- Page 1 LCD COLOUR TV USER'S MANUAL LCD3703EU Part No: IES050326...
-
Page 2: Table Of Contents
SAFETY CLASS This is an IEC safety class I product and must be grounded for safety. CONTENTS CONTENTS Important safeguard ......................... Stand installation . -
Page 3: Important Safeguard
The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the CAUTION presence of uninsulated dangerous voltage within the product s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. CAUTION: TO REDUCE THE RISK OF ELEC- TRIC SHOCK, DO NOT REMOVE COVER(OR BACK).NO USER-... -
Page 4: Stand Installation
STAND IN STALLATION WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Stand installation 1.Fix the base on the mainbody with four screws. - 2 -... -
Page 5: Preparation For Your New Tv
Preparation for Using your new TV Selecting a location for the TV 1)Place the TV on the floor or on a sturdy platform in a location where light does not directly hit the screen. 2)Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause overheating, which may damage the TV. -
Page 6: Preparation For Using Your New Tv
Preparation for Using your new TV Remote Sensing Window PC audio input Power Switch (ON/OFF) Power indicator AV video input AC Power Socket Headphone output Scart1 connector AV audio input Menu button audio output audio output Scart2 connector Source select Subwoofer output RS232C DEBUG input Volume down / cursor left... -
Page 7: Connecting Your Tv
Preparation for Using your new TV Connecting your TV Caution: Do not plug the TV in until you have finished connecting all of your equipment. Connecting to A/V equipments To enjoy its multimedia features, you can connect your to A/V equipments such as VCR, DVD, STB, Satellite receiver, Camcorder, Audio amplifier etc., and select signal sources using your remote control. -
Page 8: Connecting To An Antenna
Preparation for Using your new TV PC/NB RGB line ANT IN To speaker AUDIO IN COMPONENT IN To VGA Audio line Connecting to an antenna To enjoy the terrestrial signal transmitted by your local TV station, you need an indoor or outdoor antenna (not supplied). -
Page 9: Using The Remote Control
Using the remote control Preparing the remote control for use Installing the remote control batteries 1. Open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the + and - signs on the batteries to the signs on the battery compartment. -
Page 10: Learning About The Remote Control
Using the remote control Learning about the remote control Power:Power on/off Channel number: Direct channel selection Teletext select Recall : Return to previous channel Display:Display current input P.Mode:Select picture mode Text Teletext CH+:Channel up VOL-:Volume down VOL+:Volume up CH-:Channel down Menu:Call up the main menu S.Mode:Select sound mode Mute:Mute the sound... -
Page 11: Using The Tv Features
Using the TV features Understanding the TV features Multimedia - TV receiver, Video monitor and PC display, all in one. Wider viewing angle, 16:9 display - 176¡ã viewing angle at typical value Digital display device - truthfully reproducing the images, without distortion or blurring, irrespective of magnetic or geomagnetic effect. - Page 12 Using the TV features Select channels by [CH+/CH-] You can also use[CH+ / CH-] to select channels. [CH+] i ndicates channel number increase; [CH-] indicates channel number decrease. Select channels by numbers To select a channel : Press the channel numbers in series to select channel directly. For example, to seclect channel 120, Press the button 1, and 1 will display on the top right corner of the screen, then press the button 2, 12 will display, press the button zero, you can enjoy the program of channel 120.
-
Page 13: Using The Tv Settings Menu
Using the TV features Using the TV settings menu Program Tv settings 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item TV settings 3) Press the [CH+ or CH-] button to select Program. -
Page 14: Using The Picture Menu
Using the TV features Channel edit 1) Press the MENU button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item TV settings. 3) Press the [CH+ or CH-] button to select Channel edit. 4) Press the [ VOL+] button to start Channel edit. -
Page 15: Using The Osd Setting Menu
Using the TV features Using the OSD settings menu OSD position OSD settings 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item OSD settings. 3) Press the [CH+ or CH-] button to select OSD position OSD position 4) Press the... -
Page 16: Using The General Settings Menu
Using the TV features Using the General settings menu Colour system General settings You can set colour syetem. 1) Press the [MENU] button to enter the main menu. Language english 2) Press the [VOL+ or VOL-] button to select the item General settings Colour system 3) Press the... -
Page 17: Teletext Operations
Using the TV features Using the PC menu PC Parameters 1) Press the MENU button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item PC Parameters. 3) Press the [CH+ or CH-] button to select the item you Auto LANGUAGE ENGLISH... - Page 18 Using the TV features Teletext Operations Sub code Some Teletext pages contain sub page that require you to input the sub code. Press [ Zoom ] button until ***|**** is displayed, and enter last four-digit sub code for the sub page you need. You can mix Teletext with TV pictures, which means transparent teletext.
-
Page 19: Appendix
Appendix The SCART interface Also known as Peritel, this standard provides a cheap multi-signal connector to domestic TV and other video equipment. Arrangement 1 is the original and allows for composite video input/output, RGB inputs and stereo audio input/output. Arrangement 2 allows for composite video input/output,and stereo audio input/output. - Page 20 Appendix SCART arrangement 2 Pin Signal Signal level Impedance Audio output B (right) 0.5V rms <1kohm Audio input B (right) 0.5V rms >10kohm Audio output A (left) 0.5V rms <1kohm Ground (audio) Ground Audio input A (left) 0.5V rms >10kohm High (5 - 12V) - AV mode >10kohm Function select (AV control)
-
Page 21: Cleaning And Care
SCART arrangement 3 Pin Signal Signal level Impedance Audio output B (right) 0.5V rms <1kohm Audio input B (right) 0.5V rms >10kohm Audio output A (left) 0.5V rms <1kohm Ground (audio) Ground Audio input A (left) 0.5V rms >10kohm High (9.5-12V) - AV mode Function select (AV control) >10kohm Mid(5-8V)-Wide-screen... -
Page 22: Troubleshooting
Appendix Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solutions. Possible Solutions Symptoms Make sure the power cord is plugged in, then press [Power]. TV will not turn on The remote control batteries may be dead. -
Page 23: Specifications
Specifications LCD3703EU 940.3mm TFT LCD LCD panel Multi- system(PAL,SECAM) Television system VHF-L: E2-S8 Channel coverage VHF-H: S9-S37 UHF: S38-E69 640X480/60Hz,800X600/60Hz,1024X768/60Hz,1280X1024/60Hz Analog RGB mode 480I/60Hz,480P/60Hz,576I/50Hz,576P/50Hz,720P/50Hz,720P/60Hz, mode 1080I/50Hz,1080I/60Hz 1366X768 Resolution 600:1 Contrast 500cd/m Brightness Viewing angle 176 (H)/176 (V) AC160V--240V, 50/60Hz Power source...
