- Page 1 S E R V I C E M A N U A L SL-220 Spring Replacement Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description SL220-SK7...
- Page 2 D (1) B (1) 08-32 08-32 x 1" A (1) [Spring] C (1) .280 x .177 x .215 *NOTE: The appearance of these parts may vary from the parts being removed during service due to Chief’s program of continuous improvement.
- Page 3 Service Manual SL220-SK7 Replacing Spring Extend SL220 from ceiling. Unhook broken spring from ceiling pan. (See Figure 1) Ceiling pan Figure 1 Remove spring assembly from SL220 leg. (See Figure 2) Figure 2 Attach new spring (A) to SL220 leg using one 08-32 x 1"...
- Page 4 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
