User's
Manual
YFGW610
Field Wireless Media Converter
IM 01W02D02-01EN
IM 01W02D02-01EN
1st Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YFGW610 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for YOKOGAWA YFGW610

  • Page 1 User’s Manual YFGW610 Field Wireless Media Converter IM 01W02D02-01EN IM 01W02D02-01EN 1st Edition...
  • Page 2 Blank Page...
  • Page 3: Table Of Contents

    YFGW610 Field Wireless Media Converter IM 01W02D02-01EN This document contains important information for using YFGW610 Field Wireless Media Convert- er properly and safely. Please read this document thoroughly before using this product. The configuration of the field wireless system is described in the User’s Manual of YFGW410 Field Wireless Management Station (IM 01W02D01-01EN);...
  • Page 4 B3.1 Mounting Direction ..................B3-1 B3.2 Mounting of DIN Rails ..................B3-2 B3.3 Installation of YFGW610 ................B3-3 Power, ground, and network cable connection ........B4-1 B4.1 Connection Terminals and Communication Interface ....... B4-1 B4.2 Power Supply Cable Connection ..............B4-2 B4.3...
  • Page 5: Introduction

    No part of this manual may be reproduced in any form without Yokogawa’s written permission. The contents of this manual may be changed without prior notice.
  • Page 6: Safety Precautions

    If any protection or safety circuit is required for the system controlled by the product or for the product itself, prepare it separately. Be sure to use the spare parts approved by Yokogawa Electric Corporation (hereafter simply referred to as Yokogawa) when replacing parts or consuma- bles.
  • Page 7 <Read Me First> IMPORTANT Indicates important information required to understand operations or functions. NOTE Draws attention to information essential for understanding the operation and features. Indicates additional information.Indicates additional information. Indicates a reference source. ALSO Indicates a protective grounding terminal. Before using the product, ground the terminal. Indicates a functional grounding terminal.
  • Page 8 Yokogawa shall have neither liability nor responsibility to any person or entity with respect to any direct or indirect loss or damage arising from using the product or any defect of the product that Yokogawa can not predict in ad- vance.
  • Page 9: Copyright And Trademark Notices

    Trademark Acknowledgments • CENTUM, PRM, FieldMate, STARDOM and VigilantPlant are either trademarks or regis- tered trademarks of Yokogawa. • Ethernet is a registered trademark of XEROX Corporation. • All other company and product names mentioned in this User’s Manual are trademarks or registered trademarks of their respective companies.
  • Page 10: Information Of User's Manual Revision

    <Read Me First> Information of User’s Manual Revision Material Name : YFGW610 Field Wireless Media Converter Material Number : IM 01W02D02-01EN Edition Date Page Revised Item 1st Edition September 2012 New Issue IM 01W02D02-01EN...
  • Page 11: Part-A

    Read the User’s Manual (IM 01W02D01-01EN) of YFGW410 Field Wireless Management Sta- tion (hereafter simply referred to as YFGW410) before this manual. YFGW610 Field Wireless Media Converter (hereafter simply referred to as YFGW610) converts the signals between 100BASE-TX (metal network cable) and 100BASE-FX (optical network ca- ble) and is used when the wiring between the Field Wireless Management Station and the Field Wireless Access Point is placed outdoors or covers a long distance.
  • Page 12: A2. System Configuration

    Access Point (YFGW510) Field wireless device FA0201 Figure A2-1 Example of system configuration YFGW610 is installed near YFGW410 in the field wireless backbone, and converts the optical network connection of YFGW510 to the metal network connection for YFGW410. IM 01W02D02-01EN...
  • Page 13: A3. Function Configuration

    A3-1 <A3. Function Configuration> A3. Function Configuration The block diagram below describes the communication interface functions of YFGW610. Communication function Connect to YFGW510 Connect to YFGW410 Field wireless Optical network interface 1 backbone interface 1 Field wireless Optical network interface 2...
  • Page 14: A4. Names Of Parts

    A4-1 <A4. Names of Parts> A4. Names of Parts A4.1 Front view Status indicator LED Power supply connector Optical network Optical network Field wireless interface 1 interface backbone interface Field wireless Optical network backbone Link/ACT interface 2 interface 1 Field wireless backbone Optical network interface 2...
  • Page 15: A4.3 Rear View

    <A4. Names of Parts> A4.3 Rear view DIN rail mounting bracket FA0403 Figure A4-3 Rear view On the back of YFGW610, there is a mounting bracket to mount to a DIN rail. YFGW610 sup- ports DIN rail mounting alone. IM 01W02D02-01EN...
  • Page 16: A4.4 Top View

    FA0404 Figure A4-4 Top view There are power supply connectors and a ground terminal on the top of YFGW610. The spring terminals, which are the main components of the power supply connector to connect external wiring, are fixed by fastening the two screws of the terminals in the sockets of the hous- ing.
  • Page 17: A5. Led Indications

    A5. LED Indications The LED indications are as follows. Table A5-1 LED indications Function Indicates the status of YFGW610 Indicates the status of optical network interface 1 Indicates the status of optical network interface 2 LINK Indicates the status of optical network interface 3...
  • Page 18: A6. Operational Element

    A6-1 <A6. Operational Element> A6. Operational Element YFGW610 does not have any switches or buttons that can be mechanically operated from the outside of the housing. IM 01W02D02-01EN...
  • Page 19: A7. Checking The Product

    A7-1 <A7. Checking the Product> A7. Checking the Product When you receive YFGW610, please check that the product specifications match your order, all items are included, and there is no damage, stains, or other problems. Power supply connectors with Push-in spring-cage connection...
  • Page 20: Installation

    Wiring of the power supply, ground and network cable B1. System Installation Specifications The system must be installed in an appropriate environment to ensure stable system operation. The following defines the detailed specifications of YFGW610 installation environment. Table B1-1 System installation specifications Applicable stand-...
  • Page 21 1 m away. • The field wireless device radio output is about 10 mW. There is no impact for YFGW610, but keep to 1m than the same way as the 1 W output radio device.
  • Page 22: B2. Power Supply And Grounding

    • To avoid such a problem, supply the power source from the permanent power supply unit. IMPORTANT • YFGW610 does not have a power switch. Provide a breaker or switch for the external power line to turn on/off the device.
  • Page 23: B2.2 Grounding

    Appropriate grounding is necessary for the stable operation of YFGW610. Class D grounding (the third class grounding) with the ground resistance of 100 ohms or less is necessary. To con- nect the ground cable to YFGW610 directly, use the frame ground (FG) terminal on the top side of the housing.
  • Page 24: B3. Mounting

    B3-1 <B3. Mounting> B3. Mounting Mount YFGW610 on the DIN rails being secured to the general-purpose instrumentation board or others. No other type of mounting is allowed. B3.1 Mounting Direction YFGW610 is cooled down by natural air flow. Install it correctly.
  • Page 25: B3.2 Mounting Of Din Rails

    YFGW610 or cable tension. To securely ground YFGW610, insert an insulation bushing between the DIN rails and mounting panel and tighten the screws. Insulate the DIN rails from the metal surface of the mounting panel.
  • Page 26: B3.3 Installation Of Yfgw610

    As shown in Figure B3-2, hook the top edge of the DIN rail mounting bracket onto the top of the DIN rail, and return YFGW610 back to the horizontal position. Then, hook the bottom edge of the mounting bracket onto the bottom of the DIN rail.
  • Page 27: B4. Power, Ground, And Network Cable Connection

    B4-1 <B4. Power, ground, and signal cable connection> B4. Power, ground, and network cable connection This section explains the power, ground, and network cable connection to YFGW610. B4.1 Connection Terminals and Communication Interface Connect cables as follows; Power supply cable: to the spring terminals of YFGW610...
  • Page 28: B4.2 Power Supply Cable Connection

    IMPORTANT • Be careful to connect the power supply cable with correct polarity • YFGW610 does not have a power switch, so add a power switch or a circuit breaker to the external power line. FB0402...
  • Page 29 B4-3 <B4. Power, ground, and signal cable connection> To disconnect the power supply cable from the spring terminal, push down the orange areas around the cable inlet and pull out the power supply cable from the socket. FB0403 Figure B4-3 Disconnecting the power supply cable Applicable cables Insulated cables for industrial equipment such as;...
  • Page 30 B4-4 <B4. Power, ground, and signal cable connection> Wiring to spring terminals: 1 (without sleeve) • When using a solid conductor, strip the insulated cover and connect it. Strip the solid conductor by 10 mm. • When using a stranded conductor, strip the insulated cover and twist and connect it. Strip the stranded conductor for 10 mm.
  • Page 31 B4-5 <B4. Power, ground, and signal cable connection> Table B4-1 List of power supply cables Cable Dimensions (mm) Phoenix Contact's Section Strip type area length (mm) 0.25 10.5 0.15 0.25 AI 0.25-6 BU 10.5 0.15 0.25 AI 0.34-6 TQ 0.34 12.5 0.15 0.25...
  • Page 32: B4.3 Grounding

    Connect the ground leads from the frame ground (FG) terminal to the ground. Connect the cable shield or others to the power supply spring terminal.The internal wiring of YFGW610 housing is connected as shown in the following fi gure.
  • Page 33 B4-7 <B4. Power, ground, and signal cable connection> FB0405 Figure B4-5 Grounding terminal connection procedure IM 01W02D02-01EN...
  • Page 34 B4-8 <B4. Power, ground, and signal cable connection> Applicable cables Insulated wires for industrial equipment Examples: • 600 V polyvinyl chloride insulated wires (IV): JIS C3307 • Polyvinyl chloride insulated wires for electrical apparatus (KIV): JIS C3316 • 600 V grade heat-resistant polyvinyl chloride insulated wires (HIV): JIS C3317 •...
  • Page 35: B4.4 Network Cable Connection

    Figure B4-6 Metal network wiring Optical network (YFGW510 side) wiring To the optical network interface (YFGW510 side) on the left side of the front face of YFGW610, connect an optical network cable conforming to the 100BASE-FX standard, terminated with a SC connector.
  • Page 36: B5. Explosion-Proof Wiring

    B5-1 <B5. Explosion-Proof Wiring> B5. Explosion-Proof Wiring - Application pending - (Left blank intentionally) IM 01W02D02-01EN...
  • Page 37: B6. Settings

    B6-1 <B6. Settings> B6. Settings There are no setting elements in YFGW610. After properly wiring the power supply, ground and network cable, turn on YFGW610. If the RDY display does not turn green, see C. Maintenance. IM 01W02D02-01EN...
  • Page 38: Part-C. Maintenance

    Check the installation status of YFGW610, power supply cable and network cable connection status, and stain status. If YFGW610 becomes dirty or dusty, wipe with a soft cloth moistened with water or mild soap. IM 01W02D02-01EN...
  • Page 39: C2. Adding And Replacing Devices

    C2-1 <C2. Adding and replacing devices> C2. Adding and replacing devices For details on how to add or replace devices, see “E. Maintenance” of the User’s Manual of YFGW410 (IM 01W02D01-01EN). IM 01W02D02-01EN...
  • Page 40: C3. Maintenance In Hazardous Area

    To carry out maintenance, check the power supply, ground and network cable for looseness. Explosion-proof instruments must retain their intended properties before and after maintenance. Otherwise, hazardous conditions can arise. Be sure to consult with Yokogawa for any repair and alteration.
  • Page 41: C4. Parts With Defined Life Spans

    C4-1 <C4. Parts with Defined Life Spans> C4. Parts with Defined Life Spans YFGW610 does not include any parts with defined life spans, which need to be replaced. Read the following descriptions of parts with defined life spans. IMPORTANT Notes regarding parts with defined life spans •...
  • Page 42: Part-D. Troubleshooting

    Abnormal Orange Green If this LED is lit in red or off while energizing, YFGW610 may be broken. Replace the product. Communication status Other LEDs indicate the status of each communication interface. If any LED indicates abnormal status, check the wiring and the housing. If there is any problem in YFGW610, replace it.
  • Page 43: Specifications

    E1-1 <E1. Standard Specification> Part-E. Specifications E1. Standard Specification Communication interface Field Wireless Backbone Optical Network Specifica- ITEM Specifications tions Communication Inter- Standard 100BASE-TX 100BASE-FX face Transmission Speed 100Mbps 100Mbps Connector RJ-45 SC connector [1pole x 2] Multi-Mode Fiber Cable Type Category 5 50/125 or 62.5/125μm (2 cores)
  • Page 44: E2. Model And Suffix Codes

    To be compliant with these standards, the YFGW610 hardware needs to be installed in a lockable metal cabinet. To be compliant with these standards, the YFGW610 hardware needs to be installed in a lockable metal cabinet of IP54 or higher protection rating.
  • Page 45: E3. External Dimensions

    E3-1 <E3. External Dimensions> E3. External Dimensions Unit; mm DIN rail mounting center F04.ai IM 01W02D02-01EN...
