36 COOKTOPS/DOWNDRAFT UNITS
1
Overall Cooktop Dimensions
2
Overall Cutout Dimensions
NOTE: AGAINST-THE-WALL INSTALLATIONS ARE LIMITED DUE TO DIMENSION REQUIREMENTS.
REFER TO DETAILS BELOW.
PLANNING INSTALLATION (Note: 26 deep cabinets required)
A B
(Figure 1) (Figure 1) (Figure 1)
Cooktop Cooktop
Overall Overall
Model No.
Width Depth
JP622
35-1/2 21
JP623
JP681 35-1/2 21
JP692
35-1/2 20-3/4
JP693
JGP630
35-1/2 21
JGP631
*Required to maintain UL or AGA approvals.
JVB64, JVB65, JVB96
Figure 1
Figure 2
C B&C
(Figure 1)
Depth
Vent Cktop +
Depth D.D. Vent
2 23
2 23
2 22-3/4
2 23
3
I
D
(Figure 3*) (Figure 2)
Min. Setback—
Front Edge Min. Req'd.
Cntrtop to Front Inside Cabinet
Edge of Cutout Clearance
3-1/4 22
3-1/4 21-9/16
2 22-7/16
3-1/4 22
Figure 3
Cutout for Vent
PREPARING CUTOUT
E F G
(Figure 2) (Figure 2) (Figure 3)
Cooktop Cooktop Add'l Depth
Cutout Cutout Req'd for
Width Depth Downdraft
33-7/8 19-1/16 2-7/8
33-7/8 19-1/16 2-7/8
34-5/8 19-15/16 2-5/16
33-7/8 19-1/16 2-7/8
H
(Figure 3)
Downdraft
Cutout Width
Req'd from
Centerline
33-1/16
33-1/16
33-1/16
33-1/16
7
