- Page 1 DIGITAL TERRESTRIAL RECEIVER ESR-T121...
-
Page 2: Table Of Contents
CONTENT Safety Instruction..........................1 Front Panel.............................2 Rear Panel............................2 Remote controller ...........................3 System Connection.........................5 Power On ............................5 Menu Tree ............................6 Scan ...............................7 Setting ............................8 Channel............................13 Favorite ............................13 EPG..............................14 Specification..........................15... -
Page 3: Safety Instruction
SAFETY INSTRUCTION Please read the following instructions carefully Do not overload the following wall outlets, extension cords or integral convenience receptacles as this can result in a risk of fire or electrical shock Never allow liquids, spray or other materials to come into contact with the inside of the STB. Unplug the STB from the wall outlet before cleaning. -
Page 4: Front Panel
FRONT PANEL Card slot (spare) Standby switch EXIT: return to the program-watching status Volume decrease/ left button MENU: Menu entry Channel increase/ up button OK: menu confirmation/ channel list Volume increase/ right button Remote receiver Channel decrease/ down button LED display window REAR PANEL Power switch S-VIDEO terminal... -
Page 5: Remote Controller
REMOTE CONTROLLER KEYS Advice you operate each function of the STB using the button on the remote controller. Please read this section to help advance your understanding of the function of the STB To mute the audio output To instruct the unit to enter standby mode Non-menu: To show the favorite type Non-menu: to switch the STB TV Scart signal source from the STB or the VCR... -
Page 6: Precautions About Batteries
Non-menu: to switch the output audio language category Non-menu: to switch the watching state from TV to Radio Non-menu mode: to show the stored channel list; menu mode: to confirm the operation PRECAUTIONS ABOUT BATTERIES Improper use of batteries may cause corrosion or fluid leakage. Please observe the following instructions for the safe use of batteries 1. -
Page 7: System Connection
SYSTEM CONNECTION Connect the AUDIO, VIDEO, SPDIF and Scarts output terminals with the corresponding terminals of Television or Amplifier Connect the antenna signal cable terminal to the RF IN signal terminal of the device and ensure the connection is tight Connect the RF OUT signal terminal of the device to the RF input terminal of the Television to realize the loop watching The RS 232 serial data interface is used to update the software version and enrich the database of this... -
Page 8: Menu Tree
MENU TREE... -
Page 9: Scan
SCAN Press the MENU key to the device and the screen shows the picture as: Put the cursor on the Scan instruction and force down the OK key to enter the submenu interface Three built-in software types of scanning: Auto Scan, Manual Scan and NIT Scan, Please ask for the numerical value along with the Band width from the local television station... -
Page 10: Setting
SETTING Press the MENU key to spring out the instruction bar; put the cursor on the Setting instruction and force down the OK key to enter its sub interface and which shows as Put the cursor on the first instruction and enter whose submenu, which shows as Press the ▼... - Page 11 whether to cancel the channel, press the OK key to remove or the EXIT key to forgo Rename: pitch on one the channel name then press the yellow key to show the soft-keyboard to rename the channel name. The image and usage of soft-keyboard are as follows: Press the yellow key to switch the letters from capital and small letter, Use...
- Page 12 Standard: to choose the suitable display system Audio Output: to choose the suitable audio system Put the cursor on the Time Setting instruction to enter its submenu and the picture shows as Time zone: to select the right time zone refer to the GMT area according to the location you inhabiting Current Time: to show the current time that...
- Page 13 *.exe program upgrade.exe Open the setup menu and select the correct serial interface that using on your computer (as the illustration serial COM 1 is illustrated); Press the OK character to pitch on the COM1 Force down the icon UPGRADE to spring out the window with words “...
- Page 14 Box to box: do not connect the serial cable firstly. To pitch on the instruction of Box to Box in the menu of Software Upgrade, define one the box that has higher version software as the master and the other as the slave;...
-
Page 15: Channel
CHANNEL Put the cursor on the Channel instruction strip to enter its submenu TV Channel: press the OK key to enter the sub interface to show the TV channel list, use ▼ key to pitch on one the channel item, force down the red key to add one the “lock”... -
Page 16: Epg
channel to this favorite?”, press the OK key to add the present channel to the News type or the EXIT key to cancel To show the related information of the playing channel program Press the red key to show the current information title and instead the green key to show the next information title Press the yellow key to read the particulars... -
Page 17: Specification
SPECIFICATION Tuner UHF 470 MHz ~ 862 MHz Input Frequency VHF 174 MHz ~230 MHz RF Input Level -78dBm ~ -20dBm (75Ω) RF Input connector IEC type Female RF Output connector IEC type Male Nominal input impedance 75 ohm Electronic tuning, PLL synthesizer Channel selection system Step frequency 166.67KHz... - Page 18 PACKING LIST ITEMS Qty. REMARK DIGITAL TERRESTRIAL RECEIVER INSTRUCTION MANUAL REMOTE CONTROL AV CABLE NOTE: Any changes will not be noticed in advance. Our company reserves the rights for the explanation of the discrepancy...
