STEP 3 CONNECT DUCTWORK
• Install ductwork, making connections in direction of
airflow as illustrated.
• Secure joints in ductwork with sheetmetal screws.
• Wrap all duct joints with
duct tape for an airtight seal.
• Use duct tape to seal the
flange connection.
Reach inside the
Duct Tape
hood and push
Over Seam
the damper up
and Screw
to be sure it
moves freely.
Duct Tape
Over Transition
STEP 4 CONNECT ELECTRICAL
Verify that power is turned off at the source.
WARNING:
2-wire with a ground wire, a ground must be provided
by the installer. When house wiring is aluminum, be
sure to use U.L. approved anti-oxidant compound
and aluminum-to-copper connectors.
AVERTISSEMENT –
de la maison n'est pas du type à deux fils avec un fil de
terre, l'installateur doit fournir un circuit de terre.
Quand les fils de la maison sont en aluminium, il
prendre soin d'utiliser de la pâte antioxidation
approuvée par UL et des connecteurs pour
l'aluminium-cuivre.
A
Remove
B
Insert Power
Junction Box
Conduit Thru
Cover
Strain Relief
and Tighten
Ground
C
Use UL Listed
Wire Nuts
• Use wire nuts to connect incoming ground to green,
white to white and black to black.
• Push wires into junction box and replace cover. Be
sure wires are not pinched.
Installation Instructions
Air Flow
Screw
If house wiring is not
Si le câblage
White
STEP 5 INSTALL DUCT COVERS
Note: For easier handling, remove cardboard insert
after film is peeled off.
Remove protective film from duct covers. If more than
one duct cover is used, secure each piece together with
screws provided.
• Place the duct cover(s) on top of the hood.
• From inside the hood, secure the duct cover to the
top with the small Phillips head screws supplied with
the covers.
STEP 6 INSTALL MOTOR
• From the inside of the hood, slip motor into the
attachment slot on the left.
• Rotate motor upwards until it snaps into the spring
clip on the right.
• Secure the motor to the hood with the machine
screw and lock washer. (Screw is marked with red
or blue paint.)
• Plug connector into the motor.
Top
Black
IMPORTANT: Connector ends
are designed to mate only
one way. Match flat and
round connectors as shown.
13
Outlet
Attachment
Spring
Slot
Clip
Attachment
Screw
Spring
Clip
