- Page 1 DIGITAL SATELLITE RECEIVER ESR-D101 INSTRUCTION MANUAL...
- Page 2 SATETY INSTRUCTION Please read the following instructions carefully Do not overload the following wall outlets, extension cords or integral convenience receptacles as this can result in a risk of fire or electrical shock Never allow liquids, spray or other materials to come into contact with the inside of the STB. Unplug the STB from the wall outlet before cleaning.
-
Page 3: Front Panel
FRONT PANEL REAR PANEL... - Page 4 REMOTE CONTROLLER KEYS Advice operates each function of the STB by using the button on the remote controller. Please read this section to help advance your understanding of the function of the STB. Non-menu: to mute the audio output To instruct the unit to enter standby mode Non-menu: to select the favorite installed channel Non-menu: to show satellite list Menu mode: to select or adjust the parameter...
-
Page 5: Precautions About Batteries
Non-menu: to shift from present channel to the last one To enter the timer edits function To select the TV or radio mode Non-menu: to show the stored channel list, menu mode: to confirm the operation Non-menu: to show the present channel’s information Non-menu: to enter Game interface Non-menu: to pause the active image and press twice recover the active image... -
Page 6: System Connection
SYSTEM CONNECTION Connect the AUDIO, VIDEO, and Scart output terminals with the corresponding terminals of TV set. Adjust the direction of the dish according to the antenna signal level display on the screen. Connect F terminal to both ends of the cable, one end to LNB of satellite antenna and the other end to “SAT IN”... - Page 7 MENU TREE...
-
Page 8: Installation
INSTALLATION Press the MENU key in non-menu mode and the image shows as Move the cursor to the Installation menu strip and press the OK key, the image shows as: Press the OK key to enter the lighting satellite name and the interface shows its transponders as: Press the red key and ¡ø¨‹... - Page 9 Press the MENU key to return to the Select Satellite interface, press the red key and ¡ø¨‹ key to select one or more the satellites and press the blue key to enter the Satellite interface ( right side) to scan the chosen satellite or satellites Move the cursor to the Satellite strip, press the +/- key to select the chosen satellite (when have selected more than...
- Page 10 and whether the lock light lights up simultaneously. Light the sixth strip; press the +/- key to switch the status between “ o n” and “ o ff”, press the OK key to enter the motor interface when the “on” status is chosen and the interface shows as Light the seventh instruction strip;...
-
Page 11: User Setup
suitable situation by itself Press the MENU key to return to the Satellite interface to start the scan, there four modes to search the satellite channels, they are: Auto, TP, FTA, NIT. In which: Auto: to scan all the channels in the selected satellite name. TP: to scan the channels which in the chosen transponder FTA: to scan the channels, which are, belong to the free to NIT: to scan the channels, which are, belong to the network... -
Page 12: Local Time Setting
LOCAL TIME SETTING Light the Local Time Setting and enters its sub-menu: GMT: the Greenwich Meantime-central Europe time Selected time zone: to choose the appropriate location Summer time: daylight saving time Time offset: to modify the time What the Current Time appears is the synchro-time which is sent by the satellite signal A/V OUTPUT SETTING Light the A/V Output Setting menu strip and enters... -
Page 13: Edit Tv Channel
EDIT TV CHANNEL Light Edit TV Channel and enters its interface: Press the green key repeatedly to change the mode and which will be shown on the yellow strip correspondingly, the status includes: MOVE, FAV OR1-4, SORT, DELETE 1. Move: when the yellow strip shows the “move” character, press the yellow key, press the ¡ø¨‹... - Page 14 Change: press the yellow key, the picture shows: Light the Satellite strip and press the OK key to enter the soft-keyboard interface: Use the ¡ø¨‹, +/ - key to move the cursor and the OK key to confirm the input Use CAPS instruction to switch the letter state between capital and miniscule Use NUM instruction to switch the mode from letter to digit...
-
Page 15: Edit Transponder
channel name which operation just as above-mentioned about soft-keyboard introduction. Light the Video PID, Audio PID, and PCR instruction strip and press the digital keys to input the correct value, Add: r e turn to the Edit Satellite interface and press the blue key, the picture shows as: Press the OK key to spring out the soft-keyboard to define the satellite name, finish the definition, input... -
Page 16: Lock Setup
LOCK SETUP Return the interface to the Main Menu, light the Lock Setup menu strip and the image shows: Light the Change PIN instruction strip and press the OK key to enter its interface To realize create one new private code by this instruction: the default or primary code is “... -
Page 17: Advanced Setting
from standby or power-on status needs the code input Lock Edit & Installation: move the cursor to the fifth instructi -on strip, press the +/- key to switch the receiver mode betwee -n locked and free, when the mode is locked, enter the sub-m -enu of Installation, Edit, etc. - Page 18 TIMER Press the blue key in either non-menu or Main Menu interface, the interface enters TIMER function, the image shows as The strip on the top shows the present date and time which are sent by satellite Press the digital keys directly t o modify the showing date and time, hereinto: Input 12 digits is to modify either the date or the time Input 8 digits is to modify the date only...
-
Page 19: Telephone Directory
TELEPHONE DIRECTORY Either in non-menu mode to press the TEL key or MAIN MENU to press the green key, the interface enters the Telephone directory one Press the green key to add the telephone list, and instead the red key to remove which. Press the +/-, ¡ø¨‹... -
Page 20: Specification
SPECIFICATION Tuner Input Frequency 950 ~ 2,150 MHz Signal Level -25dBm ~ -65dBm (75 ) LNB Control DiSEqC1.0/ 22KHz LNB Power & Polarization 13V/18V (Max. 400mA) Channel Decode Demodulation QPSK (SCPC, MCPC) Input Symbol Rate 2~30MSPS Video Profile Level MPEG-II MP@ ML Output System NTSC / PAL Output Terminal...
