ceiling with a minimum thickness of 8" and a maximum drywall covering of 5/8". WARNING: IMPROPER INSTALLATION CAN RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! Structural members MUST be capable of supporting five times the combined weight... -
Page 9: Projector Installation
NOTE: Hole in the RSM allows socket wrench access without unit disassembly. PROJECTOR INSTALLATION IMPORTANT ! : Model RSM uses optional Chief "SSM" Series interface brackets. (See Parts drawing.) Install Interface Bracket Partially thread thumb nuts onto Phillips screws until screw end is visible in top of thumb screw. - Page 10 RSM Elite Series Projector Mounts Installation Instructions Example Only (Interface bracket varies dependent WARNING: IMPROPER INSTALLATION CAN on projector model) LEAD TO PROJECTOR FALLING RESULTING IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT. DO NOT substitute hardware. Use only the hardware provided by the manufacturer. Secure interface bracket to mount using installation instructions and hardware provided with interface bracket.
- Page 11 Installation Instructions RSM Elite Series Projector Mounts Securing Projector with Interface Bracket to Model RSM Mount Example Only (Interface bracket varies dependent on WARNING: IMPROPER INSTALLATION CAN projector model) LEAD TO PROJECTOR FALLING RESULTING IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT.
-
Page 12: Pitch Adjustment
Installation Instructions RSM Elite Series Projector Mounts Example Only ADJUSTMENTS (Interface bracket varies dependent YAW Adjustment on projector model) Loosen YAW adjustment locking screw using a #2 Phillips screwdriver. Turn YAW micro-adjustment screw right or left using a #2 Phillips screwdriver until image is properly aligned on target. -
Page 13: Roll Adjustment
RSM Elite Series Projector Mounts Installation Instructions Roll Adjustment Loosen ROLL adjustment locking screw using a #2 Phillips screwdriver. Turn ROLL micro-adjustment screw right or left using a #2 Phillips screwdriver until image is properly aligned on target. Example Only (Interface bracket Tighten ROLL adjustment locking screw using a varies dependent... - Page 14 RSM Elite Series Projector Mounts Installation Instructions...
- Page 15 Installation Instructions RSM Elite Series Projector Mounts...
- Page 16 F 877.894.6918 / 952.894.6918 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 Chief Manufacturing, a products division F +31 (0) 495 580 845 of Milestone AV Technologies Asia Pacific A Office No. 1 on 12/F, Shatin Galleria...
