USER'S GUIDE
N-FX-xxxx-02(x)
N-FX-xxxx-02 (standard)
N-FX-xxxx-02 (L) (low profile)
100Base-FX, Fast Ethernet Fiber NICs
Transition Networks' N-FX series of fast
Ethernet NICs (Network Interface Cards)
provide a 100Base-FX fiber port to deliver
low-cost fiber optic connectivity to the desktop
in fiber-rich LAN environments. With both
standard and low profile form factors, driver
support for most operating systems, and PCI
2.2 plug-and-play capability, these fast Ethernet NICs can be installed in virtually
any PC on the network.
Part Number
Port One - Duplex Fiber-Optic 100Base-FX
N-FX-ST-02
ST, 1300 nm multimode, 2 km (1.2 miles)*
N-FX-ST-
02(L)
N-FX-SC-02
SC, 1300 nm multimode, 2 km (1.2 miles)*
N-FX-SC-02(L)
N-FX-LC-02
LC, 1300 nm multimode, 2 km (1.2 miles)*
N-FX-LC-02(L)
N-FX-LC20-02
LC, 1310 nm single mode, 20 km (12.4 miles)*
N-FX-MT-02
MT-RJ, 1300 nm multimode, 2 km (1.2 miles)*
N-FX-MT-02(L)
N-FX-SC5-02
SC, 1310 nm single mode, 5 km (3.1 miles)*
N-FX-SC5-02(L)
N-FX-SC20-02
SC, 1310 nm single mode, 20 km (12.4 miles)*
N-FX-SC20-02(L)
N-FX-SB201-02
SC, 1310 TX/1550nm RX single mode, single fiber 20 km
02(L)
(12.4 miles)*
N-FX-SB201-
N-FX-SB202-02
SC, 1550 TX/1310 nm RX single mode, single fiber 20 km
(12.4 miles)*
N-FX-SB202-02(L)
Optional accessories sold separately
Part Number
Description
BTR-NFX
Boot ROM chip supports BBS (Bios Boot specification) and
non-BSS compliant PCs.
*Typical maximum cable distance. Actual
distance is dependent upon the physical
characteristics of the network installation.
Installation . . . . . . . . . . . . . . . . . . .2
Cable Specifications . . . . . . . . . . .4
Technical Specifications . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . . .6
Contact Us . . . . . . . . . . . . . . . . . . .7
Advertisement
Table of Contents
Related Manuals for Transition Networks N-FX-xxxx-02
Summary of Contents for Transition Networks N-FX-xxxx-02
- Page 1 USER’S GUIDE N-FX-xxxx-02(x) N-FX-xxxx-02 (standard) N-FX-xxxx-02 (L) (low profile) 100Base-FX, Fast Ethernet Fiber NICs Transition Networks’ N-FX series of fast Ethernet NICs (Network Interface Cards) provide a 100Base-FX fiber port to deliver low-cost fiber optic connectivity to the desktop in fiber-rich LAN environments. With both...
- Page 2 N-FX Series Fast Ethernet NICs Installation To install the N-FX module, do the following: Important: Install the N-FX module in a “master slot” only. Checklist Locate a master slot on the PC workstation or file server. Before installing the N-FX module, verify that the package contains the following items: Remove the cover from the PC workstation or file server—keep all screws.
-
Page 3: Cable Specifications
N-FX Series Fast Ethernet NICs Cable Specifications Technical Specifications For models N-FX-xxxx-02 and N-FX-xxxx-02(L) Fiber cable Standards: IEEE 802.3 Bit error rate: <10-9 Expansion bus standard: PCI 2.1, 2.2 Single mode fiber (recommended): 9 µm Data rate 100Mbps fiber media Multimode fiber (recommended): 62.5/125 µm... -
Page 4: Troubleshooting
SB201-02(x), N-FX-SB202-02(x) EMC Directive 89/336/EEC Regulation: Purpose: To declare that the N-FX-xxxx-02 and N-FX-xxxx-02(L), to which this declaration refers, is in conformity with the following standards: CISPR 22:1997+A1:2000; EN 55022:1998+A1:2000 Class A; FCC Part 15 Subpart B; 21CFR subpart J I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s). -
Page 5: Compliance Information
Compliance Information CISPR22/EN55022 Class A, CE Mark, CISPR22/EN55022 Class A + EN55024, CE Mark FCC regulations This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
