DRAKE AUDIOACCENT Instruction Manual

Assistive listening system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TM
AudioAccent
Assistive Listening System
Contains an ALT 1000 Assistive Listening Transmitter
(with Limiter and Compression)
and 4 Model MR306 FM Receivers
Instruction Manual
TM
Creating Sound Solutions for Easy Listening

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUDIOACCENT and is the answer not in the manual?

Questions and answers

Related Manuals for DRAKE AUDIOACCENT

Summary of Contents for DRAKE AUDIOACCENT

  • Page 1 AudioAccent Assistive Listening System Contains an ALT 1000 Assistive Listening Transmitter (with Limiter and Compression) and 4 Model MR306 FM Receivers Instruction Manual Creating Sound Solutions for Easy Listening...
  • Page 3 Important Safeguards WARNING: TO PREVENT FIRE OR 12. Power Lines—An outside antenna system should not be located in the vicinity of ELECTRICAL SHOCK DO NOT EXPOSE overhead power lines, other electric light or power circuits, where it can fall into such THIS PRODUCT'S AC ADAPTER TO RAIN OR MOISTURE power lines or circuits.
  • Page 4 This page left intentionally blank...

  • Page 5: Table Of Contents

    Table of Contents Also included with the system are (3) three Thank you for purchasing an AudioAccent Assistive Listening System. This product has been designed and AudioAccent Assistive Listening System decals. manufactured to high quality standards, and will provide These decals can be posted to inform people that a reliable operation for many years.

  • Page 6: Specifications / Options And Accessories

    Specifications / Options and Accessories SPECIFICATIONS: Ultimate S/N Ratio (with Drake Model MR306 Frequency Coverage: 72.1 to 72.9 MHz, receiver): Greater than 60 dB, 74.7 MHz, and monaural 75.3 to 75.9 MHz. Greater than 55 dB, stereo Frequency Selection: Selectable by front panel Total Harmonic Distortion: Less than 0.25%, typical.

  • Page 7: Introduction - General Description

    Introduction - General Description The ALT 1000 is a wideband FM Listening System which The Assistive Listening System has two principal parts: operates in the 72 - 76 MHz frequency band. Designed the ALT 1000 Assistive Listening Transmitter, and the for hearing assistance in places of public access, the MR306 FM Receivers.

  • Page 8: Front Panel Controls And Indicators

    Front Panel Controls and Indicators ALT 1000 ASSISTIVE LISTENING TRANSMITTER LEVEL OVER MODULATION TUNE MONITOR OUTPUT MONIT OR I NPUT 72.1 MHz Stereo LEFT R I G H T F R E QU EN C Y 1. MONITOR OUTPUT - Connect headphones to listen 5.

  • Page 9: Rear Panel Controls And Connections

    Rear Panel Controls and Connections M AD E I N U. S. A. G N D L E F T A U D I O R I G H T A U D I O F C C I D : C A R 1 0 0 2 4 3 4 H IG H R F O U T P U T I N P U T...

  • Page 10: Installation

    Installation SETUP and OPERATION If the optional magnetic-mount antenna is more appropriate, contact your dealer or the R.L. Drake Locating the ALT 1000 Company. The magnetic-mount antenna installation Prior to connection and adjustments, decide on a and placement is detailed on page 5 of this manual. location for the ALT 1000 that will provide a reliable signal to the receivers throughout the intended listening 2.
  • Page 11 Installation, continued Strain Relief M A D E I N U . S . A . R F O U T P U T - E X T. A N T E N N A - D C I N P U T P O W E R O F F 1 2 V D C...

  • Page 12: Operating The Mr306 Receiver

    Operating the MR306 Receiver 1. Phone Jack 2. Power ON/OFF Switch 3. Volume Control 4. FM MONO Stereo Switch 5. Key LOCK Switch LOCK PRESET 6. TUNING Buttons 7. Memory Indicator 8. Key Lock Indicator digital 9. FM Stereo Indicator receiver 10.
  • Page 13 Operating the MR306 Receiver, continued PRESET TUNING SUGGESTIONS FOR RECEIVER MANAGEMENT Once the desired frequencies are stored in the preset Different types of facilities will use varied approaches buttons (13), they can easily be recalled. for receiver management and earphone sanitation. The following includes some options that customers have To store a station into memory, use the following used successfully:...

  • Page 14: Service Information / If You Need To Call For Help

    Service Information / If You Need To Call For Help SERVICE INFORMATION Should you want to return your unit for service, package You may contact R.L. DRAKE Service Department for the receiver carefully using the original carton or other additional information or assistance by calling suitable container.

  • Page 15: Warranty

    Warranty Three Three Three Y Y Y Y Y ear Limited ear Limited ear Limited ear Limited W W W W W arranty arranty arranty arranty Three Three ear Limited arranty R.L. DRAKE COMPANY warrants to the original purchaser this product shall be free from defects in material or workmanship for three (3) years from the date of original purchase.
  • Page 16 R.L. DRAKE COMPANY 230 INDUSTRIAL DRIVE FRANKLIN, OHIO 45005 U.S.A. CUSTOMER SERVICE AND PARTS TELEPHONE: +1 (937) 746-6990 TELEFAX: +1 (937) 743-4576 WORLD WIDE WEB SITE: http://www.rldrake.com ® is a registered trademark of the R. L. Drake Company P/N: 3852434G-8-2001 ©...
